Mellanox Technologies Switchx MSX1035B-1BRR Bedienungsanleitung

www.mellanox.com

SwitchX 36 Port QSFP Ethernet Switch

Installation Guide

P/N:MSX1035B-1BRR, MSX1035B-1SFR, MSX1036B-1BRR, MSX1036B-1SFR

Rev 1.4

Document Number: 3468

Rev 1.4

Mellanox Technologies

350 Oakmead Parkway Suite 100

Sunnyvale, CA 94085

U.S.A.

www.mellanox.com

Tel: (408) 970-3400

Fax: (408) 970-3403

Mellanox Technologies, Ltd.

Beit Mellanox

PO Box 586 Yokneam 20692

Israel

www.mellanox.com

Tel: +972 (0)74 723 7200

Fax: +972 (0)4 959 3245

Mellanox®, Mellanox logo, BridgeX®, ConnectX®, CORE-Direct®, InfiniBridge®, InfiniHost®, InfiniScale®, PhyX®,

SwitchX®, Virtual Protocol Interconnect® and Voltaire® are registered trademarks of Mellanox Technologies, Ltd.

Connect-IB™, FabricIT™, MLNX-OS™, ScalableHPC™, Unbreakable-Link™, UFM™ and Unified Fabric Manager™ are

trademarks of Mellanox Technologies, Ltd. All other trademarks are property of their respective owners.

NOTE:

THIS HARDWARE, SOFTWARE OR TEST SUITE PRODUCT (“PRODUCT(S)”) AND ITS RELATED

DOCUMENTATION ARE PROVIDED BY MELLANOX TECHNOLOGIES “AS-IS” WITH ALL FAULTS OF ANY

KIND AND SOLELY FOR THE PURPOSE OF AIDING THE CUSTOMER IN TESTING APPLICATIONS THAT USE

THE PRODUCTS IN DESIGNATED SOLUTIONS. THE CUSTOMER'S MANUFACTURING TEST ENVIRONMENT

HAS NOT MET THE STANDARDS SET BY MELLANOX TECHNOLOGIES TO FULLY QUALIFY THE

PRODUCTO(S) AND/OR THE SYSTEM USING IT. THEREFORE, MELLANOX TECHNOLOGIES CANNOT AND

DOES NOT GUARANTEE OR WARRANT THAT THE PRODUCTS WILL OPERATE WITH THE HIGHEST

QUALITY. ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT

ARE DISCLAIMED. IN NO EVENT SHALL MELLANOX BE LIABLE TO CUSTOMER OR ANY THIRD PARTIES

FOR ANY DIRECT, INDIRECT, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES OF ANY KIND

(INCLUDING, BUT NOT LIMITED TO, PAYMENT FOR PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;

LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY

THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE

OR OTHERWISE) ARISING IN ANY WAY FROM THE USE OF THE PRODUCT(S) AND RELATED

DOCUMENTATION EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

SwitchX 40GigE 1U Ethernet Switch Installation Guide Rev 1.4

Mellanox Technologies 3

Table of Contents

Table of Contents 3

List of Figures 4

Revision History 5

About this Manual 6

Intended Audience 6

Related Documentation

The documentation set accompanying the SX10XX top of rack switch platform includes the fol-

lowing:

All of these documents can be found on the Mellanox Website. They are available either through

the product pages or through the support page with a login of user and password.

Document Conventions

When discussing memory sizes, MB and MBytes are used in this document to mean size in mega

bytes. The use of Mb or Mbits (small b) indicates size in mega bits.

Table 2 - Reference Documents

Document Name Description

Switch Hardware User Manual This document contains HW descriptions, LED assign-

ments and HW specifications among other things.

Mellanox MLNX-OS SwitchX Software



User Manual This document contains information regarding configuring

and managing Mellanox Technologies’ SwitchX Switch

Platforms.

MLNX-OS Software Command Reference Guide Command Reference Guide for MLNX-OS listing all of the

commands available through MLNX-OS with explanations

and examples.

MLNX-OS Software Configuration Guide Configuration Guide for MLNX-OS displaying different

configuration scenarios.

This symbol makes recommendations to the user.

SwitchX 40GigE 1U Ethernet Switch Installation Guide Rev 1.4

Mellanox Technologies 7

Mellanox Part Numbering Legend

This symbol indicates information that is helpful to the user.

This symbol indicates a situation that can potentially cause damage to hardware or

software.

BEWARE! This symbol indicates a situation that can potentially cause personal injury

or damage to hardware or software.

Mellanox Part Numbering Legend

Place Field Decoder

MMellanox Technologies

SX System Type SwitchX Switch

PProtocol 10 = Ethernet

MM Port and

Management

Options

35 = 36 ports with Fabric Management

36 = 36 ports internally managed

CPort Config B = 40 Gb/s Ethernet

-Separator

P# Power Sup-

plies 0=0, 1=1, 2=2....

