Lightolier Calculite ProSpec PA4H3870 Bedienungsanleitung

1 1/2"

54 1/4"

O.C.O.C.

7" 7"

O.C.

51 1/2" L X 10" W

28" L X 7" W Opening

13" 8"

Depth

8 3/4"

16"

Top View

Flanged Trimless

Calculit ®ProSp c®Lin ar Downlight PA4H3870

Pag 1 of 2 4 Light PAR38 MH S ri s A

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lig tolier a G nlyt Thomas Company www.lightoli r.com

631 Airport Road, Fall Riv r, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

W r s rv th right to chang d tails of d sign, mat rials and finish.

Features

1. Aperture Frame: Provid s cl an support for lamp hold rs and ov rlapping

flang or triml ss installation. Extrud d aluminum. Rigidly w ld d tog th r

on all corn rs.

2. Media Cartridge: Allows conv ni nt loading and r moval of up to two

acc ssori s (including lamp cov r glass; lamp cov r glass may b r plac d

with solid glass acc ssory). Easily install d and r mov d for lamping with a

simpl twisting motion. Construct d of di cast aluminum.

3. Cross Blade Louver: Extrud d aluminum. 1" d p, provid s additional

shi lding and can b asily r mov d.

4. Adjustable Ring: Allows 360° horizontal and 40° (on width) and 45° (on

diagonal) v rtical adjustm nt.

5. Tortiontite Spring: For asy installation of ap rtur fram .

6. Housing: Di -form d 22 ga. st l. Finish: Black.

7. Mounting Brackets: Adjustabl v rtically from outsid of housing.

8. T ermal Protector: M ts NEC, UL, and CSA r quir m nts.

9. Lamp older: Porc lain m dium bas d; nick l plat d scr w sh ll. 5KV puls

rat d, r wir d with #18 SF-1 l ads to ballast housing.

10. Junction Box: 14 ga. st l, 4" x 3 1/2" x 2" box. Allows insp ction from

b low.

11. Lamp and Accessory Support: .032" st l, flar d for asy ntry of M dia

Cartridg .

12. Lens Retaining Ring: .093" spring st l rod. Holds acc ssori s in plac .

13. Ballast Housing: Di -form d 18 ga. st l

Electrical

Electronic Ballast: Individual for ach lamp. High Pow r Factor. Input watts:

78; lin curr nt: .67 amps. Acc ssibl from b low.

UL list d for through branch circuit wiring with maximum of (8) no. 2 AWG 90° C.

Ceiling Cutoff: 29 1/16" L X 8 3/16" W

Ordering Information: PAR38 Series A

Cat. No. Lamp Ceiling Trim Aperture Finis

PA4H3870BL (4) 70W PAR38 MH Ov rlap Black with Whit Flang

PA4H3870WL (4) 70W PAR38 MH Ov rlap Whit with Whit Flang

PA4H3870BTL (4) 70W PAR38 MH Triml ss Black

PA4H3870WTL (4) 70W PAR38 MH Triml ss Whit

Finis

All paint d finish s ar powd r coat d bak d nam l.

Options & Accessories

Accessories: 4 3/4" dia. S ri s filt rs, l ns s, scr ns and louv rs. (2)

acc ssori s maximum, including lamp cov r glass. Lamp guard glass may b

r plac d with solid glass acc ssory.

Labels

UL/cUL (Suitabl for Damp Location), I.B.E.W.

PA4H3870BL = (Flang d) Black/Whit

PA4H3870WL = (Flang d) Whit

PA4H3870BTL = (Triml ss) Black

PA4H3870WTL = (Triml ss) Whit

0° Aiming Angle 30° Aiming Angle 30° Aiming Angle 45° Aiming Angle

PA4H3870

03/02

Lig ting Performance Data

LBeam length

WBeam width

CDistance to the center of the beam.

DDistance

AAiming angle

FC Footcandles

L and W are the outer points where the

candle power drops to 50% of the maximum.

FC are the initial footcandles at the center of

the beam.

Lamp data shown is typical, and is based on

bare lamp photometrics. Contact lamp

manufacturers for availability and

performance.

D FC LW DC FC LW DC FC LW DC FC LW

Lamps Beam Spread CBCP Rated

(To 50% CBCP Life (Hrs.

50000 7500

70W PAR38

(MC/MH SP 15˚

18000 7500

70W PAR38

(MC/MH FL 26˚

15’ 222 3.9’ 3.9’

20’ 125 5.3’ 5.3’

25’ 80 6.6’ 6.6’

30’ 56 7.9’ 7.9’

10’ 5.8’ 325 3.5’ 3.0’

15’ 8.7’ 144 5.3’ 4.6’

20’ 11.5’ 81 7.1’ 6.1’

25’ 14.4’ 52 8.8’ 7.6’ ’

5’ 8.7’ 250 5.6’ 2.6’

8’ 13.9’ 98 8.9’ 4.2’

11’ 19.1’ 52 12.2’ 5.8’

14’ 24.2’ 32 | 15.6’ 7.4’

88.0 276 4.3 3.0

12 12.0 123 6.4 4.5

16 16.0 69 8.6 6.0

20 20.0 44 10.7 7.4 9’

8’ 281 3.5’ 3.5’

12’ 125 5.3’ 5.3’

16’ 70 7.1’ 7.1’

20’ 45 8.9’ 8.9’

7’ 4.0’ 239 4.2’ 3.6’

10’ 5.8’ 117 6.0’ 5.1’

13’ 7.5’ 69 7.8’ 6.7’

16’ 9.2’ 46 | 9.6’ 8.2’

3’ 5.2’ 250 6.2’ 2.7’

4’ 6.9’ 141 8.3’ 3.5’

5’ 8.7’ 90| 10.4’ 4.4’

6’ 10.4’ 63 12.5’ 5.3’

5 5.0 255 4.7 3.1

7 7.0 130 6.5 4.4

9 9.0 79 8.4 5.6

11 11.0 53 10.3 6.9’

6’ 139 6.9’ 6.9’

8’ 78 9.2’ 9.2’

10’ 50 11.5’ 11.5’

12’ 35 13.9’ 13.9’

5’ 2.9’ 130 8.7’ 6.7’

7’ 4.0’ 66 12.1’ 9.3’

9’ 5.2’ 40 15.6’ 12.0’

11’ 6.4’ 27| 19.1’ 14.7’

2’ 3.5’ 156 * 4.6’

3’ 5.2’ 69 * 6.9’

4’ 6.9’ 39 * 9.2’

5’ 8.7’ 25 * 11.5’

3 3.0 196 10.4 4.9

55.0 71 17.3 8.2

7 7.0 36 24.2| 11.4

9 9.0 22 31.2 14.7

5000 7500

70W PAR38

(MC/MH WFL 60˚

Calculit ®ProSp c®Lin ar Downlight PA4H3870

Pag 2 of 2 4 Light PAR 38 MH S ri s A

Lig tolier a G nlyt Thomas Company www.lightoli r.com

631 Airport Road, Fall Riv r, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

W r s rv th right to chang d tails of d sign, mat rials and finish.

Job Information Type:

Data ar bas d on bar lamp photom trics. Dash d lin s

in b am spr ads indicat narrow ax s of oval shap d

b ams. FC is initial footcandl s at c nt r of b am. Land

War to th point that th candl pow r drops 50% of

maximum.
