Lantronix XPort Pro XPP1004000-02R Kurzanleitung zur Einrichtung

Part Number 900-557

Revision JAugust 2017

xPort Pro

Embedded Device Server

Integration Guide

xPort® Pro Embedded Device Server Integration Guide 2

may be transmitted or reproduced in any form or by any means without the written

permission of Lantronix.

Lantronix and xPort are registered trademarks of Lantronix, Inc. in the United States

and other countries. Evolution OS is registered trademark of Lantronix, Inc. in the

United States. DeviceInstaller is a trademark of Lantronix, Inc.

Windows and Internet Explorer are registered trademarks of Microsoft Corporation.

Mozilla and Firefox are registered trademarks of the Mozilla Foundation. Chrome is a

trademark of Google. Opera is a trademark of Opera Software ASA. Freescale is a

registered trademark of Freescale Semiconductor, Inc. Broadcom is a registered

trademark of Broadcom Corporation. All other trademarks and trade names are the

property of their respective holders.

Warranty

For details on the Lantronix warranty policy, please go to our Web site at

www.lantronix.com/support/warranty.

Contacts

Lantronix, Inc. Corporate Headquarters

7535 Irvine Center Drive

Suite 100

Irvine, CA 92618, USA

Toll Free: 800-526-8766

Phone: 949-453-3990

Fax: 949-453-3995

Technical Support

Online: www.lantronix.com/support

Sales Offices

For a current list of our domestic and international sales offices, go to the Lantronix

web site at www.lantronix.com/about/contact.

Disclaimer and Revisions

Operation of this equipment in a residential area is likely to cause interference, in

which case the user, at his or her own expense, will be required to take whatever

measures may be required to correct the interference.

Note: This product has been designed to comply with the limits for a Class B digital

device pursuant to Part 15 of FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy, and if not

installed and used in accordance with this guide, may cause harmful interference to

radio communications.

Changes or modifications to this device not explicitly approved by Lantronix will void

the user's authority to operate this device.

Note: With the purchase of Lantronix® xPort® Pro embedded device server, the

OEM agrees to an OEM firmware license agreement that grants the OEM a non-

exclusive, royalty-free firmware license to use and distribute the binary firmware

xPort® Pro Embedded Device Server Integration Guide 3

image provided, only to the extent necessary to use the xPort Pro hardware. For

further details, please see the xPort Pro OEM firmware license agreement.

Revision History

Date

Rev.

Comments

September 2009

Initial Draft

December 2010

Updated Lantronix address/contact information.

March 2011

Updated SDRAM number information.

April 2011

Updated part number information.

September 2011

Updated compliance information.

April 2012

Updated Pin 4 state and part number information.

August 2012

Updated recommended operating condition and part number

information.

June 2016

Updated to include the xPort Pro Lx6 part number and unit of

measurement information.

August 2017

Updated part number SKU information.

xPort® Pro Embedded Device Server Integration Guide 4

Table of Contents

Disclaimer and Revisions ______________________________________________ 2

Revision History _____________________________________________________ 3

List of Figures _______________________________________________________ 5

List of Tables _______________________________________________________ 5

1. Introduction 6

About the Integration Guide ____________________________________________ 6

Additional Documentation______________________________________________ 6

2. Description and Specifications 7

The xPort Pro Features _______________________________________________ 7

xPort Pro Block Diagram ______________________________________________ 8

PCB Interface _______________________________________________________ 9

Ethernet Interface ___________________________________________________ 10

LEDs _____________________________________________________________ 10

Dimensions________________________________________________________ 11

Recommended PCB Layout___________________________________________ 12

Product Information Label ____________________________________________ 13

Electrical Specifications ______________________________________________ 13

Functional Specifications _____________________________________________ 14

A: xPort Pro 485 Connection Diagram 16

B: Compliance Information 17

RoHS, REACH and WEEE Compliance Statement _________________________ 17

xPort® Pro Embedded Device Server Integration Guide 5

List of Figures

Figure 2-1. Side View of the xPort Pro ____________________________________ 8

Figure 2-2. xPort Pro Block Diagram _____________________________________ 8

Figure 2-3. xPort Pro LEDs ___________________________________________ 10

Figure 2-4. Front View _______________________________________________ 11

Figure 2-5. Bottom View ______________________________________________ 11

Figure 2-6. Side View ________________________________________________ 11

Figure 2-7. PCB Layout ______________________________________________ 12

Figure 2-8. Product Label _____________________________________________ 13

List of Tables

Table 2-1 xPort Pro Part Numbers ______________________________________ 7

Table 2-2 PCB Interface Signals ________________________________________ 9

Table 2-3 Ethernet Interface Signals (Industry Standards) ___________________ 10

Table 2-4 Absolute Maximum Ratings __________________________________ 13

Table 2-5 Recommended Operating Conditions ___________________________ 13

Table 2-6 Technical Specifications _____________________________________ 14

xPort® Pro Embedded Device Server Integration Guide 6

1. Introduction

About the Integration Guide

This guide provides the information needed to integrate the Lantronix Port® Pro

embedded device server into a customer printed circuit board. This manual is

intended for engineers responsible for integrating the xPort Pro into their product.

