Monster FlatScreen Mount SmartViewTM 200L Bedienungsanleitung

SmartView

™

200L

FlatScreen Mount

Support d’écran plat

SmartView

™

200L

Base

SmartView

™

200L

FlatScreen para televisores planos



USER GUIDE & WARRANTY

GUIDE ET GARANTIE D’UTILISATEUR

GUÍA DEL USUARIO Y GARANTÍA

A NOTE FROM THE HEAD MONSTER

Dear Enthusiast,

THANK YOU

for purchasing the Monster

SmartView

® SmartView

™

200L FlatScreen Mount. The SmartView 200L reﬂ ects

our passion for creating the most innovative

and practical AV solutions on the market, so

enthusiasts like yourself always get the absolute

best from their high-performance AV components.

The SmartView 200L delivers the distinctive, custom

look you want, plus exclusive adjustment features,

so it’s always easy to get the best view.

Noel Lee,

The Head Monster

More Great Products from Monster FlatScreen

™

The Look You Want. The Performance You Need.

Monster FlatScreen Cables

™

Ultra slim and ﬂ exible, Monster FlatScreen Cables

ensure a clean, no-clutter hookup to your thin

display. Plus, they feature advanced Monster Cable

technologies, so you always get the best possible picture

and sound.

Monster FlatScreen PowerProtect

™

and PowerCenters

™

Safeguard your ﬂ atscreen investment

from harmful electrical surges and “dirty”

AC power with exclusive Monster Power

technologies, including Monster

SurgeGuard

™

and Monster

Clean Power

™

Monster FlatScreen Clean

™

Our safe LCD and plasma cleaning solution

instantly removes dust, dirt and ﬁ ngerprints

from your ﬂ atscreen without drips, stains or scratches.

For more details on all our Monster FlatScreen products, visit us

www.MonsterCable.com/FlatScreen

technologies, so you always get the best possible picture

Monster FlatScreen Clean





SmartView

™

200L FlatScreen Mount

SmartView 200L is designed to mount

37"

60"

LCD and plasma televisions

to vertical walls. Maximum weight capacity is

200 lbs.

SAFETY WARNING:

If you don’t understand these directions, or have doubts

about this product’s installation, please call a qualiﬁ ed contractor or contact

Monster Cable Products, Inc. at

1-877-800-8989.

Before installing, carefully review the instructions to that ensure no parts are

missing or defective. Improper installation can cause damage or serious injury.

Do not use this product for any purpose not explicitly speciﬁ ed by Monster.

Monster is not liable for damage or injury caused by incorrect assembly,

incorrect mounting or incorrect use.

All hardware is supplied for the following wall conditions:

Wood stud,

brick, solid concrete and concrete block.

Note:

The supplied hardware

is not for walls with steel studs.

If you are uncertain about the nature of your wall construction, consult

an installation contractor.

Speciﬁ cations and Notes:

Monster is constantly striving to improve its products.

Speciﬁ cations are subject to change without notice.





















Required Tools

Wall Stud Mounting:

Electronic stud sensor

Level

Electric hand drill

3/16" drill bit

Phillips screwdriver

Combination wrenches or socket set

Masonry Mounting (brick, concrete, concrete blocks):

Above tools

Replace 3/16" drill bit with 1/2" masonry drill bit

•

Package Contents

If any parts are missing, please call 800-877-8989.

1 Wall Plate

2 Vertical

Adjustment Bars

4 Concrete Anchors

2 L-Shaped Locking Bars

4 Square Washers

4 Round Washers

4 Spacer #1

4 Spacer #2

Screws

4 ea. M4x15/M4x35/M4x45

4 ea. M5x15/M5x35/M5x45

4 ea. M6x15/M6x35/M6x45

4 ea. M8x15/M8x35/M8x45

4 Lag Bolts

1 Bubble Level

Cautions and Warnings

Forbidden Actions:

Do not install on a sloping surface. Install exclusively

on a vertical surface.

Do not install in a room with excessively high temperatures

or high humidity.

Do not install near an air conditioner.

Do not install in a location with excessive dust, smoke or moisture.

These sources can create a ﬁ re.

Do not apply unnecessary stress or load on the installed unit.

Do not install unit alone. Safe installation requires at least

two people.

Do not route your ﬂ atscreen TV’s power cord in wall. Check local

building/electrical codes for more information.

Cautions:

To prevent eye fatigue, do not install where there is direct sunlight

or excessive light.

When carrying out maintenance, disconnect the TV’s power supply

to avoid electrical shock.

If planning to route AV cable in wall, only use cable UL-certiﬁ ed

for this use.
