CER Cidex OPA 3 Standard Rinse Software

Upgrade Kit Instructions

Document Number MI02-0100 Revision G Page 1 of 3

1.1 CER OPA 3 Standard Rinse Software Upgrade Kit, consists of the following items:

NOTE: CER Represents all current and previous Medivators Models listed

below: CER-1, CER-2, MV-1, MV-2, 5001, 5001X, 5002V,

5002VX.

Item Description Quantity

1 Micro-controller software chip 1

2 12 minute label 1

3 Software Upgrade Kit Instructions 1

1.2 The following tools are required for the installation:

1.2.1 Phillips Screw Driver

1.2.2 Chip extraction tool or a small flat screwdriver

1.2.3 Chip insertion tool (optional)

1.3 Install OPA compatible software chip

1.3.1 Turn the unit OFF.

1.3.2 Unplug the power cord from the unit.

1.3.3 Remove (5) Phillips screws from the right side panel and remove the panel.

Figure 1

1.3.4 Remove the micro controller software chip from the motherboard using a chip extraction

tool or small flat screwdriver.

Caution: When plugging in the new chip:

•Ensure that all pins are lined up with the socket.

•Ensure that the chip is fully inserted.

•Ensure that the notch in the chip is positioned upwards.

1.3.5 Plug in the new chip.

Caution: Do not touch the motherboard while the unit is plugged in.

1.3.6 Plug in the power cord.

Right Side Panel

CER Cidex OPA 3 Standard Rinse Software

Upgrade Kit Instructions

Document Number MI02-0100 Revision G Page 2 of 3

1.3.7 Turn the unit ON.

1.3.8 Verify that the control panel is lit and that the buttons are working properly.

1.3.9 If the panel is not working properly, repeat Steps 1.3.4 through 1.3.8.

1.3.10 If the panel is working correctly, turn the unit OFF.

1.3.11 Unplug the unit.

1.3.12 Replace the side panel using the (5) screws.

1.3.13 Plug in the power cord.

1.3.14 Apply the 12-minute label over the “5/10” button on the control panel.

Note: If converting a CER unit that is Rapicide compatible, apply the 12-minute

label over the “5” button on the control panel.

1.3.15 Turn the unit ON.

1.3.16 Run a cycle (optional).

Note: Retain the Manual Addendum (page 3 of these instructions) for future

reference.

Note: If there any questions please call Medivators Technical Service

1-800-444-4729 or 763-553-3300.

CER Cidex OPA 3 Standard Rinse Software

Upgrade Kit Instructions

Document Number MI02-0100 Revision G Page 3 of 3

ADDENDUM TO

5001 / 5001X / 5002 V /5002VX User/Service Manual

After proper installation of the OPA 3 Standard Rinse Kit, the operation of the machine will differ slightly

from the manual provided.

LCG Exposure times:

The programmable LCG exposure times will be 12, 20, 32, 45, 57, 65, and 77 minutes instead of

10, 20, 30, 45, 55, 65,and 75 minutes.

Automatic Full Cycle:

The unit will perform three rinses instead of two rinses.

LCG/Rinse Cycle:

The unit will perform three rinses instead of two rinses.

Please insert this sheet into the manual provided for future reference.