Note: This document covers xPort Pro Embedded Device Server versions

XPP1004000-02R, XPP1002000-01R, XPP100200S-01R, XPP1002000-02R,

XPP100200S-02R, XPP1003000-01R, XPP100300S-01R, XPP1003000-04R and

XPP100300S-04R.

Additional Documentation

Visit the Lantronix web site at www.lantronix.com/support/documentation for the

latest documentation and the following additional documentation.

Document

Description

xPort Pro Embedded

Device Server User Guide

Provides information needed to configure, use,

and update the xPort Pro firmware.

xPort Pro Lx6 Embedded

Device Server User Guide

Provides information needed to configure, use,

and update the xPort Pro Lx6 firmware.

xPort Embedded Device

Server Universal Demo

Board Quick Start

Provides the steps for getting the xPort Pro up

and running.

xPort Embedded Device

Server Universal Demo

Board User Guide

Provides information needed to use the xPort Pro

on the demo board.

DeviceInstaller User

Guide

Provides instructions for using the Windows-

based utility to configure the xPort Pro and other

Lantronix device servers.

Com Port Redirector User

Guide

Provides information on using the Windows-

based utility to create a virtual com port.

xPort® Pro Embedded Device Server Integration Guide 7

2. Description and Specifications

The xPort Pro embedded device server is Lantronix’s most powerful, self-contained

embedded networking module. Footprint compatible with the popular xPort product

and running either Linux or the Lantronix Evolution OS® operating systems, the xPort

Pro eliminates the complexity of designing network connectivity into a product and

allows you to deploy advanced applications on the edge device itself. The thumb-

sized xPort Pro provides everything you need in a single embedded solution. It

effortlessly handles demanding applications with the power of a high-speed,

advanced architecture 32-bit processor. The ample built-in memory allows virtually

unlimited flexibility for customization and application enablement.

xPort Pro provides bullet-proof security by offering a variety of robust data encryption

and authentication options. What’s more, the option to run Linux, with IPv6 built in,

enables you to deploy custom applications and take advantage of the large feature

libraries available for Linux developers. Critical agency certification has already been

completed by Lantronix, reducing your test time and speeding time-to-market.

The xPort Pro Features

The xPort Pro contains a 32-bit Freescale® processor, with 8/16 megabytes (MB) of

SDRAM (see Table 2-1), 16 MB of Flash and an integrated Broadcom® 10/100 PHY.

Table 2-1 xPort Pro Part Numbers

Part Numbers

SDRAM

Operating System

XPP1002000-01R

8 MB

Evolution

XPP100200S-01R

8 MB

Evolution

XPPDK1000-EVO-01

8 MB

Evolution

XPP1002000-02R

16 MB

Evolution

XPP100200S-02R

16 MB

Evolution

XPPDK1000-EVO-02

16 MB

Evolution

XPP1003000-01R

8 MB

Linux

XPP100300S-01R

8 MB

Linux

XPPDK1000-LNX-01

8 MB

Linux

XPP1003000-04R

16 MB

Linux

XPP100300S-04R

16 MB

Linux

XPPDK1000-LNX-02

16 MB

Linux

XPP1004000-02R

16 MB

Linux

2: Description and Specifications

xPort® Pro Embedded Device Server Integration Guide 8

The xPort Pro also contains the following:

3.3-volt serial interface

All I/O pins are 3.3V tolerant

Ethernet magnetics

Power supply filters

Reset circuit

+1.5V regulator

Crystals and Ethernet LEDs

The xPort Pro requires +3.3-volt power and is designed to operate in an extended

temperature range (see technical data).

Figure 2-1. Side View of the xPort Pro

xPort Pro Block Diagram

The following drawing is a block diagram of the xPort Pro showing the relationships

of the components.

Figure 2-2. xPort Pro Block Diagram

RJ45

CMOS IO

RESET

+3.3VDC

32-bit CPU

FLASH/SDRAM

MAGNETICS

LEDs

PHY

2: Description and Specifications

xPort® Pro Embedded Device Server Integration Guide 9

PCB Interface

The xPort Pro has a serial port compatible with data rates up to 921600 bps. The

serial signals (pins 4–8) are 3.3V CMOS logic level. The serial interface pins include

+3.3V, ground, and reset. The serial signals connect to an internal UART driven at

3.3V. For applications requiring an external cable running with RS-232 or RS422/485

voltage levels, the xPort Pro must interface to a serial transceiver chip. We supply an

RS-232 transceiver on the xPort Universal Demo Board for this purpose.