FForm factor S = standard depth, B = short depth

YAir Flow

direction R= Connector side to PSU side airflow

F= PSU side to Connector side airflow

RRoHS R = RoHS6

Installing the Switch in the Rack

Rev 1.4

Mellanox Technologies

1 Installing the Switch in the Rack

1.1 Minimum and Maximum Rack Depth for these Switches.

This switch can be installed in any standard 19” rack with depths of 40cm to 80cm.

Make sure that the Installation kit you have is compatible with your rack.

To use the SwitchX series switch in a rack deeper than 60cm, order the switch with the standard

depth, or order the MSX60-SKIT installation kit. The both of these solutions will allow you to

install the switch in a 19” rack whose vertical supports are between 60cm and 80cm apart.

1.2 Rack Mounting

The switch platform can be rack mounted and is designed for installation in a standard 19” rack.

The power side of the switch includes a hot-swap power supply module, a blank cover for an

optional second PSU for redundancy, and a hot-swap fan tray. There are two possible air flow

directions. Be sure that the switch air flow direction is compatible with your system, rack, and

PSUs. The connector side of the switch has theQSFP ports, system LEDs, and management con-

nection ports.

The switch platform contains auto-sensing 100 - 240 VAC connections for all possible PSUs.

The installer should use a rack capable of supporting the mechanical and environmental character-

istics of a fully populated platform.

1.2.1 Installation Kits

There are two Installation kit options. One long and one short. Both the standard and the short

switches can be mounted using the long rail kit. The short kit will only work with the short switch.

See “Mellanox Part Numbering Legend” on page 7 for explanation of the switch depth according

to the Model numbers.

The rack mounting holes conform to the EIA-310 standard for 19-inch racks. Take pre-

cautions to guarantee proper ventilation in order to maintain good airflow at ambient

temperature. Cable routing in particular should not impede the air exhaust from the

chassis.

Table 3 - Installation Kit According to Rack Size

Kit OPN Rack Size

MSX60-BKIT 40-60 cm

MSX60-SKIT 60-80 cm

SwitchX 40GigE 1U Ethernet Switch Installation Guide Rev 1.4

Mellanox Technologies 9

1.2.2 Mechanical Installation

The switch platform can be rack mounted and is designed for installation in a standard 19” rack.

The power side of the switch includes a hot-swap power supply module, a blank cover for an

optional second PS unit for redundancy, and a hot-swap fan tray. There are two possible air flow

directions. Be sure that the switch air flow direction is compatible with your system, rack, and PS

units. The connector side of the switch has the QSFP ports, system LEDs, and management con-

nection ports.

The switch platform contains auto-sensing 100 - 240 VAC connections for all possible PS units.

The installer should use a rack capable of supporting the mechanical and environmental character-

istics of a fully populated platform.

1.3 Package Contents and Installation

Before you install your new SX103X switch, unpack the system and check to make sure that all

the parts have been sent, check this against the parts list below. Check the parts for visible damage

that may have occurred during shipping.

The switch comes packed with the following items:

• 1 X – switch

• 1 X – installation kit

• 1 X – power cable for each PS unit – Type C13-C14

See “Replacement Parts Ordering Numbers” on page 30 to order power cords for various

countries.

A single power cord for each power supply unit can be ordered at no extra charge

• 1 X – Harness

HAR000028 – Harness RS232 2M cable – DB9 to RJ-45

• 1 X – Quick Start Guide

• 1 X – China RoHS statement

1.3.1 Installing the Switch in the Rack

Tools and Customer Supplied Parts:

The rack mounting holes conform to the EIA-310 standard for 19-inch racks. Take pre-

cautions to guarantee proper ventilation in order to maintain good airflow at ambient

temperature. Cable routing in particular should not impede the air exhaust from the

chassis.

If anything is damaged or missing, contact your customer representative immediately.

For customer support go to:

www.mellanox.com =>Support => Customer Support Portal Login

• Phillips Screwdrivers #1 and #2 • Grounding screw

• ESD strap • Grounding wire sufficient to reach a valid ground.

• ESD mat

Installing the Switch in the Rack

Rev 1.4

Mellanox Technologies

For racks from 60cm to 80cm deep either use the standard depth switches with the long rail kit or

the short switches with the long rail kit.

Parts included in the rail kit:

Figure 1: Rack Rail Kit Parts

1. Place the ESD mat on the floor where you will be working and put on the ESD strap. Make

sure the ESD strap is touching your skin and that the other end is connected to a verified

ground.

2. Choose which side of the switch you want even with the rack vertical support. Either the side

with the power supply units or the side with the QSFP connectors can be even with one of

the vertical rack supports.

• 2 rails • 16 recessed flat head screws You will have extras!

• 2 rail slides • 10 caged nuts

• 2 switch slides • 10 pan head screws M6

Switch slide x2

Rail x2

Rail slide x2
