MSI KT4 Ultra Bedienungsanleitung

KT4 Ultra

Version 1.2

G52-M6590X8

MS-6590 (v1.X) ATX Mainboard

Manual Rev: 1.2

Release Date: November 2002

FCC-B Radio Frequency Interference Statement

This equipment has been tested and found to comply with the limits for a class

B digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the equip-

ment is operated in a commercial environment. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accor-

dance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to

cause harmful interference, in which case the user will be required to correct

the interference at his own expense.

Notice 1

The changes or modifications not expressly approved by the party respon-

sible for compliance could void the user’s authority to operate the equipment.

Notice 2

Shielded interface cables and A.C. power cord, if any, must be used in order to

comply with the emission limits.

VOIR LA NOTICE D’INSTALLATION AVANT DE RACCORDER AU

RESEAU.

Micro-StarInternational MS-6590

Testedtocomply

withFCCStandard

ForHomeorOfficeUse

iii

CopyrightNotice

The material in this document is the intellectual property of MICRO-STAR

INTERNATIONAL. We take every care in the preparation of this document,

but no guarantee is given as to the correctness of its contents. Our products

are under continual improvement and we reserve the right to make changes

without notice.

Trademarks

All trademarks are the properties of their respective owners.

AMD, Athlon™, Athlon™ XP, Thoroughbred™, and Duron™ are registered

trademarks of AMD Corporation.

PS/2 and OS®/2 are registered trademarks of International Business Machines

Corporation.

Windows®95/98/2000/NT/XP are registered trademarks of Microsoft

Corporation.

Netware®is a registered trademark of Novell, Inc.

Award®is a registered trademark of Phoenix Technologies Ltd.

AMI®is a registered trademark of American Megatrends Inc.

Revision History

Revision Revision History Date

V1.0 First release August 2002

V1.1 AddDDR400QualifiedMemory October 2002

Test List; FSB333 Support; SATA

spec update

V1.2 Modify Jumper JBAT1 description November 2002

TechnicalSupport

If a problem arises with your system and no solution can be obtained from the

user’s manual, please contact your place of purchase or local distributor.

Alternatively, please try the following help resources for further guidance.

Visit the MSI website for FAQ, technical guide, BIOS updates, driver

updates, and other information: http://www.msi.com.tw/

Contact our technical staff at: [email protected]

1. Always read the safety instructions carefully.

2. Keep this User’s Manual for future reference.

3. Keep this equipment away from humidity.

4. Lay this equipment on a reliable flat surface before setting it up.

5. The openings on the enclosure are for air convection hence protects the

equipmentfromoverheating. DONOTCOVER THEOPENINGS.

6. Make sure the voltage of the power source and adjust properly 110/220V

before connecting the equipment to the power inlet.

7. Place the power cord such a way that people can not step on it. Do not

place anything over the power cord.

8. Always UnplugthePower Cordbeforeinsertingany add-oncardormodule.

9. All cautions and warnings on the equipment should be noted.

10. Never pour any liquid into the opening that could damage or cause electri-

cal shock.

11. If any of the following situations arises, get the equipment checked by a

service personnel:

zThe power cord or plug is damaged.

zLiquid has penetrated into the equipment.

zThe equipment has been exposed to moisture.

zThe equipment has not work well or you can not get it work according

to User’s Manual.

zThe equipment has dropped and damaged.

zThe equipment has obvious sign of breakage.

12. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

UNCONDITIONED,STORAGETEMPERATUREABOVE600C(1400F),IT

MAYDAMAGETHEEQUIPMENT.

Safety Instructions

CAUTION: Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type recommended by the

manufacturer.

CONTENTS

FCC-B Radio Frequency Interference Statement ..........................................iii

Revision History ........................................................................................... iii

Technical Support ......................................................................................... iii

Safety Instructions ....................................................................................... v

Chapter1.GettingStarted ........................................................................ 1-1

Mainboard Specifications .................................................................... 1-3

Mainboard Layout ...............................................................................1-5

MSI Special Features ...........................................................................1-5

PCAlert™4 ...................................................................................1-5

LiveBIOS™/LiveDriver™ ............................................................1-7

Live Monitor™ ..............................................................................1-7

D-Bracket™2(Optional) ............................................................... 1-9

S-Bracket(Optional) .................................................................... 1-10

MSIDVD(5.1Channel) ............................................................... 1-12

CPU Thermal Protection .............................................................. 1-14

Chapter2.HardwareSetup ....................................................................... 2-1

Quick Components Guide ....................................................................2-3

Central Processing Unit: CPU ..............................................................2-3

