LELY JUNO 150

Feed Pusher

Installation and Operator Manual

D-I012.1109EN

English Original

D-I012.1109EN

innovators in agriculture

INTENTIONALLY BLANK

iii

D-I012.1109EN

innovators in agriculture

TRADEMARKS, COPYRIGHT AND

DISCLAIMER

Lely, Astronaut, Astri, Atlantis, Attis, AWS, C4C, Calm, Caltive,

Commodus, Compedes, Cosmix, Discovery, F4C, Fertiliner, Gravitor,

Grazeway, Hibiscus, Hubble, Juno, L4C, Lely Center, Lelywash, Lotus,

Luna, Nautilus, Orbiter, Qwes, SAE, Shuttle, Splendimo, Storm, T4C, Tigo,

Viseo, Voyager, Walkway and Welger are registered trademarks of the

Lely Group.

The right of exclusive use belongs to the companies of the Lely Group.

for information purposes only and does not constitute an offer for sale.

Certain products may not be available in individual countries and

products supplied may differ from those illustrated. No part of this

publication may be copied or published by means of printing,

photocopying, microfilm or any other process whatsoever without prior

permission in writing by Lely Holding S.à r.l. Although the contents of

this publication have been compiled with the greatest possible care, Lely

cannot accept liability for any damage that might arise from errors or

omissions in this publication.

The English language manual is the original manual. Translations into

other languages use the English language manual as the source

document. Lely accepts no liability for discrepancies between the

original English language manual and versions in other languages. If

there is a conflict over the content and accuracy of any translated

manual, the English language manual is the authority document.

Lely Industries N.V.

Weverskade 110

3147 PA Maassluis

the Netherlands

Phone: +31 (0)10 5996333

Fax: +31 (0)10 5996403

Website: www.lely.com

D-I012.1109EN

innovators in agriculture

INTENTIONALLY BLANK

D-I012.1109EN

innovators in agriculture

LIST OF INCLUDED AMENDMENTS

No: Issue Date

(yy/mm)

Chapter(s) Remarks

All Product name changed to "JUNO 150"

4, 6 Feed groups added

5 11/09

4, 6 Push power for feed groups added

4 10/07 All Full revision of the manual

- Software changes are incorporated

- Manual complies to the new documentation standard

2, 4, 5, 6, 8, 9 Rewritten: safety devices, component description

Added: new pictures (new position inductive sensor)

Added: updated software description (Modify Route)

Added: new procedure 'Adjust the inductive sensor'

Updated: alarm list

3 09/11 2, 4, 5, 7 Added: description, installation and maintenance procedures

with reference to the safety bar and the battery stop

2 09/03 2, 4, 8 Added: safety decals, installation safety decals, description feed

push power, procedure adjust the feed push power, description

new multiboard pcb

1 08/12 Initial issue

D-I012.1109EN

innovators in agriculture

INTENTIONALLY BLANK

vii

D-I012.1109EN

innovators in agriculture

PREFACE

Manual Contents

This manual contains the information necessary to install the JUNO 150

Feed Pusher. It also includes operating and maintenance information.

Study and understand this information thoroughly before you install,

operate or do maintenance work on the JUNO 150 Feed Pusher. Failure

to do so could result in personal injury or damage to equipment. Please

consult your local Lely service provider if you do not understand the

information in this manual, or if you need additional information.

All information in this manual has been compiled with care. Lely shall

not be liable for errors or faults in this manual. The recommendations

are meant to serve as guidelines. All instructions, pictures and

specifications in this manual are based on the latest information that

was available at the time of publication. Your JUNO 150 Feed Pusher

may comprise improvements, features or options that are not covered in

this manual.

Applicability

The table below shows the type numbers of JUNO 150 for which this

manual is applicable and the software version the procedures are based

on.

Model designation

Model Type number

Lely JUNO 150 Feed Pusher 5.4301.0000.1

Software version

The description, operation and procedures in this manual are based on

the software version:

•Multiboard pcb: JUN1.04R.bx

•E-Link: 1.07

Standard Torque Loading of Parts

All the nuts, bolts and screws used on the JUNO 150 Feed Pusher are

torque tightened to standard torque loadings applicable to the

construction materials used.

If a part has a non-standard torque loading, it is specified in the

applicable part of the manual.

viii

D-I012.1109EN

innovators in agriculture

Registration

The Type and Serial Number Plate is attached to the front side of the

JUNO 150 Feed Pusher. Always include the type and serial numbers of

JUNO 150 when you contact your local Lely service provider or order

spare parts.

Type and Serial Number Plate

We suggest you complete the table below with the type and serial

numbers of your JUNO 150. This makes sure you can easily find the

information.

Type number 5.4301.0000.1

Serial number

Maintenance Authorization

WARNING

Only technicians certified by Lely Industries are authorized to do

corrective maintenance on the JUNO 150.

If people who are not certified by Lely Industries do maintenance on

the JUNO 150, the warranty on the JUNO 150 becomes invalid.

Before a technician does maintenance on a JUNO 150, the owner must

examine the service pass of the technician and make sure the technician

is currently certified to do maintenance on the JUNO 150.

Technician Training

All the technicians certified by Lely Industries have completed an

approved training program, and passed written and practical

examinations during and at the end of the training program. The

examinations are done under supervision of a product specialist and

include troubleshooting and corrective maintenance of the JUNO 150.

There are five certification levels:

•Installation Technician (certification valid for two years)

•Service Engineer (certification valid for two years)

•Senior Service Engineer (certification valid for two years)

•Product Specialist (certification valid for one year)

•Master Product Specialist (certification valid for one year).

During training, a trainee is permitted to work for up to a maximum of

six months on a JUNO 150 in the presence of a certified technician.

D-I012.1109EN

innovators in agriculture

When the training program is completed successfully, Lely issues a

certificate and a service pass to the technician. The service pass contains

the following information:

•The name of the technician

•A photograph of the technician

•The certification number of the technician

•The date of expiry of the certification.

Contact Number Local Service Provider

We suggest you write the telephone number and email address of your

local service provider contact in the table below. This makes sure you can

easily find the information.

Telephone number

email address

D-I012.1109EN

innovators in agriculture

INTENTIONALLY BLANK
