Major Science MD-01N-110 Bedienungsanleitung

Genius Dry Bath Incubator

Instruction Manual

Catalog No.

MD-01N-110 / 220

MD-02N-110 / 220

MD-01N-T-110 / 220

MD-02N-T-110 / 220

www.majorsci.com

[email protected]

Version 02D

Revision on:2015.08.12

Packing list

MD-01N-110 / 220

MD-02N-110 / 220:

- 1 × Single Block Genius Dry Bath Incubator

1 × Dual Block Genius Dry Bath Incubator

- 1 × Power Cord

- 1 × Genius Dry Bath Incubator Instruction Manual

Note:

You may not install the external temperature probe by yourself if

purchasing MD-01N-110 / 220 or MD-02N-110 / 220. Consider carefully

before purchasing.

MD-01N-T-110 / 220

MD-02N-T-110 / 220:

- 1 × Single Block Genius Dry Bath Incubator

1 × Dual Block Genius Dry Bath Incubator

- 1 × External Temperature Probe

- 1 × Power Cord

- 1 × Genius Dry Bath Incubator Instruction Manual

Signed by:

Date:

Major Science is liable for all missing or damaged parts / accessories

within 7 days after customer received this instrument package. Please

contact Major Science immediately regarding this issue. If no response

within such time period from consignee party, that will be consignee

party’s whole responsibility.

Table of Contents

Packing list..........................................................................................................1

Warning ...............................................................................................................3

Section 1Introduction....................................................................................7

1.1 Overview ..................................................................................................... 7

1.2 Control and Features................................................................................... 7

Section 2Product Description ......................................................................9

Section 3Product Specifications................................................................10

Section 4Installation Instructions ..............................................................11

Section 5Operation Instructions ................................................................12

Temperature Calibration .................................................................................. 13

Section 6Function Control Software Instructions ....................................15

6.1 Installation Instruction................................................................................ 15

6.2 Operation Instruction ................................................................................. 15

Section 7Troubleshooting & Maintenance ................................................18

Troubleshooting Guide .................................................................................... 18

Error Detection ................................................................................................ 18

Maintenance.................................................................................................... 19

Section 8Ordering Information...................................................................20

Section 9Warranty.......................................................................................21

Warning

Major Science Genius Dry Bath Incubator has been tested and found to

comply with safety limits for the CE regulation. Also, Genius Dry Bath

Incubator is RoHS compliant to deliver confident product which meets the

environmental directive. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and can radiate

radio frequency energy, and if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference

at their expense. Changes or modifications not expressly approved by the

party responsible for compliance could void the user’s authority to operate the

equipment. It is strongly recommended for the user to read the following points

carefully before operating this equipment.

1. Read and follow carefully the manual instructions.

2. Do not alter the equipment. Failure to follow these directions could result in

personal and/ or laboratory hazards, as well as invalidate equipment warranty.

3. Use a properly grounded electrical outlet with correct voltage and current

handing capacity.

4. Disconnect from power supply before maintenance and servicing. Refer

servicing to qualified personnel.

5. Never use this instrument series without having the safety cover correctly in

position.

6. Do not use the unit if there is any sign of damage to the external tank or

cover. Replace damaged parts.

7. Do not use in the presence of flammable or combustible material; fire or

explosion may result. This device contains components which may ignite such

materials.

8. Refer maintenance and servicing to qualified personnel.

9. Ensure that the system is connected to electrical service according to local

and national electrical codes. Failure to properly connection may create fire or

shock hazard.

10. Use appropriate materials and operate correctly to avoid possible hazards

of explosion, implosion or release of toxic or flammable gases arising from

overheated materials.

11. Always use the block lifter to remove hot blocks, and wear appropriate

protection to avoid burning your hand.

ATTENTION:

Hot surface!

12. The instrument is intended for scientific research use only, and must be

operated by qualified personnel who realize the potential risks of the use of this

instrument. Major Science makes no claim that its instruments are designed or

certified as medical device; no representation, promises, express warranty, or

implied warranty will be made concerning the suitability of these instruments

for any medical use. Major Science will not provide customers any notice or

certification concerning its products being compliant as a medical device.

Safety Information

Use high level of precaution against any electrical device. Before connecting

the electrical supply, check to see if the supply voltage is within the range

stated at the rating label, and see to it that the device be seated firmly. Place

the unit in a safe and dry location; it must NOT touch the surrounding. Follow

the safety precautions for chemicals / dangerous materials. If needed, please

contact qualified service representative or ser[email protected]

Environmental Conditions

Ensure the instrument is installed and operated strictly in the following

conditions:

1. Indoor use only

2. ≤95% RH

3. 75 kPa – 106 kPa

4. Altitude must not exceed 2000 meters

5. Ambient to 40°C operating temperature

6. Pollution degree: 2

7. Mains supply voltage fluctuations up to ±10% of the normal voltage

Avoiding Electrical Shock

Follow the guidelines below to ensure safe operation of the unit.

Genius Dry Bath Incubator has been designed to use with shielded wires thus

minimizing any potential shock hazard to the user. Major Science recommends

against the use of unshielded wires.

To avoid electrical shock:

1. In the event of solution accidentally spilled into the instrument, it must be

dried out for a period of time, at least 2 hours, and restored to NORMAL

CONDITION before each operation.

2. NEVER connect or disconnect wire leads from the power jacks when the

power is on.

