BUSINESS SERIES

PRODUCT DATA

Model: SLM2008

8-Port 10/100/1000 Gigabit

Smart Switch with PD and

AC Power

Cost-Effective Gigabit switching

with entry-level management for

small business

New Linksys Business Series Smart Gigabit Ethernet Switches deliver cost-effective

switching solutions that are ideal for small businesses or workgroups within larger

organizations. These high-speed switches offer entry-level management without the

cost and complexity of a full Layer 2 managed switch.

The SLM2008 switch is ideal for conference rooms, labs, shipping/receiving

departments or in marketing, design or audio/visual workgroups. The eight

10/100/1000 Mbps (Gigabit Ethernet) ports enable companies to link to other Gigabit

devices on the network (servers, workstations and network storage) to quickly move

bandwidth-intensive files while still supporting 10/100 Mbps clients.

The SLM2008 supports the IEEE802.3af standard for Power over Ethernet (PoE) for

obtaining its power over a designated PD port or from an external AC power adapter. This

gives companies the option to install the switch in places where a power outlet may not be

present, such as in ceilings and in walls.

The SLM2008 is able to secure the network through IEEE 802.1Q VLANs and IEEE 802.1X port

authentication. For environments where IP multicast applications are used, the switch is

capable of limiting the traffic to only the ports that have requested that traffic with support

of IGMP Snooping. Additional QoS capabilities like IEEE 802.1p, DSCP, and 4 hardware queues

make it possible to maintain good quality for real-time applications like voice and video.

The SLM2008 offers an easy-to-use browser interface for the management and configuration

of the features, making it ideal for small businesses without an IT staff or that have minimal

technical expertise.

8 Gigabit Ethernet ports

ideal for small workgroups

moving large files

Can obtain power from

a standard 802.3af PoE

switch or from an external

AC power outlet

Entry-level management at

a cost-effective price point

Easy to use Web browser

interface make installation

quick and easy

SLM2008

PRODUCT DATA

BUSINESS SERIES

Features

8 10/100/1000 Gigabit

Ethernet ports

16 Gbps, non-blocking,

Store-and-Forward

switching capacity

Support IEEE 802.3af PoE-PD

(Powered Device) on port 1

as an optional power supply

Simplified QoS management

using 802.1p and DSCP

traffic prioritization

specifications

WebSmart management

enables configuration and

monitoring from a standard

web browser

802.1Q based VLANs enable

segmentation of networks

for improved performance

and security

Port level security via 802.1X

authentication

Increased bandwidth and

added link redundancy with

Link Aggregation Control

Protocol (LACP)

Storm Control on Multicast

and Broadcast traffic

Many to one Port Mirroring

for non-invasive monitoring

of switch traffic

Jumbo frame support (9KB)

Simple interface counters

support

•

8-Port 10/100/1000 Gigabit Smart Switch with PD

and AC Power

Specifications

Model SLM2008

Ports 8 RJ-45 Connectors for 10BASE-T/100BASE-TX/1000BASE-T

Auto MDI/MDI-X

Autonegotiate/Manual Setting

Buttons Reset

Cabling Type UTP CAT 5 or Better for 10BASE-T/100BASE-TX,

UTP CAT 5e or Better for 1000BASE-T

LEDs Link/Act, System

PoE

802.3af PoE-PD Compatible on Port 1

Supply System Power without an External Power Adapter

Performance

Switching Capacity 16 Gbps, Non-Blocking

Forwarding Rate 11.9 Mpps Wire-Speed Performance

Layer 2

MAC table size 8K

Number of VLANs 16 Active VLANs (4096 Range)

VLAN Port-Based and 802.1Q Tag-Based VLANs

HOL Blocking Head of Line Blocking Prevention

Management

Web User Interface Built-in Web UI for Easy Browser-Based Configuration

Firmware Upgrade Web Browser Upgrade (HTTP)

Port Mirroring Traffic on a Port can be Mirrored to Another Port for Analysis

with a Network Analyzer

Other Management

RADIUS

Port Mirroring

DHCP Client

PING

Security

IEEE 802.1x 802.1x - RADIUS Authentication. MD5 Encryption

Availability

Link Aggregation Link Aggregation using IEEE 802.3ad LACP

Up to 8 ports in up to 2 groups

Storm Control Broadcast and Multicast

Spanning Tree IEEE 802.1D Spanning Tree

IGMP Snooping IGMP (v1/v2) Snooping Limits Bandwidth-Intensive Video Traffic to

Only the Requestors. Supports 16 Multicast Groups

QoS

Priority levels 4 Hardware Queues

Scheduling Priority Queuing and Weighted Round Robin (WRR)

Class of Service Port-Based

802.1p VLAN Priority Based

IPv4/v6 IP DSCP Based

Standards

802.3 10BASE-T Ethernet, 802.3u 100BASE-TX Fast Ethernet,

802.3ab 1000BASE-T Gigabit Ethernet, 802.3z Gigabit Ethernet,

802.3x Flow Control, 802.3 ad LACP,802.3af PoE, 802.1D STP,

802.1Q/p VLAN, 802.1X Port Access Authentication

PRODUCT DATA

BUSINESS SERIES

Linksys

A Division of Cisco Systems, Inc.

121 Theory

Irvine, CA 92617 USA

E-mail: [email protected]

[email protected]

Web: www.linksys.com

Linksys products are available in more

than 50 countries, supported by

12 Linksys Regional Offices throughout

the world. For a complete list of local

Linksys Sales and Technical Support

contacts, visit our worldwide website

at www.linksys.com

Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or

and product names are trademarks or registered trademarks of their respective holders.

7050310NC-RR Model: SLM2008

Environmental

Dimensions 5.12" x 1.12" x 5.12" (130 x 28.5 x 130 mm)

Weight 0.91 lb (0.42 kg)

Power External AC Power Adapter, and IEEE 802.3af Compatible PoE-PD

Certification FCC Part15 Class B, CE Class A, UL, cUL, CE Mark, CB

Operating Temp. 32 to 104°F (0 to 40°C)

Storage Temp. -4 to 158°F (-20 to 70°C)

Operating Humidity 10% to 90%

Storage Humidity 10% to 95%

Package Contents

SLM2008 with 8 10/100/1000 Ports

AC Power Adapter with Power Cord

CD with User Guide in PDF Format

Online Registration Card

Minimum Requirements

Web-Based Utility: Web Browser–Microsoft Internet Explorer (Version 6.0 or Above), Firefox (Version 2.0.0.1

or Above)

CAT5 Ethernet Network Cable

Switch/Router with Power Over Ethernet (PoE) Support Or PoE Injector when used with PoE

Operating System: Windows®, XP or Above

Warranty

5 Years

•
