About the Integration Guide

This guide provides the information needed to integrate the XPort Pro™device

server into a customer printed circuit board. This manual is intended for engineers

responsible for integrating the XPort Pro into their product.

Note: This document covers XPort Pro™ Device Server versions XPP1002000-01R,

XPP100200S-01R, XPP1003000-01R, XPP100300S-01R, XPP1003000-02R and

XPP100300S-02R.

Additional Documentation

Visit the Lantronix web site at www.lantronix.com/support/documentation

for the

latest documentation and the following additional documentation.

Document

Description

XPort Pro User Guide Provides information needed to configure, use,

and update the XPort Pro firmware.

XPort Universal Demo

Board Quick Start Provides the steps for getting the XPort Pro up

and running.

XPort Universal Demo

Board User Guide Provides information needed to use the XPort

Pro on the demo board.

DeviceInstaller User

Guide Provides instructions for using the Windows-

based utility to configure the XPort Pro and other

Lantronix device servers.

Com Port Redirector User

Guide Provides information on using the Windows-

based utility to create a virtual com port.

XPort Pro Integration Guide 6

The XPort Pro is Lantronix’ most powerful, self-contained embedded networking

module. Footprint compatible with the popular XPort® and running either Linux or

Evolution OS™ operating systems, the XPort Pro eliminates the complexity of

designing network connectivity into a product and allows you to deploy advanced

applications on the edge device itself. The thumb-sized XPort Pro provides

everything you need in a single embedded solution. It effortlessly handles demanding

applications with the power of a high-speed, advanced architecture 32-bit processor.

And with ample built-in memory, it allows virtually unlimited flexibility for

customization and application enablement.

XPort Pro provides bullet-proof security by offering a variety of robust data encryption

and authentication options. What’s more, the option to run Linux, with IPv6 built in,

enables you to deploy custom applications and take advantage of the large feature

libraries available for Linux developers. XPort Pro also includes Lantronix’ patent

pending VIP (Virtual IP) Access™ technology, which allows for seamless integration

with the ManageLinx™ remote services enablement platform. Critical agency

certification has already been completed by Lantronix, reducing your test time and

speeding time-to-market.

The XPort Pro Features

The XPort Pro contains a 32-bit Freescale processor, with 8/16 Mbytes of SDRAM,

16 Mbytes of Flash and an integrated Broadcom 10/100 PHY.

The XPort Pro also contains the following:

3.3-volt serial interface

All I/O pins are 3.3V tolerant

Ethernet magnetics

Power supply filters

Reset circuit

+1.5V regulator

Crystals and Ethernet LEDs

The XPort Pro requires +3.3-volt power and is designed to operate in an extended

temperature range (see technical data).

2: Description and Specifications

XPort Pro Integration Guide 7

Figure 2-1. Side View of the XPort Pro

XPort Pro Block Diagram

The following drawing is a block diagram of the XPort Pro showing the relationships

of the components.

Figure 2-2. XPort Pro Block Diagram

PCB Interface

The XPort Pro has a serial port compatible with data rates up to 921600 bps. The

serial signals (pins 4–8) are 3.3V CMOS logic level. The serial interface pins include

+3.3V, ground, and reset. The serial signals connect to an internal UART driven at

3.3V. For applications requiring an external cable running with RS-232 or RS422/485

voltage levels, the XPort Pro must interface to a serial transceiver chip. We supply an

RS-232 transceiver on the XPort Universal Demo Board for this purpose.

Note: The standard baud rate of 460800 bps is not supported.

RJ45

CMOS IO

RESET

+3.3VDC

32-bit CPU

FLASH/SDRAM

MAGNETICS

LEDs

PHY

2: Description and Specifications

XPort Pro Integration Guide 8

Table 2-1. PCB Interface Signals

Signal Name

XPort

Pro Pin

Primary Function

GND

Circuit ground

3.3V

+3.3V power in

Reset

External reset in

Data Out

Serial data out (driven by built-in UART)

Data In

Serial data in (input to built-in UART)

CP1/RTS

(Configurable Pin 1) 6 CP1 can be configured as follows:

•Flow control: RTS (Request to Send) output driven

by the built-in UART for connection to CTS of attached

device.

•Programmable input/output: CP1 can be driven or

read through software control, independent of serial

port activity.

•RS485 Transmit Enable: In RS485 mode, CP1 is

driven by the built-in UART for connection to the

transmit enable pin of an RS485 Transceiver.

CP2/DTR

(Configurable Pin 2) 7 CP2 can be configured as follows:

•Modem control: DTR (Data Terminal Ready) output

driven by the built-in UART for connection to DCD of

attached device.

