MODSTER M855 Bedienungsanleitung
USER MANUAL / BETRIEBSANLEITUNG
E-BIKE
www
www.modster.at
2
User Manual MODSTER M855
1. Please store your bike away from sun exposure and raining areas.
2. Regularly check the screws and small parts on the bike, and tighten then
when needed. Screw torque of each main position: Stem screws (18-22NM), Sadd-
le screws (18-22NM), Front wheel nuts (25-39,9NM), Rear wheel nuts (30-35NM).
3. Do not use alcohol, gasoline, parafn, acetone or other corrosive chemical sol-
vents to clean the bike they may corrode the bike.
4. Chain tension standard: The distance of chain jumps up and down ≤ 10 mm. If
the chain is loosen, loosen the rear wheel nut, tight the chain adjustor, then tight
the nut.
5. If there is abnormal sound from disc brake, you can adjust the distance of the
disc brake and the disc rotor. If the disc rotor deect rate is too big or the disc
brake is disabled, you will need replace a rotor or brakes.
6. To add lubricating oil to frame folding wrench screws and slushing oil to chain
every 3 months for maintance.
7. Do not ush the E-bike with water to avoid accidents caused by internal
electronic components and wiring.
Maintenance and storage
Maintenance part
Brake Check the brake function, prevent accidents caused by brake
disfunction
Tire Rim Check the rim conditions, clean dirt, in case rim breaks or get stuck
Screws Check the screws in the main parts, in case they get loose or fall off
Throttle Check throttle condition, in case disfunction or malfunction
Charger Check if the charger cord are intact, input and output plug are reliable
Tire Check the tires condition and pressure, in case tires bursting or over
power consumption during riding
Shock absorber Check the shock absorber condition, clean and lubricant, keep it in a
good working condition
Battery Check the appearance and the battery performance, in case of wiring
faulty, extend the lifespan of the battery
Wires Check if the wires ports are loose or broken in case of wiring faulty
Lubrication Check the if axles and brake lights need lubrication
Cleaning Keep the bike surface in a clean condition
Suggest regular maintenance & check
Tip: please maintain and check the bike regularly, to keep it in a best condition
Maintenance purpose
www
www.modster.at
3
User Manual
Bike Structure & Functios
(The graphic is only for reference)
MODSTER M855
Brake
Stem
Stem folder
Bike frame
Front fork
Chainwheel
Bike frame folder
Disc
brake
Folder lock
Handle
Saddle
Seat post
Seat post clamp
Shock Absorber
Chainwheel protection wheel
Motor
Pedal
www
www.modster.at
4
User Manual
Precautions
About riding
1. In case of accident and injury, make sure your helmet, glove, elbow-pads,
knee-pads and other protection gears are well worn before riding.
2. Safety check: check the bike conditions before riding.
3. Do not ride on slippery road condition, especially on snowy and watery roads.
4. Do not ride on slopes over 15°.
5. If you must ride when its raining or snowing, keep it at a low speed and a
longer distance from the vehicle in front of you for emergency stops.
6. Kids under age 12 are advised not to ride the e-bike.
7. Avoid sudden acceleration and deceleration, do not lean forwards or
backwards while riding, and keep it at a limited speed.
8. When battery runs low, keep a low constant speed and charge the battery as
soon as possible.
9. If a fall is invitable, always put your own safety prior to the bike.
10. In case of any emergencies, keep both of your hands on the handlebar while
driving.
11. Do not store your bike in the trunk of your car in hot wheater.
12. Have full understanding of the local trafc regulations before you hit the
road.
13. Keep an eye on the surroundings, ride in a controllable condition and avoid
any collisions that might occur.
14. Keep a safe distance while riding along with other people, do not ride neck
by neck on the road.
15. Do note ride in dim environments, be cautious, if necessary, lower you speed
or stroll your bike.
16. Do not ride backwards, and do any actions that might endanger yourself and
others whille riding.
17. Do not lend your bike to those who are not familiar with the manual as you
do.
18. Do not ride while you dont feel well, not fater taking drugs or consuming
alcohol.
19. Accelerte slowly while riding, sudden acceleration may cause out-of-balance
and injure yourself.
20. Check if the brakes are working well before you ride.
MODSTER M855
www
www.modster.at
5
User Manual
Start immediately
1. Unfold the bike frame
1.Hold the frame and unfold it. 2.Fasten the folder as picture, and
check if as instruction 3) and 4)
before locked.
4.Press folder as 2) under this
status.
3.Press the folder lock to unfold top
piece. Adjust limit screw if
necessary.
MODSTER M855
www
www.modster.at
6
User Manual
Parameters (part 1)
MODSTER M855
Color options
Mechanical
conguration
Battery
specication
white/black
Suspension
Magnesium unibody frame
Rated Input
0.2-0.3 Wh per charge
Net weight (battery not included)
950mm
Battery weight
Lithium ion battery
Changing temperature 0°C-45°C
Seat height (from ground)
800*430*540mm
Battery capacity
Built-in/anti-theft lock/detachable
42V 1.5A
Tire dimension
Front and rear disc brake
Charging hour
2A max
Unfolded size
Folded size
1330*580*1040mm
Battery installment
Rear spring shock absorber
Rated output
100-240V 50/60Hz 2.0A
Brake system
About 17.5kg
Charging current
1.3kg
Wheelbase
760-920mm adjustable
Battery Type
36V / 5.2Ah
Battery lifespan 500 times
Frame material
16*1.95 inch
Power consumption
3-5 hours
www
www.modster.at
7
User Manual
3. Install the handle
1. Unfold the handlebar holder and
release the quick lock screw
clockwise.
3. Put the handlebar inside holder as
picture, fasten the holder and make
the screw out.
2. Put the nut and gasket aside, open the
holder but leave the screw there.
4. Install the nut and gasket back and tighten
them, adjust handlbar angle and position to
nish installation.
MODSTER M855
www
www.modster.at
8
User Manual
Charge Power
MODSTER M855
Option 1: uncover silicon lid to charge from
charging port of bike frame. (Pls gently pull
the silicon lid to avoid breaking)
How to push it walk or carry it
Option 2: pull out battery box to charge,
instead of moving the bike.
www
www.modster.at
9
User Manual
6. Unfold the pedals
7. Turn on Power
MODSTER M855
1. Hold the bike, unfold the pedal as
1. Please charge the battery to
activate it before rst ride.
2. Fold the pedal as picture, press inward,
and then upward
2. Long press M button on LCD to start
power.
www
www.modster.at
10
User Manual MODSTER M855
Read First
Thank you for choosing the Modster M855.
Please read this entire user manual carefully before trying this electric
bike.
This manual will help you
1) Understand the basic operating process of the product and the
usage of LCD display.
2) Get familiar with safe riding principles, and enjoy safe and happy ri-
ding experience.
3) Study the product structure, skills of maintenance, so as to extend its
lifespan.
