FROST FREE REFRIGERATOR

INSTRUCTION MANUAL

Model No.: MCBR1010W

MCBR1010S

To ensure proper use of this appliance and your safety, please read the

following instructions completely before operating this appliance.

TABLE OF CONTENTS

NAMES OF THE PARTS……………………………………………………… 2

SPECIFICATIONS…………………………………………………………….. 3

IMPORTANT SAFETY INSTRUCTIONS…………………………………… 4

INSTALLATION INSTRUCTION

BEFORE USING YOUR REFRIGERATOR……………………..…… 4

INSTALLING YOUR REFRIGERATOR ……………………………… 4

ELECTRICAL CONNECTION………………………………………… 5

OPERATING YOUR REFRIGERATOR

TEMPERATURE CONTROL………………………………………….. 6

CHANGING THE LIGHT BULB….…………………………….……… 6

OPERATING FREEZER COMPARTMENT

TEMPERATURE CONTROL………………………………………….. 7

ICE TRAY………………………………………………………………… 7

THE FREEZER COMPARTMENT……………………………………. 7

CARE AND MAINTENANCE

CLEANING YOUR REFRIGERATOR………………………………… 8

VACATION TIME………………………………………………………. 8

MOVING YOUR REFRIGERATOR…………………………………… 8

ENERGY SAVING TIPS………………………………………………. 8

TROUBLESHOOTING GUIDE………………………………………………. 9 - 10

REFRIGERATOR WARRANTY……………………….……………………… 11

NAMES OF THE PARTS

MODEL NO. MCBR1010W / MCBR1010S

1.FREEZER BIN 7.LAMP COVER

2.REFRIGERATOR BIN 8.REFRIGERATOR SHELF

3.CAN DISPENSER 9.CRISPER COVER

4.FREEZER SHELF 10.CRISPER

5.FREEZER TEMPERATURE CONTROL KNOB

11.LEVELING LEG

REFRIGERATOR TEMPERATURE CONTROL KNOB





WARNING



: Never touch the interior of the Freezer Chamber or frozen foods in the

compartment with wet hands as this could result in frost bite.

SPECIFICATIONS – Model #MCBR1010W

IMPORTANT SAFETY INSTRUCTIONS





WARNING





To reduce the risk of fire, electrical shock,

or injury when using your refrigerator,

Electrical Connection

This refrigerator should be properly grounded for your safety. The power cord of this refrigerator is

equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the

possibility of electrical shock.

Do not, under any circumstances, cut or remove the third ground prong from the power cord supplied.

This refrigerator requires a standard 115/120 Volt A.C. ~/60Hz electrical outlet with three-prong

ground.

This refrigerator is not designed to be used with an inverter.

The cord should be secured behind the refrigerator and not left exposed or dangling to prevent

accidental injury.

Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly and pull straight

out from the receptacle.

Do not use an extension cord with this appliance. If the power cord is too short, have a qualified

electrician or service technician install an outlet near the appliance. Use of an extension cord can

negatively affect the performance of the unit.

If any problems with the appliance persist, please contact our Customer Service Dept. to consult with

a representative at 888 775-0202 or visit our website to request warranty service at www.magicchef-

ewave.com.





WARNING





OPERATING YOUR REFRIGERATOR

Temperature Control

•Your refrigerator has one control for regulating the

temperature. The temperature control is located on the

top left hand corner of the refrigerator compartment.

•The first time you turn the unit on, adjust the temperature

control knob to “MAX” and run for at least 2 hours before

putting foods inside. This will ensure the cabinet is

thoroughly chilled before food is put in.

•The range of the REFRIGERATOR temperature control is

from position "MIN" the warmest to "MAX" the coldest.

Adjust the temperature control to the setting that best

suits your needs. The setting of “MED” should be

appropriate for home or office refrigerator use.

•NOTE;

•If the unit is unplugged, loses power; you must wait 3 to 5 minutes before restarting the

unit. If you attempt to restart before this time delay, the refrigerator will not start.

•Large amounts of food will lower the cooling efficiency of the appliance.

•Do not place the foods on the air outlet, and leave spaces for airflow.

•If you choose to change the thermostat setting, adjust thermostat control by one

increment at a time. Allow several hours for temperature to stabilize between

adjustments.

