Lockly DEADBOLT EDITION 7S Bedienungsanleitung

INSTALLATION MANUAL

DEADBOLT EDITION

MODEL 7S

N4X

Battery Cover

Interior Assembly

Mounting

Plate

Adhesive

Deadbolt

Strike Plate KA4*20MM Screw

Dust Box

PM4*12MM

Screw

Exterior

PM5×60mm Screw

1-3/8"~2"

(35~50mm)

Adhesive

Keys

Exterior Assembly

Adhesive TAPE

Lockly®can be fitted for both right swing doors and left swing doors.

INSTALLATION OVERVIEW & PARTS LIST

SCAN & SAVE

LOCK SERIAL

ACT IVATION CODE

PGDXXXXXXXXX

XXXXXXXX

1.1 To complete installation, you would need the following:

1.2 Prepare door and remove existing lock. If necessary, use provided

Installation Template to prepare door.

Phillips Screwdriver

Flathead Screwdriver

Ruler

1-⅜" (35mm)

to 2" (50mm)

1" (25mm)

2-⅜" (60mm)

or 2-¾" (70mm)

2-⅛" (54mm)

STEP 1. PREPARE DOOR FOR INSTALLATION

2.1 Deadbolt slit hole must be aligned to the center of the door hole. If not

adjust as shown below:

2.1.1 Wear gloves during adjustment

to prevent pinching your hands

II. Hold the metal plate (c) and

twist the deadbolt body (d)

clockwise till it snaps to 2-3/8"

III. To return to default status,

while the deadbolt (b) is

extended, hold the metal

plate (c) and twist the dead-

bolt body (d) counter-clock-

wise till it snaps to 2-3/4"

(b) (a)

（c）（d）

I. Push the crank (a) to extend

the deadbolt (b)

Deadbolt at 2-3/4" (70mm)

(default shipping status)

STEP 2. ADJUST DEADBOLT AND INSTALL

2.2 Extend the deadbolt by inserting a

flat head screwdriver on the slit hole or

by pushing the crank towards the metal

face plate.

2.3 Insert the Deadbolt to the edge

door hole, make sure that its right side

up and the slit hole is in vertical position,

then secure with 2 screws (K)

K(2X)

STEP 2. ADJUST DEADBOLT AND INSTALL

3.2 Before placing the exterior assembly

on the door, make sure the torque blade is

in vertical position and the deadbolt is

extended.

Vertical

When installing the exterior assembly,

make sure the deadbolt is fully

extended and the slit hole is vertically

positioned on the bottom, the torque

blade should be inserted in a vertical

position.

Peel paper off the

Adhesive tape

3.3 Place the exterior assembly on the door

by inserting the torque blade on a vertical

position to the deadbolt slit hole and guide

the cable under the deadbolt. Secure with

the adhesive strips.

EXTERIOR VIEW

(1)

3.1 To secure Exterior Assembly of lock, peel the cover off the adhesive strips

STEP 3. INSTALLING THE EXTERIOR ASSEMBLY

G (2X)

4.1: Check the mounting plate

alignment to your door hole before

you peel of the cover off the

adhesive strip.

4.3: Without using any tools, insert 2

screws (G) on the side of the torque

blade. By using hand carefully, turn

the screws clockwise to catch the

thread, then counter clockwise to

make sure they are not cross threaded

and turns smoothly. Make five turns

before using a screw driver to tighten

the screws until the mounting plate is

securely placed to the door.

4.4: After securing the mounting

plate, use the physical key and try to

unlock/lock to check if the deadbolt

is moving and not stuck. Do not

forget to take out the key before

proceeding to next steps.

4.2: Place the mounting plate on the

interior side of the door. Guide the cable

to the opening ear on the side of mounting

plate and make sure the torque blade is at

the center of the mounting plate.

STEP 4. INSTALLING THE INTERIOR ASSEMBLY (F)

NOTE: In case you need to reinstall the

lock and disconnect the cable, make

sure to press the snap to release the

plug before carefully pulling it out. Do

not force to pull the plug as this may

result to lose connection and damage

the lock.

5.1 Plug the cable that is coming through the door into the Interior lock. Make sure you

match the direction of the plug correctly and matching the red side of the plug with the

red side on the lock. Secure the connection by ensuring the snap is inserted tightly.

STEP 5. INSTALLING THE INTERIOR ASSEMBLY (F)

I（2X）

RESET

PROGRAM

RESET

PROGRAM

STEP 5. INSTALLING THE INTERIOR ASSEMBLY (F)

5.2 Before placing the interior

assembly to the mounting plate,

ensure the thumb turn is vertical.

5.3 Place the interior assembly against the

mounting plate and make sure the torque

blade is inserted to the thumb turn shaft.

5.4 Secure the interior assembly with 2 screws (I)

Torque Blade Thumb turn shaft

Push the thumb turn shaft into the

torque blade.

MAKE SURE IT IS IN THE

VERTICAL POSITION

First install 3 of the 4 batteries. Before installing the

last battery, press and hold the PROGRAM button

while installing the last battery until you hear

a beep from Lockly

Lockly

will then perform a self check and the

keypad screen will start to initiate. This self check

will automatically determine and set your door lock

to a left open or right open door.

RESET

PROGRAM

After the lock finished the self-check, do the 2-steps below to ensure your lock is properly

installed:

1. Manually lock and unlock your door by

using the thumb turn and the key to

make sure the deadbolt moves smoothly.

If you feel that there is a tight tension

while you are turning, it means that the

lock may have not been installed

straight. Go back to Step 2 and re-install

the lock.

IMPORTANT: If your lock is not properly

installed, it will open and close repeatedly

at times and/or it will reduce battery life.

2. Swipe your hand across the touchscreen

keypad, the lock will close. If the deadbolt

bounces and unlocks automatically,it means

that your lock was installed incorrectly. Go

back Step 2 to make sure your lock was

installed with the (a) deadbolt extended and

(b) the torque blade was inserted vertically

while the deadbolt was extended.

After you checked that the lock manually lock and unlock properly and deadbolt moves

smoothly, install the Battery Cover (H) and secure with screw.

STEP 6. INSTALLING BATTERIES
