Lectrosonics IFBR1B Bedienungsanleitung

Quick

Start

Guide

Fill in for your records:

Serial Number:

Purchase Date:

This guide is intended to assist with

initial setup and operation of your

Lectrosonics product.

For a detailed user manual, down-

load the most current

version at:

www.lectrosonics.com

IFBR1B

UHF Multi-Frequency Belt-Pack IFB Receiver

IFBR1B, IFBR1B-941, IFBR1B-VHF

17 March 2020

U.S. Patent 7,225,135

NOTE: The IFBR1B does not ship standard with

the single battery charger. To order this unit with a

charger, order as IFBR1B-WITH-CHARGER.

LECTROSONICS, INC.2

IFBR1B Features

Battery status

LED

On/Off and

volume knob

Headphone

output

LINK LED

On/Off and Volume Knob

Turns unit on or off and controls headphone audio level. When the IFBR1B is

ﬁrst turned on, the ﬁrmware version will display brieﬂy.

Battery Status LED

When the battery status LED glows green, the batteries are good. The color

changes to red at a midpoint during the runtime. When the LED begins to

blink red, only a few minutes remain.

The exact point at which the LED turns red will vary with battery brand and

condition, temperature and power consumption. The LED is intended to sim-

ply catch your attention, not to be an exact indicator of remaining time.

NOTE: The LCD will also alert when the battery is critically low.

RF Link LED

When a valid RF signal from a transmitter is received, this LED will light up

blue.

Headphone Output

A 3.5 mm mini phone jack accommodates a standard mono or stereo type

3.5 mm plug. The unit will drive low or high impedance earphones. The jack is

also the receiver antenna input with the earphone cord acting as the antenna.

The cord length is not critical but must be at least 6 inches minimum.

USB Port

Firmware updates via Wireless Designer are made easy with the USB port in

the battery compartment.

www.lectrosonics.com 3

Installing the Battery

An attached sliding door makes battery installation easy. The

USB port is located in the battery compartment.

USB port

Slide the battery compartment door open, drop the battery in so that the con-

nectors match and slide the battery door closed.

Battery Charging

The receiver operates on a 3.6 V rechargeable battery that will provide about

six hours of operation per charge.

CAUTION: Use only Lectrosonics LB-50 supplied battery (p/n

40106-1).

The optional battery charger kit provides a folding NEMA 2-prong plug on

the charger, and will operate from 100-240 VAC sources. The LED glows red

during charging and turns green when the battery is fully charged. The kit

includes a Euro plug adapter and vehicle auxiliary power adapter cord.

Battery charger kit

P/N 40107

CAUTION: Use only Lectrosonics battery chargers, P/N 40107 or

CHSIFBRIB.

LECTROSONICS, INC.4

IFBR1B Functions

Frequency Selection

Press the FREQ button to select receiver frequency. Frequency is shown in

MHz. The UP and DOWN arrow buttons adjust the frequency in 25 0r 100 kHz

steps (VHF: 125 kHz steps). Simultaneous press of FREQ + UP or FREQ +

DOWN adjusts the frequency in 1 MHz steps.

NOTE: Holding down the UP or DOWN arrow button, as opposed to a

quick press, will scroll through the frequency steps at an accelerated

pace.

Preset Selection

Press the PRESET button to select preset frequencies for future use. Presets

are displayed as:

P on the left and the current preset number (1-10) on the right OR

If the current preset slot is empty, an E also appears on the right. Use the UP

and DOWN arrow buttons to navigate among any programmed presets, tuning

the receiver to each.

NOTE: If the preset number is blinking, the receiver IS NOT currently

tuned to that preset.

There are two options available for setting presets:

Choosing the preset slot ﬁrst:

1. Press PRESET to display the preset menu.

2. Use PRESET + UP and PRESET + DOWN to choose the desired slot.

When navigating among the preset slots in this way, all slots are acces-

sible, even the empty ones, and the receiver’s tuning is not affected.

www.lectrosonics.com 5

3. If the desired preset slot is occupied, you can reprogram by pressing

PRESET + DOWN to clear the slot.

4. Press FREQ to display the frequency, then use the UP and DOWN arrow

buttons adjust the frequency in 25 kHz steps.

5. Press PRESET again to return to the presets menu. You should see an E

next to the blinking preset number.