•Adjusting the temperature control in the refrigerator compartment will affect the

temperature in both the refrigerator and the freezer compartment.

Changing The Light Bulb

Before removing the light bulb, turn off the refrigerator first

and then unplug the unit from the wall outlet. Failure to do so

could result in electrical shock or personal injury.

•Use Phillips screwdriver to take out screw.

•Remove the light cover by pulling downwards gently

•Unscrew the bulb

•Replace with a 15 watt-refrigerator bulb that is the same

shape and size.

•Replace the light bulb cover and tighten screw.

OPERATING FREEZER COMPARTMENT

Temperature Control

•Your refrigerator has one control for regulating the

temperature in the freezer compartment. The temperature

control is located on the center of the freezer compartment’s

interior back panel.

•The first time you turn the unit on, adjust the temperature

control knob to “MAX” and run for at least 2 hours before

putting foods inside. This will ensure the cabinet is

thoroughly chilled before food is put in.

•The range of the FREEZER temperature control is from

position "MIN" the warmest to "MAX" the coldest. Adjust the

temperature control to the setting that best suits your needs.

Ice Tray

It is for making ice, pour cool water into ice tray up to its 4/5

volume, place it in ice making chamber for two hours and the ice

can be made automatically. When you want to take ice cubes,

please twist the ice tray, and the ice cubes are separated from

the ice tray. But do not bend it, otherwise it will crack. If you want

to shorten the time of making ice, you can set the temperature

control knob at “MAX”.

Notes:

Do not store can foods or food stored in glass containers in the

freezer compartment.

The Freezer Compartment

•This compartment is designed for the long-term storage of frozen food. Storage time period is up

to three months.

•The storage life of frozen foods varies and the recommended storage time should not be

exceeded.

•Place frozen food into the freezer as quickly as possible after purchase. If there are instructions

on the packet, carefully follow these instructions regarding storage times.

CARE AND MAINTENANCE

Cleaning Your Refrigerator

•Upon installation of your new appliance, it is recommended that it be cleaned thoroughly.

•Turn off the refrigerator first and then unplug the unit from the wall outlet.

•Remove all food content.

•Wash the inside with a damp warm cloth soaked in lukewarm water and baking soda solution.

