SmartView 300S FlatScreen Mount
SmartView 300S is designed to mount
10"
to
24"
fl atscreen televisions to vertical walls. Maximum weight
capacity is
40 lbs.
SAFETY WARNING:
If you don’t understand these
directions, or have doubts about this product’s installation,
please call a qualifi ed contractor or contact Monster Cable
Products, Inc. at
1-877-800-8989.
Before installing, carefully review the instructions to
ensure that no parts are missing or defective. Improper
installation can cause damage or serious injury. Do not
use this product for any purpose not explicitly specifi ed
by Monster or the manufacturer. Neither Monster nor the
manufacturer can be liable for damage or injury caused by
incorrect assembly, incorrect mounting or incorrect use.
All hardware is supplied for the following wall conditions:
Wood stud, brick, solid concrete and concrete block.
Note:
The supplied hardware
is not for steel stud walls.
If you are uncertain about the nature of your wall
construction, consult an installation contractor.
2
Specifi cations and Notes:
Monster is constantly striving to improve its products.
Specifi cations are subject to change without notice.
3
Required Tools
Wall Stud Mounting:
Electronic stud sensor
Level
Electric hand drill
3/16" drill bit
Phillips screwdriver
Combination wrenches or socket set
Masonry Mounting
(brick, solid concrete, concrete blocks):
Above tools
Replace 3/16" drill bit with 1/2" masonry drill bit
•
•
•
•
•
•
•
•
4
Package Contents
1 LCD Mounting Plate
(VESA
™
(VESA™
(VESA
75/100-Compliant)
Screws
4 ea. M4x15
4 ea. M5x15
Bubble Level
2 Round
Washers
2 Lag Bolts
2 Masonry
Anchors
1 Wall Mounting Plate
Allen Wrench
If any parts are missing, please call 800-877-8989.
5
Warnings
Forbidden Actions:
Do not install on a sloping surface. Install
exclusively on a vertical surface.
Do not mount to cabinetry made of particleboard.
Do not install in a room with excessively high
temperatures or high humidity. Install at least
3 ft. from all water sources.
Do not install near an air conditioner.
Do not install in a location where there is excessive
dust, smoke or moisture. These sources can create
a fi re.
Never apply unnecessary stress or load on the
installed unit. Never hang on unit.
Do not install unit alone. Safe installation requires
at least two people.
Do not route your fl atscreen TV’s power cord
in wall. Check local building/electrical codes for
more information.
6
Cautions
To prevent eye fatigue, do not install where
there is direct sunlight or excessive light.
When carrying out maintenance, disconnect
the TV’s power supply to avoid electrical shock.
If planning to route AV cable in wall, only use
cable UL-certifi ed for this use.
