Metra Electronics AHDH-HD2 Bedienungsanleitung

HONDA HARNESS

USED WITH AHDT-01 AND AHDI-IO1

1-800-221-0932 www.metraonline.com

AHDH-HD2

INSTALLATION INSTRUCTIONS

1-800-221-0932 www.metraonline.com

AHDH-HD2 AHDH-HD2

•Note : The AHDH-HD2 will not work with a

radio that has the 6-disc in dash cd changer.

Rev. 10/19/07 INSTAHDH-HD2

* READ IMPORTANT WARNING ON PAGE 1

BEFORE ATTEMPTING ANY INSTALLATION

HONDA

Accord 1994-1997

CRV 1995-1998

Odyssey 1995-1998

Prelude 1995-1998

The AHDH-HD2 is to be used along with the AHDT-01 HD Tuner and

the AHDI-I01 import HD radio interface (all sold separately) in the vehi-

cles listed. An iPod may also be connected by using the XIAH-IPC iPod

cable (sold separately). The OEM radio will control the functions of the

HD Tuner and the iPod through the buttons on the radio. Also for those

radios that do not display text, the XIA-LCD display screen (sold sepa-

rately), may be added to display the HD and iPod text information.

*IMPORTANT WARNING

THIS PRODUCT INCLUDES INSTRUCTIONS FOR INSTALLATION WHICH

MUST BE CAREFULLY FOLLOWED. THE INSTRUCTIONS ARE WORDED

IN SUCH A MANNER TO ASSUME THAT THE INSTALLER IS CAPABLE

OF COMPLETING THESE TYPE OF ELECTRONIC INSTALLATIONS.

IF YOU ARE UNCLEAR AS TO WHAT YOU ARE INSTRUCTED TO DO OR

BELIEVE THAT YOU DO NOT UNDERSTAND THE INSTRUCTIONS SO AS

TO PROPERLY AND SAFELY COMPLETE THE INSTALLATION YOU SHOULD

CONSULT A TECHNICIAN WHO DOES HAVE THIS KNOWLEDGE AND

UNDERSTANDING. FAILURE TO FOLLOW THESE INSTRUCTIONS

CAREFULLY AND TO INSTALL THE INTERFACE AS DESCRIBED COULD

CAUSE HARM TO THE VEHICLE OR TO SAFETY SYSTEMS ON THE

VEHICLE. INTERFERENCE WITH CERTAIN SAFETY SYSTEMS COULD

CAUSE HARM TO PERSONS AS WELL. IF YOU HAVE ANY QUESTIONS

IN THIS REGARD PLEASE CALL THE HELP LINE OR THE METRA AT

1-800-221-0932 FOR ASSISTANCE.

AHDH-HD2 AHDH-HD2AHDH-HD2

OPERA

TION

When the AHDI-I01 interface is installed the radio will see the interface as a cd

changer. It is recommended to use the XIA-LCD to get the most out of your iPod

or HD radio. If there is a factory cd changer already in the vehicle that is not an

in dash type, the cd changer will have to be disconnected.

Note: The Acura/Honda radios vary in what buttons they have however this

instruction will cover as many buttons as possible. The radios will not have every

button described below but the definition of the buttons displayed on the radio

will still be valid.

CD/CHG

AM/FM

SEEK/SKIP

PRESET #5 DISK SEL

PRESET #6 DISK SEL

OPERATION IN CD CHANGER MODE

FIRMWARE FOR THE iPOD:

BUTTON DESCRIPTION OF FUNCTION

The AHDI-I01 can emulate a factory CD Changer. In this mode, the button opera-

tions are re-defined to work with both the iPod and HD radio receiver.

Enters into ‘CD Changer’ mode & selects the next device. If

HD-AM was the previous device that was playing, then HD-

FM is selected and vise versa. If an iPod is attached, then it

will alternatively be chosen in the following order :

HD-AM > iPod > HD-FM > iPod

Deselects ‘CD Changer’ mode. (HD-AM, HD-FM, or iPod).

In iPod mode it goes to the next / previous song. In HD

mode, seeks to the next/previous channel.

In iPod mode, Seek to previous playlist.

In iPod mode, Seek to next playlist.

The firmware in your iPod must be the latest revision to operate correctly. Go to

Apple.com and check your revision with iPod Update.

PORT OVERVIEW

1) This port is used with the optonal XIA-LCD display.

2) This port is used with the HD cable included with AHDT-01 tuner.

3) This port is used with the iPOD cable XIAH-IPC or the AUX IN cable XIAH-RCA.