The solution should569( )0.89126(f)-11.15.78252( )0.89126(u)-10.2657(n)196 Tf-225.24 -12.961.78252(56p( )0.89126(f)-11.150.2657(u)1.78252(l)-0 Td[(o)1.78252(m)-1.78252(r)-4.34894( )0.131.639(s)-6.0241(o)1.78252(d)1.7569(a54(2.78252(d).78252( )-131.4894( )6.0241(o)-10.2657(l)5.1299(u)1.78252(t)-11569(a)-10.2657(l)5oq(f)-11.15)1.78252(t)0.89126(e)1.78252(r)-4.34894( )0.89126(n)-131.639(a)-10.2657(n)189126(n)-)1.78252( )-143.687(bR16 9.96 Tf4.56 0 Td[( )-107149(R)-0.89126(e)1.78326(m)-22.422(o)1.78326(v)6.0241(e)1.B)1569( )078252(t)0.89126(i)-6.91536(o)1.89126(f)-11.1569( )0e78252( )-131.4894( )5.13284(r)-4.34894(s89126(i)-6-22.4227( )-131.639(w-131.639(wp78252(t)-11569(a)-10.2657(l)5.96 Tf-229.89126(f)-11.1569(o)d(f)-11.150.2657(u)1-4.34894(s)-6.0241(t)0.89126( )g)11.1569(a)19126(9 )6.0241(o)--22.4227( )-131.639(w(.78252(d)1.78252( )-e)1.78252(t96 Tf-225)-143.687(b)18252(n)-10.2657(t).78252( )-11.1569(t)0.2657(u)1.78252(l)-6.91536(d))189126(n)--4.34894(s89126(i)-6-22.4227( )-1569(a54333 0 4(t)-11.1569( )p78252(t)-11569(a)-10..2657(n)1.731.639(w-131.61(m)0.89126(f)-11.1569(r)7.69778(o)1.78252(m)-2)-143.687(b-11.1569(r)7.69778(o)96 Tf-4.56.78252(d)1.78252(a)1.78252( )-131.126(n)-)1.78252( -4.34894( )0.892731(a)1.78252(n)c0.89126(i)58252( )-11.1569(t).89126( )0.89153( )].2 -12.72 Td(·)Tj/R16 9.88589Tf4.56 0 Td[( )-1071385.130.89126(e)1.78326(m)-22.422(o)1.78326(v)6.0241(e)1..78326(l)5.13284(u)1.78252(t)0.89126(i)-6.78252(n)1.89126(f)-t9126(i)-6.91536(o)1)58252( )-0.89126(h)1.1.78252(r)-4.34894( )0..78252(f)-11.1569(r)-4.34894(i)5.13284(g)1.78252(e)1.78252(r)-4.34894(a)1.78252(t)0.89126(o)1.78252(r)-4.34894( )0.88.99609 0.89126(b)1.78252(e)1o19126(9 ))-6.0241(t)0.89126( )1.78252(569( )0.89126(.1569(.)0.96 Tf-2256 Tf-229.89126(f)-11.1569(o)10.2657(t).78252( )-1111.1569(a)191269(t).89126( )01111.1569(a569(a54(978326(v)61.78252( )-131.639(d)-10.2657(a)-10.2657(m)-24894(a)-4.34894(m)i1.1569(l)5. Tf-2250.89126(h)1.78252( ))1.78252(d)1.78252( )-143.687(bg6 Tf-229.89126(f)-.89126( )0.89153( )]-6.91536(a)1.78252(n)10.2657(n)1.78252( )0.89126(u)11.78252( )-)1.78252(t)0.89126(e)1.78252(r)-4.89126(o)1.78252(u)1.78252( ))1.78252(d)1.78252( )-143.687(b16 9.88589Tf4.56 0 Td[( )-107136.52s)-6.0241(o1.78326(m)-22.422(o)1.78326(v)6.0241(e)1.D.78252( )-0.88.9960)-10.2657(e)11569(a)-10.2657(l)5.96 Tf-49.78252(t)0.89126(i531.78546(k)-18.0723(e)1)1.78252(d)1.78252( )-143.2(t)0.88252(o)-10.2657(u)111.1569(4t)0.89126( )1.78252(n)1011.1569(a.78252(d)1.78252( x78252( )-11.1569(t)4.34894( )0.88.99609 i.0241(o)1.78252(a)10.88.99609 4.89126(o)1.78252( )-131.639(d)-10.2657(a)-5316.0241(o)-10.2657(l)-4.34894(a)-231.639(s)-6.0241(o)1.78252(a)1.7.2657(n)1.731.639(wR16 9.96 Tf4.56 0 Td[( )-1074(W)-31.9037(a)13.8315(s)-6.0241(h)1.78326( )-131.639(t).78326(l)5.13284(u)1.78252(t)0.89126(i)-6c91536(o)1.78252(n)110.2657(n)1.78252( ).89126(f)-.89126( )0.78252( )-e)-6.0241(t)0.89126( )10.2657(t)0.89126(.)0i1.1569(l)5. Tf-2250 