BEFORE USE ....

Thank you for choosing M-System. Before use, please check

contents of the package you received as outlined below.

If you have any problems or questions with the product,

please contact M-System’s Sales Ofﬁce or representatives.

■PACKAGE INCLUDES:

Totalized pulse input module .............................................(1)

■MODEL NO.

Conﬁrm Model No. marking on the product to be exactly

what you ordered.

■INSTRUCTION MANUAL

This manual describes necessary points of caution when

you use this product, including installation, connection and

basic maintenance procedures.

POINTS OF CAUTION

■CONFORMITY WITH EU DIRECTIVES

• The equipment must be mounted inside the instrument

panel of a metal enclosure.

• The actual installation environments such as panel con-

ﬁgurations, connected devices, connected wires, may af-

fect the protection level of this unit when it is integrated

in a panel system. The user may have to review the CE

requirements in regard to the whole system and employ

additional protective measures to ensure the CE conform-

ity.

■HOT INSERTION/REMOVAL OF MODULES

• Removing or replacing modules does not affect other mod-

ules on the same backplane. It is possible to replace them

without removing the power supply. However, replacing

multiple modules at once may greatly change line voltage

levels. We recommend that you replace them one by one.

■GENERAL PRECAUTIONS

• DO NOT set the switches while the power is supplied.

The switches are used only for maintenance without the

power.

■ENVIRONMENT

• Indoor use.

• When heavy dust or metal particles are present in the

air, install the unit inside proper housing with sufﬁcient

ventilation.

• Do not install the unit where it is subjected to continuous

vibration. Do not subject the unit to physical impact.

• Environmental temperature must be within -10 to +55°C

(14 to 131°F) with relative humidity within 30 to 90% RH

in order to ensure adequate life span and operation.

■WIRING

• Do not install cables close to noise sources (relay drive

cable, high frequency line, etc.).

• Do not bind these cables together with those in which

noises are present. Do not install them in the same duct.

■AND ....

• The unit is designed to function as soon as power is sup-

plied, however, a warm up for 10 minutes is required for

satisfying complete performance described in the data

sheet.

INSTALLATION

Use the Installation Base (model: R5-BS).

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN

Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp

EM-7573 Rev.1 P. 1 / 3

INSTRUCTION MANUAL

TOTALIZED PULSE INPUT MODULE

(screw terminal block; Pi 2 points) MODEL R5T-PA2

COMPONENT IDENTIFICATION

Counter

Reset

2345678

Counter Reset SW is normally OFF during operation.

RUN

Status Indicator LED

RUN LED

■

SIDE VIEW ■FRONT VIEW

Note 1: Counter Reset SW is normally OFF during operation.

Note 2: Be sure to set unused SW1 through 7 to OFF.

■STATUS INDICATOR LED

RUN indicator: Bi-color (red/green) LED;

Red when the bus A operates normally;

Green when the bus B operates normally;

Amber when both buses operate normally.

Input status indicator: Red LED; turns on with the inputs supplied.

PC CONFIGURATOR

With conﬁgurator software, settings shown below are available.

Refer to the software manual of R5CON for detailed operation.

■CHANNEL INDIVIDUAL SETTING

PARAMETER AVAILABLE RANGE DEFAULT SETTING

Span 100 to 60000 10000

R5T-PA2

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN

Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp

EM-7573 Rev.1 P. 2 / 3

TERMINAL CONNECTIONS

Connect the unit as in the diagram below.

■EXTERNAL DIMENSIONS unit: mm (inch)

38.5 (1.52) 98.5 (3.88)

TERMINAL COVER

6–M3.5

TERMINAL

SCREWS

8.2 (.32)

7.2 (.28)

LOCKING CLAMP

90 (3.54) 5.6

(.22)

18 (.71)

POSITIONING GUIDE

■CONNECTION DIAGRAM

BUS CONNECTOR

INTERNAL POWER

*For dual redundant communication.

Pi 1

COM1(–)

Pi 2

COM2(–)

INTERNAL BUS A

INTERNAL BUS B*

WIRING INSTRUCTIONS

■SCREW TERMINAL

Torque: 0.8 N·m

COUNTER RESET

1) Remove Network Module or its cables and interrupt com-

munication with other devices.

2) Turn ON the Counter Reset SW (SW8) on R5T-PA2 mod-

ule.

3) Return the module to the base and turn the power supply

on.

4) Red RUN LED turns on and the module starts resetting

its counter. When the resetting is complete, the LED

turns to green. DO NOT remove the power while the red

LED is on.

5) After the green LED is conﬁrmed, turn the power supply

off.

6) Turn OFF the Counter Reset SW (SW8).

7) Return the Network module onto the base and turn the

power supply on.

Note: Counter Reset SW must be turned OFF after this pro-

cedure because the module does not start counting with

ON state.

R5T-PA2

5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN

Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp

EM-7573 Rev.1 P. 3 / 3