3. WAIT at least 5 seconds after stopping a run before handling output leads or

connected apparatus.

4. ALWAYS make sure that hands, work area, and instruments are clean and

dry before making any connections or operating the equipments.

5. ONLY connect the power cord to a properly grounded AC outlet.

Avoiding Damage to the Instrument

1. Do not attempt to operate the device if it is damaged.

2. Protect this unit from physical damage, corrosive agents and extreme

temperatures (direct sunlight, etc.).

3. For proper ventilation and safety concerns, keep at least 10 cm of space

behind the instrument, and at least 5 cm of space on each side.

4. Use high level of precautions against the damages on the unit.

5. Do not operate the unit out of environmental conditions addressed above.

5. Prior to apply any cleaning or decontamination method other than

manufacturer’s recommendation, users should check with the manufacturer’s

instruction to see if the proposed method will damage the equipment.

Equipment Operation

Follow the guidelines below to ensure safe operation of the unit:

1. Check the displayed temperature figure and external temp. probe to see if it

is overheating, and check if it will function in the case of a single fault at least

once per day.

2. NEVER access dangerous chemicals or other materials to prevent possible

hazard of explosion and damage.

3. Do not apply lids or covers on the tube heated inside Genius Dry Bath

Incubator to prevent possible hazards of explosion and damages.

4. A temporary conductivity caused by condensation might occur even though

this series is rated Pollution Degree 2 in accordance with IEC 664.

Symbols

The symbols used on Genius Dry Bath Incubator are explained below.

Indicates an area where a potential shock hazard may exist.

Consult the manual to avoid possible personal injury or

instrument damage.

ATTENTION: Hot surface!

Indicates disposal instruction.

DO NOT throw this unit into a municipal trash bin when this unit

has reached the end of its lifetime. To ensure utmost protection

of the global environment and minimize pollution, please recycle

this unit.

Section 1 Introduction

1.1 Overview

Major Science’s single and dual block Genius Dry Bath Incubators provides

comprehensive designs for a wide variety of applications. Excellent

temperature control figures can deliver accurate and reliable experimental

results from one experiment to another. Genius Dry Bath Incubators are also

space compact instruments with competitive pricing offerings. It is a user

friendly unit that comes with great value. More importantly, Genius Dry Bath

Incubators are RoHS compliant and designed to comply with the CE

regulation.

MD-01N MD-02N

1.2 Control and Features

Please refer to the following page for the location of the following controls and

features.

(1) (2) (3) (4)

Front view

Rear View

(8) (9) (10)

(1) Key – to increase temperature or time value

(2) Key – to decrease eithertemperature or time value

(3) Key – activate or stop the unit.

(4) Key – set or select timer mode

(5) TIMER – This LED light indicates running Timer Mode

(6) Set Temp - This LED light indicates temperature is on setting value

(7) Heating –This LED light indicates temperature is increasing.

(8) AC Power Switch – to switch the unit power ON/OFF

(9) AC Power Cord and Fuse Holder – Power Cord Socket and Fuse Holder

(10) RS232 Connected Port – for Data Log

Section 2 Product Description

Both single and dual block Genius Dry Bath Incubators use interchangeable

heating block modules for a variety of applications, including restriction

enzyme digestion, denaturing DNA, BUN, melting agar, coagulation studies,

hybridization, and Hot Start thermo-cycled reaction. Due to its molded

aluminum alloy chamber, it can be applied as a mini water bath. All models

incorporate a PID controller for easy temperature selection, rapid heat up and

excellent stability. Temperature may be set in 0.1°C increments from 5°C

above ambient to 150°C. An optional temperature probe is available for placing

directly in samples. A timer equipped within the unit may be set from 1 to 999

min for user’s convenience. In addition to Function Control software package

which controls the dry bath incubator through a computer is also a

comprehensive design for your experiment.

Features:

Microprocessor controller with digital display

User temperature calibration

Leakage proof for molded aluminum alloy heating chamber

Single and Dual block modes

Optional external temperature probe is available

Optional Function Control software package is available

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Major Science Zubehör Handbücher

Major Science

Major Science Winpact SI-200 Bedienungsanleitung

Beliebte Zubehör Handbücher anderer Marken

Hillco

Hillco 2810 Bedienungsanleitung

Siemens

Siemens QSA2700D Bedienerhandbuch

Contours

Contours ZY024 Bedienungsanleitung

Saivod

Saivod VS621 Bedienungsanleitung

Virtuox

Virtuox VirtuCLEAN 2.0 Bedienungsanleitung

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Bedienungsanleitung

Z-Wave

Z-Wave HSD-200Z Bedienungsanleitung

turck

turck FMX-IM-2UPLI63FX Bedienungsanleitung

Decagon Devices

Decagon Devices 10HS Bedienungsanleitung

UPPAbaby

UPPAbaby Cup Holder Bedienungsanleitung

Elko

Elko SmartSensor Leakage Wireless Bedienungsanleitung

Grizzly

Grizzly H8371 Bedienungsanleitung

Panasonic

Panasonic HG-T Series Bedienungsanleitung

IFM Electronic

IFM Electronic Efector 250 Series Referenzhandbuch

DigiDesign

DigiDesign 888/24 I/O Bedienungsanleitung

PROZIS

PROZIS QUAY Bedienungsanleitung

patagonia

patagonia PSI Vest Bedienungsanleitung

SFC Energy

SFC Energy EFOY GO! Bedienungsanleitung
