G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse FAQs 1
G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse
INDEX
GETTING STARTED
●User guide
○Package contents
○Setup instructions
○Mouse features
○Onboard profiles by default
○Profile, DPI selection and DPI shift
○Battery life
SPECIFICATIONS
●Product information
●Product dimensions
●Mouse specifications
●Receiver specifications
FAQs
●Scrolling on my G502 X is erratic
●My mouse does not hold a charge
●My G502 X Plus and LIGHTSPEED mouse shows incorrect LED status while the system is
in sleep mode
G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse FAQs 2
●I have paired my G502 X Plus/LIGHTSPEED mouse to my keyboard but it reconnects to
the original receiver while charging
●My G502 X does not show up on G HUB automatically when connected via USB
●G HUB indicates my G502 X Plus or LIGHTSPEED is fully charged, but the LED is breathing
green
●How do I know when to charge my G502 X Plus and LIGHTSPEED?
●What does the G502 X wheel mode toggle button do?
●Why are the button clicks loud on my G502 X?
●Onboard Memory Mode DPI profiles on G502 X
●Change the DPI button position on G502 X
●G-Keys in Logitech G HUB
●Using the Device Pairing Tool in G HUB
●G HUB freezes while loading and logo animation loops
●G502 - Troubleshooting - Connection Issue: Intermittently working
●G502 - Troubleshooting - Connection Issue: Mouse not detected/recognized by
computer
●G502 - Troubleshooting - Connection Issue: Mouse auto disconnects from computer
●Logitech G HUB - FAQs
○About Logitech G Hub
WARRANTY
●Hardware warranty
CONTACT US
●Logitech Support
DOWNLOAD
●G Hub
G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse FAQs 3
GETTING STARTED
USER GUIDE
Package contents
G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse FAQs 4
Setup instructions
1. Orientate the DPI Shift to fit your
preference or replace it by the
button cover to extend the grip
surface.
2. The receiver can be stored in
the mouse behind the door
when on the go.
3. The LIGHTSPEED Wireless USB-A
receiver is below the mouse in
the product tray.
Plug the USB-A cable connector
into your PC and the USB-C
connector into the receiver
extension adapter. Plug the
USB-A receiver into the adapter.
●The LIGHTSPEED Wireless receiver can also be plugged directly into your PC, but
using the cable and extension adapter will ensure a better connection and
easy access to the cable when you need to charge your mouse.
G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse FAQs 5
4. Slide the power button up to turn on your
mouse.
5. Download Logitech G HUB gaming software
to personalize your G502 X mouse. Fine tune
to suit your playstyle, personality and each of
your games, assign commands to any of the
13 controls, and more.
6. To charge your mouse,
disconnect the cable from the
adapter and plug it into the
USB-C port located at the front of
the mouse. Your mouse will
operate in data‑over-cable
mode whenever it is plugged in
directly to a PC. Charging from
0% to 100% takes around 2 hours
when plugged into a USB port.
Compatible with Powerplay
wireless charging system.
G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse FAQs 6
Tips:
●Keep the mouse and receiver at least 2 meters away from wireless routers or other 2.4
GHz wireless devices to minimize environmental noise.
●G502 X PLUS and G502 X LIGHTSPEED have a wireless range of up to 10 meters. To
ensure optimal performance in noisy wireless environments, and to keep the charging
cable easily accessible, it is recommended to keep the receiver within 20 cm of the
mouse.
G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse FAQs 7
Mouse features
1. Left click (Button G1)
2. Right click (Button G2)
3. DPI up (Button G8)
4. Scroll up
5. Scroll left (Wheel tilt left)
6. Scroll right (Wheel tilt
right)
7. Middle click (Button G3)
8. Scroll down
9. DPI Shift (Button G6)
10. Wheel mode toggle
button
(not programmable)
11. DPI down (Button G7)
12. Profile cycling (Button G9)
13. Forward (Button G5)
14. Back (Button G4)
15. On / Off switch
(bottom of mouse, not
programmable)
16. POWERPLAY™ Aperture
door
wireless receiver storage
G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse FAQs 8
Onboard profiles by default
Up to 5 Onboard memory profiles can be unlocked and customized in G HUB.
SETTINGS
MAIN PROFILE
GAMING
SECONDARY PROFILE
PRODUCTIVITY
SECONDARY PROFILE
G-SHIFTED
(G-SHIFT on DPI Shift
button)
Report Rate
1 ms
2 ms
No changes
DPI
800, 1200, 1600, 2400,
3200
800, 1200, 1600, 2400,
3200
No changes
DPI steps colors
1: White 2: Orange 3:
Teal 4: Yellow 5:
Magenta
1: White 2: Orange 3:
Teal 4: Yellow 5:
Magenta
Default DPI
1600
1600
No changes
G6 button
DPI Shift to 800
G-Shift
(see right column)
No changes
PROGRAMMABLE CONTROLS
Left Main Button
Left click -
system/application
Left click -
system/application
No changes
Right Main Button
Right click -
system/application
Right click -
system/application
No changes
Middle Wheel Button
Wheel click/press -
system/application
Wheel click/press -
system/application
Ctrl-T - opening a
new tab in browser
G4 Button
Side button -
system/application
(commonly used
backwards)
Side button -
system/application
(commonly used
backwards)
No changes
G5 Button
Side button -
system/application
(commonly used
backwards)
Side button -
system/application
(commonly used
backwards)
No changes
G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse FAQs 9
PROGRAMMABLE BUTTONS
G7 Button
DPI Down
DPI Down
Ctrl-X
G8 Button
DPI Up
DPI Up
Ctrl-Z
G9 Button
Profile cycle
Profile cycle
Ctrl-0
Scroll right (wheel tilt
right)
Tilt Right -
system/application
Tilt Right -
system/application
Ctrl-Tab
Scroll left (wheel tilt
left)
Tilt Left -
system/application
Tilt Left -
system/application
Ctrl-Shift-Tab
Wheel Scroll Up
Scroll Up -
system/application
Scroll Up -
system/application
Volume Up
Wheel Scroll Down
Scroll Down -
system/application
Scroll Down -
system/application
Volume Down
Profile, DPI selection and DPI shift
When the DPI Shift button is pressed: the mouse displays the color associated with the DPI
shift speed, when released the mouse displays the DPI setting color that was used prior to this
action.
DPI and profile selection are communicated using lighting on the top and the rear of the
mouse. DPI change is expressed by different steady colors, while profile change is displayed
by different blinking colors.
G502 X PLUS | G502 X LIGHTSPEED Gaming Mouse FAQs 10
Battery life
G502 X PLUS and G502 X LIGHTSPEED have a rechargeable 500 mAh LiPol battery which
provides up to 140 h of continuous motion for G502 X and up to 120 h for G502 X PLUS.1
Charging Status:
When the charging cable is plugged in the device:
●Steady green = charge completed (100%) when device is ON or OFF
●Breathing green = charging (0 - 99%)
Battery level:
When turning the device ON:
●Steady green = good (31% - 100%)
●Steady red = low (16 – 30%)
●Slow blink red = critical (< 16%)
Tips:
●Charge level, power draw, and estimated remaining battery life can be checked in
Logitech G HUB.
1Battery life and capacity may vary with age and use.
Rechargeable batteries have a limited number of charge cycles.
