SmartView

™

200M FlatScreen Mount

SmartView 200M is designed to mount

24"

37"

LCD and plasma televisions

to vertical walls. Maximum weight capacity is

100 lbs.

SAFETY WARNING:

If you don’t understand these directions, or have doubts

about this product’s installation, please call a qualiﬁ ed contractor or contact

Monster Cable Products, Inc. at

1-877-800-8989.

Before installing, carefully review the instructions to ensure that no parts are

missing or defective. Improper installation can cause damage or serious injury.

Do not use this product for any purpose not explicitly speciﬁ ed by Monster.

Monster is not liable for damage or injury caused by incorrect assembly,

incorrect mounting or incorrect use.

All hardware is supplied for the following wall conditions:

Wood stud,

brick, solid concrete and concrete block.

Note:

The supplied hardware

is not for walls with steel studs.

If you are uncertain about the nature of your wall construction, consult

an installation contractor.

Speciﬁ cations and Notes:

Monster is constantly striving to improve its products.

Speciﬁ cations are subject to change without notice.



















Required Tools

Wall Stud Mounting:

Electronic stud sensor

Level

Electric hand drill

3/16" drill bit

Phillips screwdriver

Combination wrenches or socket set

Above tools

Replace 3/16" drill bit with 1/2" masonry drill bit

•

Masonry Mounting (brick, concrete, concrete blocks):

Package Contents

1 Wall Plate

2 Vertical

Adjustment Bars

4 Concrete Anchors

1 L-Shaped Locking Bar

If any parts are missing, please call 800-877-8989.

4 Square Washers

4 Round Washers

4 Spacers #1

4 Spacers #2

Screws

4 ea. M4x15/M4x35/M4x45

4 ea. M5x15/M5x35/M5x45

4 ea. M6x15/M6x35/M6x45

4 ea. M8x15/M8x35/M8x45

4 Lag Bolts

1 Bubble Level

Cautions and Warnings

Forbidden Actions:

Do not install on a sloping surface. Install exclusively

on a vertical surface.

Do not install in a room with excessively high temperatures

or high humidity.

Do not install near an air conditioner.

Do not install in a location with excessive dust,

smoke or moisture. These sources can create a ﬁ re.

Do not apply unnecessary stress or load on the installed unit.

Do not install unit alone. Safe installation requires at least

two people.

Do not route your ﬂ atscreen TV’s power cord in wall. Check local

building/electrical codes for more information.

Cautions:

To prevent eye fatigue, do not install where there is direct sunlight

or excessive light.

When carrying out maintenance, disconnect the TV’s power supply

to avoid electrical shock.

If planning to route AV cable in wall, only use cable UL-certiﬁ ed

for this use.
