TE Series

SELF-LUMINOUS EXIT

Page 1 of 2

Job Information Type:

Job Name:

Cat. No.:

Notes:

Features

Illumination: Illumination

of the exit stencil face is

accomplished with borosilicate

glass-sealed tubes internally

coated with zinc sulfide

phosphor and filled with

tritium gas. The sign is available

with either 10, 15, or 20 year

life.

Housing: Attractive ABS

flame-retardant housing

comes standard with a gray

frame. Black or white frames

are optional. Easy installation

for ceiling, wall, or flush

mount applications. Universal

mounting bracket is supplied

standard. Design incorporates

a high-impact acrylic lens,

polycarbonate lens option

available with field-selectable

chevrons. Designed to operate

in harsh, corrosive, humid, or

explosive environments.

Electronics: No external

power source required. No

maintenance costs. Illumination

level will exceed the .15 foot

Lambert minimum for the

entire service life. Suitable

for California low level

applications. Lifetime of 10, 15

or, 20 years.

Code Compliance

UL 924 listed. NFPA 101,

NEC (Article 500, Class I &

II conditions), BOCA, OSHA

and IBC illumination standards.

State of California. City of Los

Angeles. USNRC. Meets ICBO

and SBCCI requirements.

Warranty

10, 15, or 20 year warranty

provided, depending on the

product useful life version.

TERU20S

14.0"

(35.56 cm)

1.0"

(2.54 cm)

8.5"

(21.59 cm)

Double

Face

width is

2.25"

TE Series

SELF-LUMINOUS EXIT

Page 2 of 2

Philips Lightolier

e: [email protected]

t: (508) 679-8131

w: www.lightolier.com

TE Series September 23, 2011

Specifications are subject to change without notice.

Job Information Type:

Ordering Information

Series

TE = Self-Luminous

Tritium Exit

U= Universal

Arrow

R= Red

G= Green

Face Color

AF = Anodized, Brushed Aluminum Frame

BK = Black Plastic Frame

IF1 = Black Anodized Aluminum Vandal Resistant Frame1

IF5 = Brushed Aluminum Vandal Resistant Frame1

PW = Polycarbonate Lens

WH = White Plastic Frame

RM = Recessed Mount

Factory Installed Options

Note

1) Available on singe face exits only.

10 = 10 Year Life

15 = 15 Year Life

20 = 20 Year Life

Useful Life

S= Single

D= Double

# of Faces

Accessories (order as a separate item)

PKITTRB = 12” Pendant Kit, Black

PKITTRG = 12” Pendant Kit, Gray

PKITTRW = 12” Pendant Kit, White

PCS1 = Polycarbonate Vandal Shield
