MakerBot Replicator 2X Bedienungsanleitung

USER MANUAL

The product may dier slightly from the images and instructions in this manual as we continue to improve the

MakerBot Ecosystem. Please see www.makerbot.com/um_rep_2X for the latest version of the manual.

WELCOME

1 WELCOME 5

Legal Notices 6

Safety and Compliance 8

Diagrams 10

How it Works 12

Accessory Checklist 13

Filament 14

2 ONBOARD OPERATIONS 16

The LCD Panel 17

LCD Menus 18

Utilities Menu 19

Info and Settings Menu 21

Active Build Menu 24

Leveling the Build Plate 26

Loading Makerbot Filament 28

3 MAKERBOT DESKTOP 32

Downloading and Installing MakerBot Desktop 33

About MakerBot Desktop 35

The Prepare Screen 36

4 PRINTING WITH YOUR MAKERBOT REPLICATOR 2X 39

Choosing a Model 40

Preparing a Model 41

Printing a Model 45

5 ADVANCED SETTINGS 49

Quality 50

Temperature 53

Speed 54

Custom Proﬁles 55

6 MAINTENANCE 56

Leveling the Build Plate 57

Replacing Kapton Tape 59

Lubricating the Z-Axis Rod and Idler Pulley 61

Realigning the Gantry 63

TABLE OF CONTENTS

WELCOME

Tightening the X and Y-Axis Pulleys 65

Filament Care 66

7 TROUBLESHOOTING 67

Printing Issues 68

LCD Error Messages 73

Misaligned Nozzles 76

Dos and Don’ts 78

Useful Tools 79

Diagnosing Print Quality Issues 80

8 REFERENCE 85

Speciﬁcations 86

Glossary 87

Notes 91

TABLE OF CONTENTS CONTINUED

WELCOME

Welcome to the User Manual for the MakerBot Replicator 2X Experimental

3D Printer. Your MakerBot Replicator 2X is optimized for ABS, a traditional

thermoplastic that can be tricky and unpredictable. In order to achieve

great results, you will need to experiment and tinker. That’s why it’s so

crucial to take the time to learn about your new 3D printer.

In this manual, you will learn how to set up and start using your

MakerBot Replicator 2X. You will also be introduced to MakerBot

Desktop, software that prepares 3D models for printing and turns them

into instructions for your MakerBot Replicator 2X. By the time you finish

reading, you will know everything you need to start experimenting.

We are so excited to welcome you to the MakerBot community.

Let’s get started!

WELCOME

LEGAL NOTICES

PRODUCT WARRANTY

The MakerBot Replicator 2X Experimental 3D Printer is covered by a limited warranty.

For terms and conditions, see makerbot.com/legal.

OVERALL PROVISIONS

All information in this user manual is subject to change at any time without notice and

is provided for convenience purposes only. MakerBot Industries, LLC and our respective

aliates and suppliers (“MakerBot”) reserves the right to modify or revise this user

manual in its sole discretion and at any time and makes no commitment to provide any

such changes, updates, enhancements, or other additions to this user manual in a timely

manner or at all. You agree to be bound by any modiﬁcations and/or revisions. Contact the

MakerBot Support Team for up-to-date information.

In order to protect MakerBot proprietary and conﬁdential information and/or trade secrets,

this document may describe some aspects of MakerBot technology in generalized terms.

INTELLECTUAL PROPERTY

The design of this user manual and all text, graphics, information, content, and other

names, service marks, and logos (the “Marks”) used in this user manual are registered

and unregistered trademarks, trade names, and service marks of MakerBot and its

aliates. Nothing contained in this Manual grants or should be construed as granting,

by implication, estoppel, or otherwise, any license or right to use any Marks without the

written permission of MakerBot. Any unauthorized use of any information, materials, or

Marks may violate copyright laws, trademark laws, laws of privacy and publicity, and/or

other laws and regulations.

WELCOME

DISCLAIMERS

MakerBot does not warrant the accuracy or completeness of the information, products,

or services provided by or through this user manual and assumes no responsibility

for any typographical, technical, or other inaccuracies in this user manual, which is

provided “as is” and without any express or implied warranties of any kind, including

warranties of merchantability, ﬁtness for a particular purpose, or non-infringement of

intellectual property. MakerBot makes no warranties to those deﬁned as “consumer”

in the Magnuson-Moss Warranty-Federal Trade Commission Improvement Act. In

connection with your use of this user manual, MakerBot shall not be liable to you for any

damages whatsoever, be they direct, economic, commercial, special, consequential,

incidental, exemplary, or indirect damages, even if MakerBot has been advised of the

possibility of such damages, including without limitation, loss of business revenue

or earnings, lost data, or lost proﬁts. MakerBot assumes no responsibility, nor will be

liable, for any damages to, or any viruses or malware that may infect, your computer,

telecommunication equipment, or other property caused by or arising from your

downloading of any information or materials related to this user manual. The foregoing

exclusions do not apply to the extent prohibited by law; please refer to your local laws

for any such prohibitions.

LEGAL NOTICES

WELCOME

SAFETY AND COMPLIANCE

RADIO AND TELEVISION INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

You may also ﬁnd helpful the following booklet, prepared by the FCC: “How to Identify

and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S.

Government Printing Oce, Washington D.C. 20402.

Changes and Modiﬁcations not expressly approved by the manufacturer or registrant

of this equipment can void your authority to operate this equipment under Federal

Communications Commission rules.

MANUFACTURER

MakerBot Industries, LLC

One MetroTech Center, 21st Floor

Brooklyn, NY 11201

347.334.6800

I. T. E.

WELCOME

SAFETY AND COMPLIANCE CONTINUED

Safety alert symbols precede each safety message in this manual.

These symbols indicate potential safety hazards that could harm you

or others or cause product or property damage.

WARNING: The MakerBot Replicator 2X Experimental 3D Printer

generates high temperatures. Always allow the MakerBot Replicator 2X

to cool down before reaching inside.

WARNING: The MakerBot Replicator 2X includes moving parts that

can cause injury. Never reach inside the MakerBot Replicator 2X while

it is in operation.

WARNING: Do not leave the MakerBot Replicator 2X unattended

during operation.

CAUTION: Use caution when printing with materials that have not been

approved by MakerBot for use with the MakerBot Replicator 2X.

CAUTION: In case of emergency disconnect power supply from

wall socket.

CAUTION: The socket outlet must be located near the equipment and

must be easily accessible

CAUTION: The MakerBot Replicator 2X melts plastic during printing.

Plastic odors are emitted during this operation. Make sure to set up the

MakerBot Replicator 2X in a well-ventilated area.

WELCOME

MAKERBOT REPLICATOR 2X DIAGRAMS

1Gantry System

2LCD Panel

3Heated Build Plate

4Build Platform

5Threaded Z-Axis Rod

6Enclosure Door Handle

7Filament Guide Tubes

8Extruder Cable

9Extruders

10 Filament Spool

11 Spool Holders
