USER MANUAL

V-22

Please take time to read these

instructions before starting

to use the scale

Version 1.0 03/17

Contents

Product Specification 3

Safety Instructions 4

Before Using the Scale 5

Operation 6

Error Messages 7

Manufacturer’s Declaration of Conformity

This product has been manufactured in accordance with the harmonized

European standards, following the provisions of the below stated directives:

Electro Magnetic Compatibility Directive 2014/30/EU

Low Voltage Directive 2014/35/EU

Marsden Weighing Machine Group Ltd.

Page 2

Product Specification

Thank you for purchasing a Marsden professional veterinary scale.

This is a precision weighing instrument and considerate use will

result in many years of accurate weighing.

The scale has a maximum load capacity of 20kg which must not be

exceeded.

Model

Marsden V-22

Capacity/Division

20kg x 5g

Units of Measure

Kg/lb

Function Keys

MEMORY, MODE, ON/TARE

Display

Easy to read LCD display with five active

digits

Operating Temperature

5 to 35°C

Power Supply

4x AA batteries

Dimensions

578mm x 334mm x 578mm

Warranty

One year

Weight of Scale

3kg

Please note: Marsden’s policy is one of continuous development and therefore

we reserve the right to change product specification without notice.

Page 3

Safety Instructions

Before putting this scale into use, please read with care the information given in this user

manual, which contains important instructions for proper installation, use and maintenance

of the device.

Marsden/the manufacturer shall not be liable for damages arising from failure to heed the

following instructions:

When using electrical components under increased safety requirements, always

comply with appropriate regulations.

Inappropriate installation/use will render the warranty null and void.

Ensure the voltage marked on the power supply unit matches your mains supply.

This product is not waterproof. We do not recommend using the scale in humid,

damp or wet environments.

Observe the permissible ambient temperatures for use.

The device meets the requirements for electromagnetic capability. Do not exceed

the maximum values specified in the applicable standards.

If you have any problems, contact Marsden/your local dealer/your service partner.

Cleaning

Please do not use corrosive liquids or large amounts of water to clean the scale. We

recommend using alcohol-based wipes or similar.

Always disconnect the scale from the mains power supply before cleaning.

Never disassemble the scale as this may cause malfunction.

Maintenance

The scale does not require any routine maintenance. However, we recommend

checking the scale’s accuracy at regular intervals. If any inaccuracies occur, please

contact your local dealer or service partner.

You can book an accuracy check with the Marsden Service team on 01709 364296.

Disposing of the Scale

This product should not be treated as regular household waste, but should be

handed in to an electrical/electronic equipment recycling centre.

Page 4

Before using the Scale

All Marsden V-22 scales come complete with plastic platform. There are three easy

to use function keys: ON/TARE, MODE, MEM.

The scale can be used in a fixed location or as a portable scale, powered by 4x AA

batteries.

If you require any assistance with using the V-22, call the Marsden team on 01709

364296, quoting model number V-22 and the serial number, which can typically be

found on the underside of the scale.

Before use, ensure the scale is on a flat surface. An un-level surface for weighing

could result in inaccurate readings.

Page 5

Operation

Switching the Scale on/off

To switch the V-22 on, press ON/TARE.

Once the scale shows a line of zeros, it is ready to use.

To switch the V-22 off, press and hold ON/TARE for three seconds.

Using the Tare function

The Tare function allows you to remove unwanted weight from the display, such as

a towel or blanket.

With the scale switched on, place the item you wish to tare off onto the platform.

Press ON/TARE. The display will show zero, and when you remove the item, a minus

reading.

When you place an animal to the scale the weight reading will show the weight of

the album, minus the weight of the item you removed using Tare.

To cancel the saved tare weight, switch the scale off.

Using the Mode function

To alternate between kg and lb readings, press the MODE button.

Using Memory Recall

Press MEM to store a weight reading showing on the indicator.

With the scale switched on and with a reading at 0kg, press MEM to recall one

previously stored weight reading.

Using Auto-hold

When you place an animal on the scale, the auto-hold feature will be automatically

hold the weight reading.

When additional weight is added to the scale, the reading will adjust, and

automatically hold the weight again.

Page 6

Error Messages

Display

Problem

Solution

Low battery

Replace the 4x AA batteries

Overload

If the total load exceeds

20kg, the display will show

this message. The weight

must be removed

immediately from the scale

to prevent damage.

Error

Any other error. Switch the

scale off and back on again.

If the error persists, contact

your dealer.

Page 7

Tel: 01709 364296 / 0800 169 2775

Fax: 01709 364293

E-mail: sales@marsdengroup.co.uk

Manufacturing and Distribution:

Unit 7, Centurion Business Park,

Coggin Mill Way,

Rotherham,

S60 1FB

Head Office:

Unit 1, Genesis Business Park,

Sheffield Road,

Rotherham

S60 1DX

www.marsden-weighing.co.uk