CPU Core Speed Derivation Procedure .........................................2-3

CPU Installation Procedures for Socket 462 ..................................2-4

Installing AMD Athlon CPU (Socket 462) Cooler Set ...................2-5

Introduction to DDR SDRAM.......................................................2-6

Memory................................................................................................2-7

DDR DIMM Module Combination ................................................2-7

Installing DDR Modules ...............................................................2-7

ATX 20-Pin Power Connector: JWR1 ............................................2-8

Power Supply .......................................................................................2-9

BackPanel ............................................................................................2-9

Mouse Connector ......................................................................... 2-9

RJ-45LANJack (Optional) .......................................................... 2-10

Keyboard Connector ................................................................... 2-11

USB 2.0 Connectors .................................................................... 2-11

Serial Port Connectors: COM A & COM B.................................. 2-11

Parallel Port Connector: LPT1...................................................... 2-13

Audio Port Connectors ............................................................... 2-13

Connectors......................................................................................... 2-14

Floppy Disk Drive Connector: FDD1........................................... 2-14

Fan Power Connectors: CFAN1/SFAN1/NBFAN1 ...................... 2-15

IrDA Infrared Module Header: JIR1 ............................................ 2-16

Hard Disk Connectors: IDE1 & IDE2 ........................................... 2-17

Hard Disk RAID Connectors: IDE3, SER1 & SER2 (Optional) ..... 2-18

CD-InConnector:JCD1 ............................................................... 2-20

S-Bracket (SPDIF) Connector: JSP3 (Optional)............................ 2-20

IEEE1394Connectors:J1394_0,J1394_1,J1394_2(Optional) ..... 2-22

Front Panel Connectors: JFP1 & JFP2 ......................................... 2-24

Bluetooth Connector: JBT2 (Optional) ........................................ 2-26

Front USB Connectors: JUSB1 .................................................... 2-27

D-Bracket™2Connector: JLED1 (Optional) ............................... 2-28

Jumpers .............................................................................................. 2-29

Clear CMOSJumper: JBAT1 ........................................................ 2-29

Center/Subwoofer Speaker Setting Jumper: ................................ 2-30

J4 & J5 (Optional) ........................................................................ 2-30

Slots ................................................................................................... 2-31

AGP (Accelerated Graphics Port) Slot......................................... 2-31

PCI (Peripheral Component Interconnect) Slots.......................... 2-31

PCI Interrupt Request Routing .................................................... 2-32

Chapter3.BIOS Setup.............................................................................. 3-1

vii

Entering Setup......................................................................................3-3

Selecting the First Boot Device .....................................................3-3

Control Keys ................................................................................. 3-3

Getting Help ..................................................................................3-3

The Main Menu ...................................................................................3-5

Standard CMOS Features ....................................................................3-7

Advanced BIOS Features ....................................................................3-9

Advanced Chipset Features............................................................... 3-13

Power Management Features............................................................. 3-19

PNP/PCI Configurations..................................................................... 3-23

Integrated Peripherals ........................................................................ 3-25

PC Health Status ................................................................................ 3-27

Frequency/Voltage Control ................................................................ 3-29

Set Supervisor/User Password........................................................... 3-31

Load High Performance/BIOS Setup Defaults.................................... 3-31

AppendixA.Using4-or6-ChannelAudioFunction.................................A-1

Installing C-Media Drivers ..................................................................A-2

Hardware Configuration ......................................................................A-3

Software Configuration .......................................................................A-4

Attaching Speakers ......................................................................A-6

Using 4- or 6-Channel Audio Function ...............................................A-6

AppendixB.DDR400/PC3200 MemoryTestreport ...............................B-1

Troubleshooting ........................................................................................ T-1

Glossary ....................................................................................................G-1

1-1

Getting Started

Chapter 1. Getting

Started

Thank you for purchasing KT4 Ultra (MS-6590 v1.X)

ATX mainboard. The KT4 Ultra is based on VIA®Apollo KT400

&VT8235 chipsets and provides six USB 2.0 ports for high-speed

data transmission, C-Media 8738MX chip for 6-channel audio

output, one SPDIF pinheader for digital audio transmission, and

one extra Bluetooth pinheader that fulfills your need for wireless

connection. Designed to fit the advanced AMD®Athlon™,

Athlon™ XP or Duron™ processors, the KT4 Ultra delivers a

high performance and professional desktop platform solution.

Getting Started

1-2

KT3 Ultra2-C ATX MainboardKT4 Ultra ATX Mainboard

Mainboard Specifications

CPU

hSupports Socket A (Socket-462) for AMD®Athlon™/Athlon™ XP /Duron™

processors.

hSupports up to 2800+ or higher speed.