Td[(o)1.78252(m)-1.78252(569( )0.89126(f)-11.15 Tf-2256(h)1.78252(a)-10.2657(n)1..2657(n)113284( )0c91536(o)1.891269(.)0.91269(.)10.2657( )0.892657(n)1.78252( )0.89126(u)11.2657(n)1.731.639(w-178252(l)-6.91536(u)1.78252(g)0.2657(l)5.96 Tf-229.86 Tf-22910.2657(e)11.91536(a)1.569(a)n)1.78252(d)10.3745(m)-22.4221(m)0.89126(f)d891269(.)0.91269(.).78252( )-1189126(n)-10.2657(e))1.78252(u)1.78252(r)r-143.687(b)18252(n)-d.89126(.)0i1.1569(l))0.89126(e)89126(n)-10.2657(e)16 9.88589Tf4.567137.)-31.9037(a)1cm BT/R14 9.96 Tf1 0 0 1 71.9995 712.641 Tm[(C)-0.89126(l)0.89126(e)1.78326(a)1.78326(51.7885768(i)V)1569( )0)0.89126(Yc96 Tf-49.)0.89126(Yt1.1569( )0-16.3971(o)1.78252(f)n)3.45768( )0.89126(R.78326(l)5.-16.3971(omTQ0664(w-1556 0 8.33333 0 0 cm47475.13564 0 cm Tf1 0 0 1 199.8 712.641 Tm( )TjETQ0 0 0 RG0 0 0 rgq8.3333330 0 51.7885768( cm BT/R44 9.96 Tf1 0 0 1 71.9995 700.281 Tm(·)Tj/R16 9.96 Tf4.56 0 Td[( )-1071.4(U)559.1626(p)1.78326(o)1.78326(n)1.78326( )-11.1569(i)1.78326(f)0.89126(f)-11.1569( )0.89126(t)0.89126(h)1.78252(e)1.78252( )0.89126(r)-4.34894(e)1.78252(f)-11.1569(r)-4.34894(i)5.13284(g)1.78252(e)1.78252(r)-4.34894(a)1.78252(t)0.89126(o)1.78252(r)-4.34894( )0.89126(f)-11.1569(i)5.13284(r)-4.34894(s)-6.0241(t)0.89126( )0.892731(a)1.78252(n)1.78252(d)1.78252( )-11.1569(t)0.89126(h)1.78252(e)-10.2657(n)1.78252( )0.89126(u)1.78306(n)-10.2657(p)1.78252(l)-6.91536(u)1.78252(g)1.78252( )0.89126(t)-11.1569(h)]TJ220.68 0 Td[(e)1.78252( )0.89126(u)-10.2657(n)1.78252(i)5.13284(t)-11.1569( )0.89126(f)-11.1569(r)7.69778(o)1.78252(m)-22.4227( )0.89126(t)0.89126(h)1.78252(e)1.78252( )0.89126(w)11.1569(a)-10.2657(l)5.13284(l)-6.91536( )0.89126(o)1.78252(u)1.78252(t)-11.1569(l)5.13284(e)1.78252(t)-11.1569(.)0.89153( )]TJ/R44 9.96 Tf-225.24 -12.96 Td(·)Tj/R16 9.96 Tf4.56 0 Td[( )-1071.4(R)-0.6.0241(o1.78326(m)-22.422(o)1.78326(v)6.0241(e)1.78252( )0.89126(a)1.78252(l)-6.91536(l)5.13284( )0.89126(f)-11.1569(o)1.78252(o)1.78252(d)1.78252( )0.89126(c)-0.2657(l)5.96 Tf-229.89126(f)-11.1569(o)6.0241(o)-10.2657(n)1.78252(t)0.89126(e)1R16 9.96 Tf4.56 0 Td[( )-1074(W)-31.9037(a)13.8315(s)-6.0241(h)1.78326( )-131.639(t)0.89126(n)-3. Tf-225.24 -168( )06 Tf-49..89126(t)0.89126(h)10.2657(l)5.96 Tf-229.89126(f)-11.1569(o))1.78252(e)1.78252(r)-4.34894(a)1.78252(t)0.89126(o)1.78252(r)-4.34894( )0.89126(f)-11.1569(i)5..78252(u)1.78252(r)r-143.6(f)-R16 9.96 Tf4.56 0 Td[( )-1074(W)-31.9037(a)13.8315(s)-6.0241(h)1.78326( )-131.639(t)L3284(u)1.78252(t)0.)06 Tf-49.13284( )0.89126(t)0.89126(h)10..2657(n)1.731.639(w-131.62( )0.89126(u)1.78252(,)0.89126( )-1.78252(d1.78252(r)p96 Tf-229.89126(f)-.78252(l)-6.91536(d)1.78252(561.78252(d)1.89126(o)1.76 Tf-229h1.1569(i)5.9153( )].2 -12.72 Td(·)Tj/R6.91536(d))189126(n)--4.348(9 )11.1569(o)1.6 Tf-22913284( )0-4.3481590.89126( )-1.78252(dp96 Tf-2291.78252(r)8252(561.71569(t)4.3420241(o)-10.2657(n)1.78252(745(m)-22.4126(u)1.78o1.782528.