6. Press and hold PRESET + UP to program the preset. The E will disappear

and the preset number will stop blinking, indicating that this slot has now

been programmed with the current frequency.

Choosing the frequency ﬁrst:

1. Press FREQ to display the frequency, then use the UP and DOWN arrow

buttons adjust the frequency in 25 kHz steps.

2. Press PRESET to display the preset menu.

3. Use PRESET + UP and PRESET + DOWN to choose the desired slot.

When navigating among the preset slots in this way, all slots are acces-

sible, even the empty ones, and the receiver’s tuning is not affected.

4. If the desired preset slot is occupied, you can reprogram by pressing

PRESET + DOWN to clear the slot.

5. Press and hold PRESET + UP to program the preset. The E will disappear

and the preset number will stop blinking, indicating that this slot has now

been programmed with the current frequency.

Clear a Preset Selection

1. Press PRESET to display the preset menu.

2. Press either UP or DOWN arrow buttons (tuning as you scroll) or PRESET

+ UP and PRESET + DOWN (selecting the preset without tuning) to

select the preset number you wish to clear.

NOTE: If there is an E next to the preset number, the slot is already

clear.

3. Press and hold PRESET + DOWN to clear the slot. The E will appear and

the preset number will blink, indicating the slot is now empty.

Backlight Settings

Press the UP arrow button while powering on the receiver to display the back-

light time out menu. Use the UP and DOWN arrow buttons to scroll through

the options:

bL: Backlight always on; default setting

bL 30: Backlight times out after 30 seconds

bL 5: Backlight times out after 5 seconds

Press the FREQ button to exit and save settings.

LECTROSONICS, INC.6

LED On/Off

Press the UP arrow button while powering on the receiver. From the backlight

time out menu, press the FREQ button to access the LED on/off menu. Use

the UP and DOWN arrow buttons to scroll through the options.

Press the FREQ button to exit and save settings.

Locale Menu

On block 941 receivers ONLY, from the LED On/Off menu, press the FREQ

button to access the LOCALE menu. Use the UP and DOWN arrow buttons to

scroll through the options:

LC CA: Use for newer transmitters

LC --: Use for older transmitters

Press the FREQ button to exit and save settings.

Locking the Settings

To lock or unlock the IFBR1B settings, press and hold the UP and DOWN ar-

row buttons simultaneously until the countdown completes.

There are two options available for locked settings:

Locking Frequency: If frequency is displayed when the receiver is locked,

the frequency remains displayed, and the UP or DOWN arrow buttons will not

alter the frequency.

Locking Preset: If preset is displayed when the receiver is locked, preset

remains displayed, and the UP or DOWN arrow buttons can be used to scroll

through previously programmed presets; however, the presets may not be

programmed or deleted.

Firmware Update Instructions

Use the Lectrosonics wireless Designer program to install ﬁrmware updates.

Firmware update ﬁles and change notes are available from the Lectrosonics

website.

Remove the battery and connect the IFBR1B to your Windows or macOS

computer with a USB cable. The cable must have a micro-B male connector to

mate with the USB jack in the IFBR1B. When updating ﬁrmware, the IFBR1B

is powered by the USB cable. Use the “Firmware Update” Wizard in Wireless

Designer to open the ﬁrmware ﬁle and install the new ﬁrmware version.

www.lectrosonics.com 7

Accessories

27258

Wire belt clip.

40106-1

LB-50 3.6V lithium-ion battery pack

40107

Battery charger kit for Lectrosonics

LB-50 battery; includes charger, EU

plug adapter and vehicle auxiliary

power cord

CHSIFBR1B

IFBR1B Receiver battery charg-

ing station; any combination of four

batteries or IFBR1Bs; up to four

stations on one power supply or 16

batteries/IFBR1Bs on one power

supply

DCR5-9AU

Power supply for the CHSIFBR1B;

can power 4 CHSIFBR1B at once

IFBR1BBCSL

Spring loaded beltcip for IFBR1B

LIMITED ONE YEAR WARRANTY

The equipment is warranted for one year from date of purchase against defects in

materials or workmanship provided it was purchased from an authorized dealer. This

warranty does not cover equipment which has been abused or damaged by careless

handling or shipping. This warranty does not apply to used or demonstrator equipment.

Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any

defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot

correct the defect in your equipment, it will be replaced at no charge with a similar new

item. Lectrosonics, Inc. will pay for the cost of returning your equipment to you.

