MIMAKI CG-60SL Montageanleitung

Supplement for the Basic Operation manual

MIMAKI ENGINEERING CO., LTD. D202064-10

The following functions are added from firmware version 1.80.

Please read this manual and fully understand it before using the device.

If you have any question, contact your local distributor.

This manual correspond to the models as firmware version 1.80 or later.

When turning on the power, you can confirm the firmware version.

Table of Contents

Make the media without uncut area ................................................................................ 2

Other Convenient Settings ............................................................................................... 3

Error message ................................................................................................................... 4

2

Make the media without uncut area

By over wrapping the start point and the end point arbitrarily, you can

make the media without uncut area.

Specify the over cut function (valid/invalid) and the length of the over cut.

If the length of the over cut is set, when cut starts, cut will be performed

from the position to the front by the specified length and the tool will move

up going too far at the end.

1Press the key in the local mode.

2Press the jog key or to select [SET UP] .

3Press the key.

4Press the jog key or to select [OVER

CUT] .

5Press the key.

6Press the jog key or to select OVER

CUT setting.

•Set values : OFF or a value from 0.1 to 1.0mm (0.1mm unit)

7Press the key.

8Press the key twice for terminating this function.

• Setting proper over cut can reduce uncut area of start and end point of a media easy to bend. If too

large value is set, the result may have a rupture

Over cut

part

DATA CLEAR <ENT >

FUNCTION

SET UP <ENT>

ENTER/HOLD

OVER CUT < e n t >

OVER CUT : OF F

ENTER/HOLD

OVER CUT : 0 . 3mm

0.1 ~ 1mm

0.1 ~ 1mm

ENTER/HOLD

END

3

Other Convenient Settings

The setting items are added in the "Other Convenient Settings" of the Operation Manual page.3-59.

The following three items are added.

Function name Outline Setting values

Over Cut Make the media without uncut area. OFF/ 0.1 to 1.0 mm

Start Mode Set the mode after detecting the sheet.

LCL

The mode switches to the

standby condition of the local

mode after detecting the sheet.

REM

The mode automatically

switches to the remote mode

after detecting the sheet.

4

Error message

The error message is added.

If the following message appears, take an appropriate remedy according to the table below.

If the remedy does not work, contact your distributor or an sales office of MIMAKI.

Error message Cause Remedy

ERR51 PINCH POS* The pinch rollers are not on the grit roll-

ers.

Move the pinch rollers onto the grit roll-

ers.

5

6

Memo

7

D202064-10-27052009

All Rights Reserved. NH

© MIMAKI ENGINEERING CO., LTD. FW:1.80
