MasterChef TF2201804-MC Bedienungsanleitung

Outdoor 3-In-1 Cooker

Product no. 085-3250-4 (TF2201804-MC)

USER MANUAL

Toll-free: 1-855-803-9313

Read this manual thoroughly before using and save it for future reference.

Table of Contents

Warnings 2

Product Diagram 6

Component List 7

Hardware List 8

Assembly Instructions 9

LP Tank 15

Lighting Instructions 19

Warnings

•To the installer or person assembling this appliance: Leave this manual with this appliance for future reference.

•This instruction manual contains important information necessary for the proper assembly and safe use

of the appliance.

•Read and follow all warnings and instructions before assembling and using the appliance.

•Follow all warnings and instructions when using the appliance.

•Keep this manual for further reference.

SAFETY SYMBOLS:

The symbols and boxes shown below explain what each heading means.

Read and follow all of the messages found throughout the manual.

DANGER: Indicates an imminent hazardous situation which, if not avoided, will result in death or

serious injury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in

death or serious injury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or

moderate injury.

Product no. 085-3250-4 (TF2201804-MC) |

Leak Testing

Cleaning and Maintenance 21

Operation 24

Cooking Guide 26

Troubleshooting 30

Limited Warranty

DANGER:

If you smell gas:

1. Shut o gas to the appliance.

2. Extinguish any open ﬂame.

3. Open lid.

4. If odour continues, keep away from the appliance and immediately call your gas supplier or ﬁre

department.

Failure to follow these instructions could result in ﬁre or explosion which could cause property

damage, personal injury or death.

Warnings

DANGER:

1. Never operate this appliance unattended.

2. Never operate this appliance within 10’ (3.0 m) of any structure, combustible material or other

gas cylinder.

3. Never operate this appliance within 25’ (7.5 m) of any ﬂammable liquid.

4. If a ﬁre should occur, keep away from the appliance and immediately call your ﬁre department.

Do not attempt to extinguish an oil or grease ﬁre with water.

Failure to follow these instructions could result in ﬁre or explosion which could cause property

damage, personal injury or death.

WARNING:

This appliance is not intended for commercial use.

WARNING:

1. Do not store or use gasoline or other ﬂammable liquids or vapors in the vicinity of this or any other

appliance.

2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

3. Do not attempt to repair or alter the hose/valve/regulator for any “assumed” defect. Any

modiﬁcation to this assembly will void your warranty and create the risk of a gas leak and ﬁre. Use

only authorized replacement parts supplied by manufacturer.

DANGER:

•The safety relief valve on the LP tank could activate releasing gas and cause an intense ﬁre with

risk of death or serious injury. Therefore, follow instructions bulleted below exactly.

(a) Do not store a spare LP-gas cylinder under or near this appliance.

(b) Never ﬁll the cylinder beyond 80 percent full.

•If the instructions in (a) and (b) are not followed exactly, a ﬁre causing death or serious injury

may occur.

Warnings

Product no. 085-3250-4 (TF2201804-MC) |

WARNING:

•This appliance is for OUTDOOR USE ONLY. DO NOT use in building, garage, shed, breezeway, or

any other enclosed area.

•This appliance is not intended to be installed in or on a boat. This appliance is not intended to be

installed in or on recreational vehicles.

•This appliance must not be used on or under any apartment or condominium balcony or deck.

•If stored indoors, detach and leave cylinder outdoors.

•DO NOT leave appliance unattended. Keep children and pets away from the appliance at all times.

•The use of alcohol, prescription or non-prescription drugs may impair the user’s ability to properly

assemble or safely operate the appliance.

•Never move the appliance when in use. Allow the cooking vessel to cool before moving or storing.

•Always keep the fuel supply hose away from any heated surface.

•It is for household use only. DO NOT use this appliance for anything other than its intended purpose.

•This appliance is not intended for and should never be used as a heater.

•Never use natural gas in a unit designed for liquid propane gas.

•Leak tests must be conducted prior to each use.

•Appliance is hot when in use.

To avoid burns:

DO NOT attempt to move the appliance.

Wear protective gloves or oven mitts.

DO NOT touch any hot surfaces.

DO NOT wear loose clothing or allow hair to come in contact with appliance.