Note: The standard baud rate of 460800 bps is not supported.

Table 2-2 PCB Interface Signals

Signal Name

xPort Pro

Pin #

Primary Function

GND

Circuit ground

3.3V

+3.3V power in

Reset

External reset in

Data Out

Serial data out (driven by built-in UART)

Data In

Serial data in (input to built-in UART)

CP1/RTS

(Configurable Pin 1)

6 CP1 can be configured as follows:

•Flow control: RTS (Request to Send) output driven

by the built-in UART for connection to CTS of

attached device.

•Programmable input/output: CP1 can be driven or

read through software control, independent of serial

port activity.

•RS485 Transmit Enable: In RS485 mode, CP1 is

driven by the built-in UART for connection to the

transmit enable pin of an RS485 Transceiver.

CP2/DTR

(Configurable Pin 2)

7 CP2 can be configured as follows:

•Modem control: DTR (Data Terminal Ready)

output driven by the built-in UART for connection to

DCD of attached device.

•Programmable input/output: CP2 can be driven or

read through software control, independent of serial

port activity.

CP3/CTS/DCD

(Configurable Pin 3)

8 CP3 can be configured as follows:

•Flow control: CTS (Clear to Send) input read by

the built-in UART for connection to RTS of attached

device.

•Modem control: DCD (Data Carrier Detect) input

read by the built-in UART for connection to DTR of

attached device.

•Programmable input/output: CP3 can be driven or

read through software control, independent of serial

port activity.

1 Data out will float during and immediately after power up or assertion of RESET on Pin 3. Pin 4 can be pulled

up to +3.3V with a 10K ohm or larger resistor to hold the pin high during reset.

2: Description and Specifications

xPort® Pro Embedded Device Server Integration Guide 10

Ethernet Interface

The Ethernet interface magnetics, RJ45 connector, and Ethernet status LEDs are all

in the device server shell. The xPort Pro PHY is Auto MDIX capable allowing

connection to either straight through or cross over Ethernet cables.

Table 2-3 Ethernet Interface Signals (Industry Standards)

Signal Name

DIR

Contact

Primary Function

TX+

Out

Differential Ethernet transmit data +

TX-

Out

Differential Ethernet transmit data -

RX+

Differential Ethernet receive data +

RX-

Differential Ethernet receive data -

Not used

Terminated

Not used

Terminated

Not used

Terminated

Not Used

Terminated

SHIELD

Chassis ground

LEDs

The xPort Pro contains the following LEDs:

Link (solid green, left LED)

Activity (blinking amber, right LED)

Figure 2-3. xPort Pro LEDs

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Lantronix Server Handbücher

Lantronix

Lantronix SLC48 Bedienungsanleitung

Lantronix

Lantronix xPico XPW100A003-01-B Kurzanleitung zur Einrichtung

Lantronix

Lantronix xSenso 2100 Bedienungsanleitung

Lantronix

Lantronix PremierWave EN Bedienungsanleitung

Lantronix

Lantronix xSenso 2100 Bedienungsanleitung

Lantronix

Lantronix UDS200 Bedienungsanleitung

Lantronix

Lantronix EDS3000PR Bedienungsanleitung

Lantronix

Lantronix DeviceLinx EDS00812N-01 Bedienungsanleitung

Lantronix

Lantronix Device Server MSS 485 Bedienungsanleitung

Lantronix

Lantronix SLC8 Bedienungsanleitung

Lantronix

Lantronix UDS1100 Bedienungsanleitung

Lantronix

Lantronix EDS3000PR Bedienungsanleitung

Lantronix

Lantronix xDirect-IAP Bedienungsanleitung

Lantronix

Lantronix XPortPro Bedienungsanleitung

Lantronix

Lantronix xport pro Installationshandbuch

Lantronix

Lantronix MSS1-T Bedienungsanleitung

Lantronix

Lantronix XPico 900-691-R Bedienungsanleitung

Lantronix

Lantronix MSS1-T Bedienungsanleitung

Lantronix

Lantronix XPress DR+ Bedienungsanleitung

Lantronix

Lantronix Device Installer Bedienungsanleitung

Lantronix

Lantronix PremierWave XC Bedienungsanleitung

Lantronix

Lantronix MatchPort b/g Pro Installationshandbuch

Lantronix

Lantronix WiPort Kurzanleitung zur Einrichtung

Lantronix

Lantronix xDirect Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung

Lantronix xPort Pro XPP1004000-02R Kurzanleitung zur Einrichtung

Beliebte Server Handbücher anderer Marken