-31.9037()-6.91536(o)1.78252(n))-2o)1.78252(f)-11.1569( )-11.1569(y)18.0723(o).78326(l)5.13284(u)1.78252( )-11.1569(t)0.89126(o)1.78252(n)110.2657(n)1.78252)1.78252(r)-4.34894( n))-2o).89126( ),)1.78252(n)1.7816(v)6.0241(e )-1(m)-24894(a)-4.34894,)1.78252(n)1.7816(v-1189126(n)-10.2657(e))1.78252(o)1.78252(ma)-4.34894-1189126(n)-10.2657(e(n)1.78252)]TJ/R44 9.96 Tf24 9.96 Tf-4.56 -12.96 Td(·)Tj23396 9.96 Tf4.56 0 Td[( )-1071.4(R)-0.6.0241(o1.78326(o)1.78326(n(n)1.78252( ).8952(t)0.)06 Tf( ).8952(t9(a.7825)5.96 Tf-229.89126(f)6.0241(1(c)-18.0723(l)5.13284(e)11.78252)1.78252(r)-6.91536(o)1.78252(n))-2o)1.78252(f)-11.1569(b-11.1569(r)7.69778(h)1.78252(e)-10.2657(n)1.78252( )7.69778(h)1.78252(ee)11.78269(d)-10.2657(n)1.78252( ).89126()1)58252( )-0.89126(h)1.cl)5. Tf-2250 Td[(a)-10.2657(m)-24894(a)-4.34894e)11.91536(a)-11.154( )278.003]TJTJ/R44 9.96 Tf24 9.96 Tf71(o)1.782573(n)1.78252( )7.69778(h).89126.1518.0723(e)1.731.639(w-131.61(m)0.89126(f)-11.1569(r)7.69778s))189126(nh)1.569(a)(t)0.89126( )1.78252(569( )0.89126(.1569(.)0.n0.89126( )-1f)-11.1569(r)7.6977896 Tf-225a)-10.2657(n)1..2657)0.89126( )-11.1569(.78252(dp96 Tf-2291.78252(r.89126(u)-10.2657(n)1 )-11.1569(t)0.2657(u)1.78252(l)-1.78252(ee)11.78f-2250 Td[(a)-10.2657(m)-24894(a).89126(u)’)1.24877(t)0.89126(.)0i1.1569i)-6.91536(a)1.78252(a6.0243jE )]TJ/R44 9.96 T420 )-11.420 )-11.42164.56 -12.96 Td(·)Tj237d(·6 9.96 Tf4.56 0 Td[( )-1074(W)-31.903 0 0 r( )'ETQ0 0 04518.0723(S)1.78326(ht1.1569( )o)0.89126(R)-12.9395()0)0.89126(.)0i1.1569v)-11.1569(o)10.2657(c)10.2657()1.78252(r)-4.78252(e)196 Tf-49.Yt1.1569( )s1.78252(r:)-11.1569(i)2786 TL( [( )-10748118.0723(L96 Tf-225d))189126(n)--4.348()1 tu49..89126(t)0.89126(h)10.2657(l)5.96 Tf-229.89126(f)-11.1569(o)eratr fnulp-4.34894(a)1.78252(t)0.891536()1.78252(r)--11.1569(b-11.1569(r)..89126(t)-11.1569(h)]TJ220.d)10.3745(m)-22.4221ugtdanr n.78252m0518.0723(h)1.1.71569(t)4.3420241(o.78252(dp96 T11-225.24 -168( )06 Tf-4910.2657()1.78252(rr)7.69778(h)1.78252(e)-10.2657(n)1.78252(t)-]TJ224.64 0 Td[(o )7.69778(h)1.78252(el)5.13284(4 0 Td[(o )7.69778(d))1891282e(n)1.78252)]3.08 Td[(T( )'ETQ0 005(s)-6.024 0 0 r(2(r)r-143.6(f28.29.88589Tf4.56 0 Td[( )-1071385.130.8912 0 0 r( )'ETQ0 0 04518.0723(Lt1.1569( )o)0.89126(R( )0.89126(Y)-7.69925(o)-47.30159v)-11.1569(o)10.2252(c)10.2657()1.78252(r)-4.78252(e)196 Tf-49.)0.89126(Yt1.1569( )s1.78252(r:)-11.1569(i)2786 TL( [( )-1074801518.0723(I)0.89126(t)0.89126(h)11.78252(e)-10.2657(n)1.78252(t )7.69778(h)1.78252(ed))189126(nl)5.13284(i)-6.91536(a)1.78252(n)1.78252(a6..731.639(w-131.61()0.89126( )-11.1569(h)123.2051o)1.78252(a)10.88.9960 )0.89126(f)-11.1569(o)1.78252(en0.89126( )-1f)-11.1569(r123.2051o Tf-22523.2051om)-22.4221(m)0.89126 )0.89126(t)0.89126(h)1.78252( )-131.126(n) )0.89126(f)-11..2657(n)1.2657(u(m)0.89126 )0.89126()--4.348()1t)0.891536()1-6.91536(a)1.78252( )-131.639(d)-10.2(e )-19.78252(t)0.89126(i5)1.78252( 9s89126(i)(m)0.89126i)5.13284(t)0.89126( )-]TJ224.64 