This warranty applies only to items returned to Lectrosonics, Inc. or an authorized

dealer, shipping costs prepaid, within one year from the date of purchase.

This Limited Warranty is governed by the laws of the State of New Mexico. It states the

entire liablility of Lectrosonics Inc. and the entire remedy of the purchaser for any

breach of warranty as outlined above. NEITHER LECTROSONICS, INC. NOR

ANYONE INVOLVED IN THE PRODUCTION OR DELIVERY OF THE EQUIPMENT

SHALL BE LIABLE FOR ANY INDIRECT, SPECIAL, PUNITIVE, CONSEQUENTIAL,

OR INCIDENTAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE

THIS EQUIPMENT EVEN IF LECTROSONICS, INC. HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL THE LIABILITY OF

LECTROSONICS, INC. EXCEED THE PURCHASE PRICE OF ANY DEFECTIVE

EQUIPMENT.

This warranty gives you specific legal rights. You may have additional legal rights which

vary from state to state.

Andere Handbücher für IFBR1B

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Lectrosonics Empfänger Handbücher

Lectrosonics

Lectrosonics UCR195D Bedienungsanleitung

Lectrosonics

Lectrosonics D4 Bedienungsanleitung

Lectrosonics

Lectrosonics Venue Bedienungsanleitung

Lectrosonics

Lectrosonics IFBR1a/E01 Bedienungsanleitung

Lectrosonics

Lectrosonics R1a Bedienungsanleitung

Lectrosonics

Lectrosonics UDR700 Bedienungsanleitung

Lectrosonics

Lectrosonics UCR401 Bedienungsanleitung

Lectrosonics

Lectrosonics CR187 Bedienungsanleitung

Lectrosonics

Lectrosonics LR Bedienungsanleitung

Lectrosonics

Lectrosonics SRc-941 Bedienungsanleitung

Lectrosonics

Lectrosonics UDR200C Bedienungsanleitung

Lectrosonics

Lectrosonics UCR401 Bedienungsanleitung

Lectrosonics

Lectrosonics UCR 195 Bedienungsanleitung

Lectrosonics

Lectrosonics IFBR1a-VHF Bedienungsanleitung

Lectrosonics

Lectrosonics Dante DSQD/AES3 Bedienungsanleitung

Lectrosonics

Lectrosonics UCR100 Bedienungsanleitung

Lectrosonics

Lectrosonics M2R Bedienungsanleitung

Lectrosonics

Lectrosonics UCR300 Bedienungsanleitung

Lectrosonics

Lectrosonics DSR4 Bedienungsanleitung

Lectrosonics

Lectrosonics SRa5P/E01 Bedienungsanleitung

Lectrosonics

Lectrosonics QUADUHFD Bedienungsanleitung

Lectrosonics

Lectrosonics SRb5P Bedienungsanleitung

Lectrosonics

Lectrosonics CR187 Bedienungsanleitung

Lectrosonics

Lectrosonics UCR201 Bedienungsanleitung

Beliebte Empfänger Handbücher anderer Marken

Garmin

Garmin GA 23 Bedienungsanleitung

Aiphone

Aiphone PS-12F Bedienungsanleitung

IMES

IMES TCS-01CA-PMI Bedienungsanleitung

BWI Eagle

BWI Eagle AIR-EAGLE SR Handbuch

AMIMON

AMIMON AMN12310 WHDI Bedienungsanleitung

Dual

Dual DMCPA79BT Betriebsanleitung

Sound Associates

Sound Associates SA652P Bedienungsanleitung

Sherwood

Sherwood NewCastle R-772 Bedienungsanleitung

Audio

Audio A10-RX Series Bedienungsanleitung

AllSee

AllSee PushShare PSRV1.1 Bedienungsanleitung

DEMAG

DEMAG DRC-DR D2 Bedienungsanleitung

Teleco

Teleco TVRCL868A02 Bedienungsanleitung

Bosch

Bosch RF3222E Bedienungsanleitung

Kramer

Kramer 631R Bedienungsanleitung

Xpress

Xpress xmc10 Bedienungsanleitung

JVC

JVC KD-MR1BTS Bedienungsanleitung

Omega Engineering

Omega Engineering UWTC-REC3 Bedienungsanleitung

e-survey

e-survey E300 Pro Bedienungsanleitung