Chipset

hVIA®KT400 chipset

- FSB @200/266/333 MHz.

- Supports DDR200/266/333 and up memory.

-AGP 8X and PCI advanced high performance memory controller.

hVIA®VT8235 chipset

- Dual channel Ultra DMA 66/100/133 master mode EIDE controller.

- ACPI & PC2001 compliant enhanced power management.

- Integrated USB 2.0 controller.

MainMemory

hSupports six memory banks using three 184-pin 200/266/333/400 DDR

SDRAMs.

hSupports up to 3GB memory size.

(Please go to MSI website http://www.msi.com.tw or refer the attached DDR

400 Qualified Memory Test List for details and updated information.)

Slots

hOne AGP (Accelerated Graphics Port) slot.

- Supports AGP 2.0 4x/8x.

hSix 32-bit PCI bus slots (support 3.3v/5v PCI bus interface).

On-Board IDE

hAn IDE controller on the VT8235 chipset provides IDE HDD/CD-ROM with

PIO, Bus Master and Ultra DMA133/100/66 operation modes.

Serial ATA Interface (Optional)

hPromise 20376 controlls 2 Serial ATA ports in 150 MB/s operation mode and

1 Ultra DMA port

On-Board Peripherals

hOn-Board Peripherals include:

- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and

1-3

Getting Started

2.88Mbytes

- 2 serial ports (COM A + COM B)

- 1 parallel port supports SPP/EPP/ECP mode

- 1 IrDA connector for SIR/ASKIR/HPSIR

- 1 audio port

- 6 USB 2.0 ports (Rear * 4/ Front * 2)

Bluetooth (Optional)

h1 extra pinheader for Bluetooth connect connection.

Audio

hC-Media 8738MX 6-channel audio with SPDIF out.

LAN 10/100/1000MBps (Optional)

hBroadcom 4401/5702

- Integrated Gigabit Ethernet MAC and PHY transceiver, auto-negotiation

operation..

- Supports single-port 10MB/s, 100MB/s and 1000MB/s BAST-T application.

- Compliance with PCI v2.2 and LAN on Motherboard (LOM) standard.

BIOS

hThe mainboard BIOS provides “Plug & Play” BIOS which detects the pe-

ripheral devices and expansion cards of the board automatically.

hThe mainboard provides a Desktop Management Interface (DMI) function

which records your mainboard specifications.

hACPI, 1.0a, APM1.2, PnP 1.0a, SMBIOS 2.3, USB 2.0, WFM 2.0, Overclock,

Boot from USB device.

Dimension

hATX Form Factor: 30.5 cm (L) x 23 cm (W).

Mounting

h6 mounting holes.

Others

hSuspend to RAM/Disk (S3/S4).

hPC99, PC2001, WHQL WINXP compliant.

hCPU and Onboard temperature monitoring.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere MSI Hauptplatine Handbücher

MSI

MSI K7D Master-L Bedienungsanleitung

MSI

MSI IA-945GC Bedienungsanleitung

MSI

MSI 925X Neo Platinum Bedienungsanleitung

MSI

MSI P7N SLI PLATINUM - Motherboard - ATX Bedienungsanleitung

MSI

MSI MS-6188 Bedienungsanleitung

MSI

MSI 848P Neo-S Bedienungsanleitung

MSI

MSI E350DM-E33 series Bedienungsanleitung

MSI

MSI Z68A-GD80 G3 series Bedienungsanleitung

MSI

MSI MS-98E6 Bedienungsanleitung

MSI

MSI Fuzzy 945GME1 Series Gebrauchsanweisung

MSI

MSI H6Ma-P35 (B3) Bedienungsanleitung

MSI

MSI X370 GAMING PRO CARBON Bedienungsanleitung

MSI

MSI MS-9803 Bedienungsanleitung

MSI

MSI 945GCM5 Series Bedienungsanleitung

MSI

MSI MS-5184 Bedienungsanleitung

MSI

MSI P6NGM series Bedienungsanleitung

MSI

MSI H370 GAMING PLUS Bedienungsanleitung

MSI

MSI H57M-ED65 Series Bedienungsanleitung

MSI

MSI MS-6382 Bedienungsanleitung

MSI

MSI MICRO NLX BX4 Bedienungsanleitung

MSI

MSI 970A-G43 Series Bedienungsanleitung

MSI

MSI K8MM2 Bedienungsanleitung

MSI

MSI MS-6747 Bedienungsanleitung

MSI

MSI 648 Max Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
