Lenovo ThinkServer RS110 Bedienungsanleitung

ThinkServer RS110 Ty pe s 6435, 6436, 6437 and 6438

User Guide

ThinkServer RS110 Ty pe s 6435, 6436, 6437 and 6438

User Guide

Note: Before using this information and the product it supports, read the general information in “Notices,” on page 47 and the

Warranty and Support Information document on the ThinkServer Documentation DVD.

Second Edition (April 2009)

©Copyright Lenovo 2008, 2009.

Portions ©Copyright International Business Machines Corporation 2007, 2008.

LENOVO products, data, computer software, and services have been developed exclusively at private expense and

are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted rights

to use, reproduction and disclosure.

LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer software, or services are delivered

pursuant aGeneral Services Administration ″GSA″contract, use, reproduction, or disclosure is subject to restrictions

set forth in Contract No. GS-35F-05925.

Contents

Safety ............................v

Chapter 1. The ThinkServer RS110 Types 6435, 6436, 6437 and 6438 ....1

Related documentation ......................1

Notices and statements in this document................2

Features and specifications.....................3

What your server offers ......................5

Reliability, availability, and serviceability features .............6

EasyStartup ..........................7

Server controls, LEDs, and power ..................7

Front view ..........................7

Rear view ..........................8

Server power features......................9

Chapter 2. Installing optional devices................11

Server components .......................11

System-board internal connectors .................14

System-board switches and jumpers ................15

System-board external connectors.................16

System-board LEDs ......................17

System-board optional-device connectors ..............18

Installation guidelines ......................19

System reliability guidelines ...................20

Working inside the server with the power on .............21

Handling static-sensitive devices .................21

Removing the cover .......................21

Installing an adapter .......................22

Installing ahard disk drive.....................26

Installing asimple-swap Serial ATA hard disk drive...........26

Installing ahot-swap hard disk drive ................28

Installing anew CD or DVD drive ..................29

Installing an optional PCI-X riser-card assembly.............30

Installing amemory module ....................33

Completing the installation.....................35

Installing the cover ......................35

Connecting the cables .....................35

Updating the server configuration .................36

Chapter 3. Configuring the server .................37

Using the Configuration/Setup Utility program .............38

Starting the Configuration/Setup Utility program ............38

Configuration/Setup Utility menu choices ..............38

Passwords .........................42

Using the LSI Logic Configuration Utility program ............44

Starting the LSI Logic Configuration Utility program ..........44

Configuring the controller and devices ...............44

Using the baseboard management controller ..............45

Using the baseboard management controller utility programs .......45

Configuring the Gigabit Ethernet controllers ..............46

Appendix. Notices .......................47

Trademarks ..........................48

Important notes.........................48

©Lenovo 2008, 2009. Portions ©IBM Corp. 2007, 2008. iii

Waste electrical and electronic equipment (WEEE) notices .........49

Recycling statements for Japan ...................50

Battery return program ......................51

German Ordinance for Work gloss statement ..............52

Electronic emissions notices ....................52

Federal Communications Commission (FCC) statement .........52

Industry Canada Class Aemission compliance statement ........53

Avis de conformité àla réglementation d'Industrie Canada ........53

Australia and New Zealand Class Astatement ............53

United Kingdom telecommunications safety requirement.........53

European Union EMC Directive conformance statement .........53

German Class Acompliance statement ...............53

Japanese Voluntary Control Council for Interference (VCCI) statement ...54

Taiwanese Class Awarning statement ...............55

Lenovo product service information for Taiwan ............55

Chinese Class Awarning statement ................55

Korean Class Awarning statement ................55

Index ............................57

iv ThinkServer RS110 Types 6435, 6436, 6437 and 6438: User Guide

Safety

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de Segurança.

Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Lees voordat udit product installeert eerst de veiligheidsvoorschriften.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.

Avant d’installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise lesen.

Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.

Antes de instalar este produto, leia as Informações sobre Segurança.

©Lenovo 2008, 2009. Portions ©IBM Corp. 2007, 2008. v

Antes de instalar este producto, lea la información de seguridad.

Läs säkerhetsinformationen innan du installerar den här produkten.

Important:

Each caution and danger statement in this document is labeled with anumber. This

number is used to cross reference an English-language caution or danger

statement with translated versions of the caution or danger statement in the Safety

Information document.

For example, if acaution statement is labeled “Statement 1,” translations for that

caution statement are in the Safety Information document under “Statement 1.”

Be sure to read all caution and danger statements in this document before you

perform the procedures. Read any additional safety information that comes with the

server or optional device before you install the device.

vi ThinkServer RS110 Types 6435, 6436, 6437 and 6438: User Guide

Statement 1:

DANGER

Electrical current from power, telephone, and communication cables is

hazardous.

To avoid ashock hazard:

vDo not connect or disconnect any cables or perform installation,

maintenance, or reconfiguration of this product during an electrical

storm.

vConnect all power cords to aproperly wired and grounded electrical

outlet.

vConnect to properly wired outlets any equipment that will be attached to

this product.

vWhen possible, use one hand only to connect or disconnect signal

cables.

vNever turn on any equipment when there is evidence of fire, water, or

structural damage.

vDisconnect the attached power cords, telecommunications systems,

networks, and modems before you open the device covers, unless

instructed otherwise in the installation and configuration procedures.

vConnect and disconnect cables as described in the following table when

installing, moving, or opening covers on this product or attached

devices.

To Connect: To Disconnect:

1. Turn everything OFF.

2. First, attach all cables to devices.

3. Attach signal cables to connectors.

4. Attach power cords to outlet.

5. Turn device ON.

1. Turn everything OFF.

2. First, remove power cords from outlet.

3. Remove signal cables from connectors.

4. Remove all cables from devices.

Safety vii

Statement 2:

CAUTION:

When replacing the lithium battery, use only the battery recommended by the

manufacturer. If your system has amodule containing alithium battery,

replace it only with the same module type made by the same manufacturer.

The battery contains lithium and can explode if not properly used, handled, or

disposed of.

Do not:

vThrow or immerse into water

vHeat to more than 100°C (212°F)

vRepair or disassemble

Dispose of the battery as required by local ordinances or regulations.

viii ThinkServer RS110 Types 6435, 6436, 6437 and 6438: User Guide
