Midea M100-B Administratorhandbuch

VACUUM CLEANER

OPERATION INSTRUCTIONS MANUAL

M100-B

Please read this Instruction Manual carefully before operating, and keep it properly.

Jiangsu Midea Cleaning Appliances Co.,Ltd

No.39 Caohu Avenue, Xiangcheng Economic

Development Zone, Suzhou , Jiangsu Province, 215131, P.R.C

http://www.midea.com/global

Contents Safety Introduction

Product Introduction

Product Operation

Product Maintenance

Trouble Shooting

Safety Introduction

1. Please do not use the vacuum cleaner near a heat

source, radiation or burning cigarette end. Do not

inhale the following objects:

- All liquids, including water and solvent.

- Construction dust and garbage such as lime or

cement ash.

- Hot objects, such as the unextinguished cigarette

end, etc.

- Shards.

- Flammable and explosive items.

2. Do not let children play, operate vacuum cleaners,

in case of accident;

3. Your vacuum cleaner is an electric appliance: it

must be used in accordance with normal

conditions, and it must not be operated by the

vacuum cleaner without supervision;

4. Clean, repair or temporarily not use, must cut oﬀ

the power supply;

5. Cut oﬀ the power supply, do not pull the power

cord directly, use the hand to hold the plug plug;

6. Check to conﬁrm that the power supply voltage

must be consistent with the vacuum operation

voltage;

7. The power cord of the vacuum cleaner can not be

contacted with sharp objects to avoid damage;

8. Do not use the vacuum cleaner in the water, avoid

the heat source or exposure, prevent the ﬁre;

9. Do not use vacuum cleaner in the following

situations and send them to the maintenance repair

point in time:

- Severe collision has occurred and caused obvious

damage or abnormal operation.

- The power cord is damaged.

10. Avoid long running when the suction inlet is

blocked, resulting in motor damage and vacuum

cleaning.

Product Introduction

Main body

Hose

Main brush

Combination suction brush

Plastic double pipe

Connect the hose accessories:

insert the hose end into the hose socket at the dust cup and then hook it.

Remove the hose accessories:

rotate the hose at both side and then pull the hose accessories.

Connect the plastic tube to the curves end of the hose.

Connect diﬀerent nozzle tools to the tube for diﬀerent cleaning purpose: ﬂoor brush (adjust to

the type of ground) for carpet or ﬂoor.

Product Operation

Illustration of the main unit

Pull out the power cord to connect the power: When you see the red marking on the power

cord, don't pull it out any more.

Turn on the machine: press the on/oﬀ switch pedal, the machine could start working.

Cord rewinding: hold the plug and pull out the cord; press the cord rewinding pedal, that

power cord will be drawn in.

Remove the dust cup: press the dust cup to release the key, gently pull the dust cup handle,

emove the dust cup;

Dumping garbage: please press the dust button to dump the garbage.

Open the dust cup: cover and extract the dust bowl;

Clean the ﬁlter element: remove the ﬁlter, rinse with water, and pay attention to the direction

of rotation.

Wash or exchange the outlet ﬁlter (HEPA): clip down and remove the outlet cover by hands for

wash or exchange of ﬁlter.

Product Maintenance

Dust cup cleanning

In case of malfunction, please refer to the following table

TROUBLESHOOTING

If the problem still can’t be solved, please contact local service center.

Solution

- Clean up the dust cup

- Reconnect the power

Suction abate

Possible reason

- Cup full of dust

- The power cord plugs oﬀ

- No power/power plug is not inserted

The machine

suddenly stopped

working

The machine

suddenly stops

Problem