0 Td[(od)-10.2657(o)0.89126()--4.348()123.2051ol)5.13284( )0.89126(f)-11.1569(o).78252( )-131.126(n) conthiougthhnvo t v bg6 Tf-2298 04561()0.89126(c)-6.0241(of)-11..2657(n)83226(v)d bave m agfaen, ifo-13.08 Td[(T)-2ETQ88589Tf4.6(( )06 Tf-4910.226( )-131.639(t)1.78252(u)1.7825472 Td(·)94( )0.89126(f)-11.1569(i)5.13284(o)-6.91536(u)1.78252(.78252(d1.78252(r)p96 Tf-229.78252(a)-10.2657()-6.91536(d)1.78252(561.78252(d)1.89126(o)1.76 Tf-229h1.1569(:)5.13284(t)0.89126( (r)8252(561.71569(t)4 )0.89126()5.13284(ud))1891208(b-11.1569(r)7.69778()-11.1569(h)]TJ220.m)0.89126(f)-11.1569(r)7.69778o)-6.91536(u)1.78252(.78252(d1.78252(r)4.34894( n))-2h)1.)1.78252( )-11.1569()0.89126( )-11.1569(.78252(dp96 Tf-9.86 Tf17TQ9126(i)2( x782582(29h1.1569(i)5.9153( )0.89126(f)-11..2657(n)1.2657(uh)1.569(a)o)10.2657()-)0.89126 )0.89126(-1.24 -168( )06 Tf-49..89126(t)0.89126(h)10.2657(l)5.96 Tf-229.89126(f)-11.1569(o)d(f)523 )0-16.3971()-]TJ224.64 0 Td[(od)-10.2(e )-1)--4.348()1o)6.0241(o)-10.2657(n)1.782516 Td(·)Tj235TQ88589Tf4.( 9.88589Tf4.567137.)-31.9037(a)1cm BT/R14 9.96 Tf1 0 0 1 71.9995 712.641 Tm[(C)-0.8912 l)3.43697(M)Rv Yo(u)-3.486(f)- RefdgeraoreoR0 0 rgq8.3333330 0 51.7885768( cm BT/R44 9.96 Tf1 0 0 1 71.9995 700.281 Tm(·)Tj/R16417T5 Tf4.56 0 Td[( )-1071.4(U)559.1626(p)1.78326(o)1.78326(n)1.78326( )-11.1569(i)1.78326(f)0.89126(f)-11.1569( )0.89126(t)0.89126(h)1.78252(e)1.78252( )0.89126(r)-4.34894(e)1.78252(f)-11.1569(r)-4.34894(i)5.13284(g)1.78252(e)1.78252(r)-4.34894(a)1.78252(t)0.89126(o)1.78252(r)-4.34894( )0.89126(f)-11.1569(i)5.13284(r)-4.34894(s)-6.0241(t)0.89126( )0.892731(a)1.78252(n)1.78252(d)1.78252( )-11.1569(t)0.89126(h)1.78252(e)-10.2657(n)1.78252( )0.89126(u)1.78306(n)-10.2657(p)1.78252(l)-6.91536(u)1.78252(g)1.78252( )0.869778()-11.1569(h)]TJ220.68 0 Td[(e)1.78252( )0.89126(u)-10.2657(n)1.78252(i)5.13284(t)-11.1569( )0.89126(f)-11.1569(r)7.69778(o)1.78252(m)-22.4227( )0.89126(t)0.89126(h)1.78252(e)1.78252( )0.89126(w)11.1569(a)-10.2657(l)5.13284(l)-6.91536( )0.89126(o)1.78252(u)1.78252(t)-11.1569(l1.78252(r)-4.78252(t)-11.1569(.)0.89153( )]TJ/R44 9.96 Tf-225.24 -12.96 Td(·)Tj/R16 9.96 Tf4.56 0 Td[( )-1071.4(R)-0.89126(e)1.78326(m)-22.422(o)1.78326(v)6.0241(e)1.78252( )0.89126(a)1.78252(l)-6.91536(l)5.13284( )0.89126(f)-11.1569(o)1.78252(o)1.78252(d)1.78252( )0.89126(c)-0.2657(l)5.96 Tf-229.89126(f)-11.1569(o)6.0241(o)-10.2657(n)1.78252(t)0.89126(e)1R16 9.96 Tf4.56 0 Td[( )-1074(W)-31.9037(a)13.8315(S)-22.422(o)1.78326((n)1..2657(n)11352(t)0.89126(i)-61.7825472 )0.89126(f)]TJ/R44 h)1.78252(e)-10.2657()-10.2657(l)..89126(t)0.89126(h)10.2657(l)5.89126(f)--11.1569(a)--3.45768( .78252(l)-6.91536(l)-6.91536( )0.89126(o)1.78252(u)1.78252(t(a)-2.89126( )-1.78252e)-4.3)Tj/R]TJ220.m)0.89126(f)6.78252(d)1.78252(a)6.0241(1(c.78252)1)58252( )-6.0241(i)-6.91536(d)1.78252(e)1.89126(f)-t9126(i)-0.89126(h)1.78252(e)1.78252(r)-1.78252(m)-1.78252()-10.2657(e)ofi

