LIVARNO LUX HG00776A Technische Daten
LED SOLAR LIGHT
LED-SOLARLEUCHTE
Montage-, Bedienungs- und Sicherheitshinweise
IAN 315252
LED-AURINKOKEN-
NOVALAISIN
Asennus-, käyttö- ja turvallisuusohjeet
LED SOLAR LIGHT
Assembly, operating and safety instructions
LED-SOLCELLSLAMPA
Monterings-, bruks- och säkerhetsanvisningar
SOLARNA LAMPKA LEDOWA
Wskazówki montażu, obsługi i
bezpieczeństwa
GB Assembly, operating and safety instructions Page 5
FI Asennus-, käyttö- ja turvallisuusohjeet Sivu 18
SE Monterings-, bruks- och
säkerhetsanvisningar Sidan 30
PL Wskazówki montażu, obsługi i
bezpieczeństwa Strona 42
DE/AT/CH Montage-, Bedienungs- und
Sicherheitshinweise Seite 56
1
1
4
4
5
7
3
6
5
7
8
8
2
3
2
3
9
9
10
10
HG00776A/HG00776C
HG00776B/HG00776D
6
5GB
List of pictograms used..................................... Page 6
Introduction................................................................ Page 6
Proper use......................................................................... Page 6
Description of parts and features.................................... Page 7
Scope of delivery............................................................. Page 7
Technical data.................................................................. Page 7
Safety instructions................................................ Page 8
Product-specific safety instructions .................................. Page 9
Safety instructions for batteries/rechargeable
batteries............................................................................ Page 10
Functioning.................................................................. Page 11
Preparing for use .................................................. Page 11
Installing the product........................................................ Page 12
Setting up the product...................................................... Page 12
Replacing the rechargeable battery............................... Page 13
Charging the rechargeable battery................................ Page 13
Maintenance and care...................................... Page 14
Troubleshooting ..................................................... Page 14
Disposal......................................................................... Page 15
Warranty...................................................................... Page 16
6 GB
List of pictograms used
Splash-proof (IP44)
LED solar light
Introduction
We congratulate you on the purchase of your new product. You
have chosen a high quality product. The instructions for use are
part of the product. They contain important information concern-
ing safety, use and disposal. Before using the product, please fa-
miliarise yourself with all of the safety information and instructions
for use. Only use the product as described and for the specified
applications. If you pass the product on to anyone else, please
ensure that you also pass on all the documentation with it.
Proper use
The product is intended for outdoor use. The product is intended
for private use only. The product is not intended for commercial or
for use in other applications.
Not suitable for ordinary lighting in household
room illumination.
This product is suitable for extreme temperature up to -21°C.
7GB
Descri
ption of parts and feat
ures
1Solar cell
2Solar housing
3Recess
4Rechargeable battery
compartment cover
5Rechargeable battery
6Groove
7Rechargeable battery
compartment
8ON/OFF switch
9Housing
10 Ground spike
Scope of delivery
1 LED solar light
1 Ground spike
1 Rechargeable battery Ni-MH (nickel-metal hydride), AA/
1.2V/600 mAh (pre-installed)
1 Assembly, operating and safety instructions
Technical data
Operating voltage: 1.2V (direct current)
Rechargeable battery: 1x rechargeable battery Ni-MH (nickel-
metal hydride)/AA/1.2V/600mAh
LED: 1x LED (not replaceable)
Rated power LED: approx. 0.06W per LED
Protection type: IP44 (splash proof)
Solar cell: approx. 66 x 66mm
8 GB
Safety instructions
BEFORE USING THE PRODUCT, PLEASE FAMILIARISE
YOURSELF WITH ALL OF THE SAFETY INFORMATION AND
INSTRUCTIONS FOR USE! WHEN PASSING THIS PRODUCT
ON TO OTHERS, PLEASE ALSO INCLUDE ALL THE DOCUMENTS!
DANGER TO LIFE AND
RISK OF ACCIDENTS FOR INFANTS AND
CHILDREN! Never leave children alone and
unsupervised with the packaging material. There is always a
risk of suffocation if children play with the packaging material
Children often underestimate risks. Always keep children away
from the packaging material. This product is not a toy.
This product can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
product in a safe way and understand the hazards involved.
Children shall not play with the product. Cleaning and user
maintenance shall not be made by children without supervision.
Never leave children unattended with the packaging material.
It can cause suffocation. Children often underestimate dangers.
Always keep children away from the product.
This product is not a toy and should be kept out of the reach
of children. Children are not aware of the dangers associated
with handling electrical products.
Do not use the product if you detect any kind of damage. The
LED cannot be replaced.
The LED is not replaceable.
9GB
If the LED fails at the end of its life, the entire product must be
replaced.
CAUTION! DANGER OF EXPLOSION! Do
not operate the product in potentially explosive en-
vironments in which there are inflammable vapours,
gases or dusts.
Q
Product-specific safety instructions
Do not subject the product to strong vibrations or high
mechanical loads.
Make sure that the solar cell 1is free of dirt and free of snow
and ice in winter. Otherwise the performance of the solar cell
1will diminish.
Cold temperatures have a negative influence on the operating
life of the rechargeable battery. If the product is not going to
be used for a long time, e.g. in winter, it should be switched
off, taken up, cleaned and stored in a dry, warm room.
Never open up the solar housing 2! In the event of damage,
repairs or other problems with the product, please contact an
electrician. The LED is not replaceable.
CAUTION! DANGER OF EXPLOSION! Use
only rechargeable battery of the recommended
type. Other rechargeable or single-use batteries
could explode during charging.
RISK OF INJURY! Make sure that when the
housing 9is removed that the ground spike 10 is also removed
so they cannot pose any risk (e.g. stumbling over them).
Dispose of the product in the proper way if the product is
damaged.
10 GB
Safety instructions for batteries/
rechargeable batteries
DANGER TO LIFE! Keep batteries / rechargeable batteries
out of reach of children. If accidentally swallowed seek
immediate medical attention.
DANGER OF EXPLOSION! Never recharge
non-rechargeable batteries. Do not short-circuit bat-
teries/rechargeable batteries and/ or open them.
Overheating, fire or bursting can be the result.
Never throw batteries/rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries / rechargeable
batteries.
Risk of leakage of batteries/rechargeable batteries
Avoid extreme environmental conditions and temperatures,
which could affect batteries/rechargeable batteries, e.g.
radiators/ direct sunlight.
If batteries/rechargeable batteries have leaked, avoid contact
with skin, eyes and mucous membranes with the chemicals!
Flush immediately the affected areas with fresh water and seek
medical attention!
WEAR PROTECTIVE GLOVES! Leaked or dam-
aged batteries/rechargeable batteries can cause
burns on contact with the skin. Wear suitable pro-
tective gloves at all times if such an event occurs.
In the event of a leakage of batteries/ rechargeable batteries,
immediately remove them from the product to prevent damage.
Remove batteries/rechargeable batteries if the product will
not be used for a longer period.