•This appliance will be hot during and after use. Use insulated oven mitts or gloves for protection

from hot surfaces or splatter from cooking liquids.

•When cooking with oil or grease, have a type BC or ABC ﬁre extinguisher readily available. In the

event of an oil or grease ﬁre do not attempt to extinguish with water. Immediately call the FIRE

DEPARTMENT. A type BC or ABC ﬁre extinguisher may, in some circumstances contain ﬁre.

•When cooking, the appliance must be on a level, stable noncombustible surface in an area clear of

combustible material. An asphalt surface is not acceptable for this purpose.

Warnings

WARNING:

•Use your appliance OUTDOORS in a well-ventilated

space away from dwellings or other buildings to

prevent dangers associated with gas accumulation

and toxic vapors. The appliance should be situated

at least 10 feet (3.05 m) from buildings. Not

adhering to these clearances will prevent proper

ventilation and may increase the risk of a ﬁre and/or

property damage, which could also result in personal

injury.

•Maintain a minimum clearance of 10 feet (3.05 m)

between all sides of the appliance, deck railings,

walls or other combustible material. The outdoor cooking gas appliance must not be used under

overhead combustible constructions. DO NOT obstruct the ﬂow of combustion/ventilation air.

WARNING:

•Never move the appliance when in use.

•Never operate appliance with LP cylinder out of correct

position speciﬁed in assembly instructions.

•Always close LP cylinder valve and remove coupling nut

before moving LP cylinder from speciﬁed operating

position.

•Avoid bumping of or impact with the appliance to prevent

spillage or splashing of hot grease.

•Grease collected in grease tray is hot. Do not remove the

grease tray from the appliance until it is cool to touch.

•Keep appliance area clear and free from combustible

materials, gasoline and other ﬂammable vapors and liquids.

•Keep LP cylinder at a minimum distance of 24 inches (61 cm) away from appliance at all times.

WARNING: Hose is a trip hazard

24” (61 cm)

Keep the fuel supply hose away

from any heated surface

10’ (3 m)

CAUTION:

•Open lid while lighting.

•It is not possible to put out grease ﬁres by closing the lid, as the appliance is well ventilated for

safety reasons.

•Do not use water on a grease ﬁre. Personal injury may result. If a grease ﬁre develops, turn knob

and LP cylinder o.

•Do not leave appliance unattended while burning o food residue. If appliance has not been

regularly cleaned, a grease ﬁre can occur that may damage the product.

Product Diagram

Product no. 085-3250-4 (TF2201804-MC) |

Component List

Key No. Description Qty.

1 1

2 Body Assembly 1

3 4

4 Lid Handle, Silver 1

5 2

6 Basket 1

7 1

8 Front Left Leg 1

9 1

10 Control Panel And Regulator Assembly 1

11 3

Lid Assembly

Match Hole Cover

Rear Legs

Grease Tray

Front Right Leg

Flame Tamer

12 Grease Collector 1

13 1

Meat Thermometer

14 Lifting Hook 1

15 2

16 Wood Chips Box 1

17 1

Fryer Handle, Black

Hanger

18 Rack 1

19 1

Thermometer

Hardware List

Product no. 085-3250-4 (TF2201804-MC) |

Part No. Description Diagram Qty.

A M6 x 12 mm Bolt 24

Tools required (not included):

Cross-head screwdriver / Adjustable wrench

BM6 Step Bolt 4

C Hinge Pin 2

DCotter Pin 2

E Heat Insulation Washer 4

Assembly Instructions

Step 1

Step 2

Attach the Rear Legs (5), Front Left

Leg (8) and Front Right Leg (9) to

the Body Assembly (2) by using

12 pcs M6 x 12 mm Bolt (A).

Attach the Control Panel And

Regulator Assembly (10) to the

front legs by using 4 pcs

M6 x 12 mm Bolt (A) as shown.

Assembly Instructions

Step 3

Step 4

Product no. 085-3250-4 (TF2201804-MC) |

Attach the Oriﬁce Bracket to the

bottom of the body assembly by

using 2 pcs M6 x 12 mm Bolt (A)

as shown.

Make sure that the valve outlet

(oriﬁce) is inserted UPRIGHT

into the burner port.

Correct Position Incorrect Position

Insert the terminal of the ignition

wire into the connector of the

burner valve.