•Programmable input/output: CP2 can be driven or

read through software control, independent of serial

port activity.

CP3/CTS/DCD

(Configurable Pin 3) 8 CP3 can be configured as follows:

•Flow control: CTS (Clear to Send) input read by the

built-in UART for connection to RTS of attached

device.

•Modem control: DCD (Data Carrier Detect) input

read by the built-in UART for connection to DTR of

attached device.

•Programmable input/output: CP3 can be driven or

read through software control, independent of serial

port activity.

2: Description and Specifications

XPort Pro Integration Guide 9

Ethernet Interface

The Ethernet interface magnetics, RJ45 connector, and Ethernet status LEDs are all

in the device server shell. The XPort Pro PHY is Auto MDIX capable allowing

connection to either straight through or cross over Ethernet cables.

Table 2-2 Ethernet Interface Signals (Industry Standards)

Signal Name

DIR

Contact

Primary Function

TX+

Out

Differential Ethernet transmit data +

TX-

Out

Differential Ethernet transmit data -

RX+

Differential Ethernet receive data +

RX-

Differential Ethernet receive data -

Not used

Terminated

Not used

Terminated

Not used

Terminated

Not Used

Terminated

SHIELD

Chassis ground

LEDs

The XPort Pro contains the following LEDs:

Link (solid green, left LED)

Activity (blinking amber, right LED)

Figure 2-3. XPort Pro LEDs

2: Description and Specifications

XPort Pro Integration Guide 10

Dimensions

The XPort Pro dimensions are shown in the following drawings.

Figure 2-4. Front View

RIGHT

LED

18.25 [0.719]

16.25 [0.640]

11.55 [0.455]

7.15 [0.281]

CONTACT 1

CONTACT 8

5.85 [0.230]

14.50 [0.571] 4.03 [0.158]

13.50 [0.531]

1.85 [0.073]

3.25 [0.128]

3.30 [0.130]

1.27 [0.050]

0.40 [0.016]

FRONT

VIEW

DIMS = mm (in)

LEFT

LED

SHIELD TAB

TOLERANCE

.XX+/-0.20[0.008]

Figure 2-5. Bottom View

Figure 2-6. Side View

33.90 [1.335]

1.00 [0.039]

0.35 [0.014] 10.84 [0.427]

6.35 [0.250]

2.54 [0.100] 3.20 [0.126]

0.60 [0.024]

FRONT SHIELD

GROUND

INTERFACE

PINS

DIMS = mm (in)

11.90 [0.468]

SHIELD TAB

TOLERANCE

.XX+/-0.20[0.008]

Andere Handbücher für xport pro

Inhaltsverzeichnis

Andere Lantronix Server Handbücher

Lantronix

Lantronix UDS200 Bedienungsanleitung

Lantronix

Lantronix SGX 5150 Bedienungsanleitung

Lantronix

Lantronix PremierWave XN Bedienungsanleitung

Lantronix

Lantronix MSS100 Bedienungsanleitung

Lantronix

Lantronix MSS4 Bedienungsanleitung

Lantronix

Lantronix EDS32PR Bedienungsanleitung

Lantronix

Lantronix XPico 900-691-R Bedienungsanleitung

Lantronix

Lantronix Com Port Redirector Bedienungsanleitung

Lantronix

Lantronix EDS-MD Series Bedienungsanleitung

Lantronix

Lantronix XPort Kurzanleitung zur Einrichtung

Lantronix

Lantronix XPortPro Bedienungsanleitung

Lantronix

Lantronix xPico Bedienungsanleitung

Lantronix

Lantronix Device Server UDS 10 Bedienungsanleitung

Lantronix

Lantronix SLC48 Bedienungsanleitung

Lantronix

Lantronix xDirect Bedienungsanleitung

Lantronix

Lantronix WiPort NR Bedienungsanleitung

Lantronix

Lantronix SLB Bedienungsanleitung

Lantronix

Lantronix xport pro Bedienungsanleitung

Lantronix

Lantronix XPort Kurzanleitung zur Einrichtung

Lantronix

Lantronix Device Installer Bedienungsanleitung

Lantronix

Lantronix SecureBox SDS2100 Bedienungsanleitung

Lantronix

Lantronix PremierWave XC Bedienungsanleitung

Lantronix

Lantronix Com Port Redirector Bedienungsanleitung

Lantronix

Lantronix ETS16PR Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung

Lantronix xport pro Kurzanleitung zur Einrichtung

Beliebte Server Handbücher anderer Marken
