Owners Manual

VUP861NB(T)

V-UP861NB(T)

VTUP61NB(T)

P/No.: 38288I2002K

The LGE Customer Support Team can be contacted as follows:

For all Consumer enquiries

Line opening hours

Monday-Friday 09:00 to 20:00,

Saturday 09:00 to 18:00,

Sunday 10:00 to 16:00

Phone 0870 873 LGLG(5454)

(National call Rate)

www.lgelectronics.co.uk,

then select "CONTACT US"

0870 872 7337

E-Mail

Fax

6-7

3-4

8-13

9-10

8-9

10-11

*Apply only for VUP861NBT/

V-UP861NBT/VTUP61NBT

*Apply only for VUP861NBT/

V-UP861NBT/VTUP61NBT

VUP861NBT/V-UP861NBT/

VTUP61NBT

Holding dirt cup over trash recep-

tacle, press dirt cup door release

rod (C) on back of dirt cup to open

dirt cup door (D).

Empty dirt cup.

Close and snap dirt cup door shut.

Lifetime HEPA filter

If you wish to clean this filter, it may

be removed and cleaned.

3-4

3-6

3-3

How to empty

Disconnect cleaner from electrical

outlet. Do not use the cleaner

without dirt cup or filters in place.

Press dirt cup release button (B)

and pivot cup out.

3-5 3-7

3-8

Place bottom of dirt cup in first.

Pivot cup into cleaner body.

Press dirt cup firmly until you hear a

click to ensure that it is locked in

place.

3-2

When to empty

It is recommended that the dirt cup

be emptied before the dirt reaches

the fill line (A), or after every use if

preferred.

CAUTION: Very fine materials,

such as face powder or cornstarch,

may seal the filter and cause loss

of suction. When using the cleaner

for this type of dust, empty the cup

and clean the filters often.

Dirt cup

Press on the tab (A) located on the

side of the filter cover to remove.

Remove the HEPA filter (B) and

brush with the combination tool to

clean or tap side of filter against a

trash receptacle. Return the HEPA

filter into the filter cavity.

Align tab (C) on filter cover with slot

(D). Press cover closed until you

hear a snap.

Cleaning filters

Dirt cup filter

assembly

How to clean

Disconnect cleaner from electrical

outlet. Do not use cleaner without

dirt cup or filters in place.

3-9

Remove dirt cup as described in

Fig. 3-3.

Twist dirt cup lid (A) counterclock-

wise until arrows on lid and dirt cup

align. Remove lid with filter cartridge

from dirt cup.

Dirt and debris can then be cleaned

from the filter cartridge by brushing

with the cleaner’s combination tool.

3-10