TROUBLESHOOTING GUIDE

You can solve many common refrigerator problems easily, saving you the cost of a possible

service call. Try the suggestions below to see if you can solve the problem before calling for

service.

PROBLEM POSSIBLE CAUSE

Refrigerator does not operate. Not plugged in.

The circuit breaker tripped or a blown fuse.

Compressor turns on and off frequently. The room temperature is hotter than normal.

A large amount of food has been added to the

refrigerator.

The door is opened too often.

The door is not closed completely.

The temperature control is not set correctly.

The door gasket does not seal properly.

The refrigerator does not have the correct

clearances.

The refrigerator has recently been disconnected

for a period of time. 4 hours are required for the

refrigerator to cool down completely.

Temperature inside the refrigerator is too warm. Temperature control is set too warm. Turn the

control to a cooler setting and allow several hours

for the temperature to stabilize.

Door is kept open too long or is opened too

frequently. Warm air enters the refrigerator every

time the door is opened. Open the door less

often.

The door is not closed completely.

The door gasket does not seal properly.

A large amount of warm or hot food might have

been stored recently. Wait until the refrigerator

has had a chance to reach its selected

temperature.

The refrigerator has recently been disconnected

for a period of time. 4 hours are required for the

refrigerator to cool down completely.

Temperature inside the refrigerator is too cold. Temperature control is set too cold. Turn the

control to a warmer setting and allow several

hours for the temperature to stabilize.

Temperature of external refrigerator surface is

warm.

The exterior refrigerator walls can be as much as

30οF warmer than room temperature. This is

normal while the compressor works to transfer

heat from inside the refrigerator cabinet.

Popping or cracking sound when compressor

comes on.

Metal parts undergo expansion and contraction,

as in hot water pipes. This is normal. Sound will

level off or disappear as refrigerator continues to

run.

Bubbling or gurgling sound, like water boiling. Refrigerant (used to cool refrigerator) is

circulating throughout the system. This is normal.

Vibrations. Check to assure that the refrigerator is on a level

surface.

Floor is uneven or weak. Refrigerator rocks on

the floor when it is moved slightly. Be sure floor
