neabot NoMo N2 Bedienungsanleitung
Neabot NoMo N2 Robot Vacuum
USER GUIDE
英
GUIDE DE L'UTILISATEUR
BENUTZERHANDBUCH
FR
DE
ユーザーガイド
JP
使用説明
繁
ユーザーガイド
Benutzerhandbuch
•Safety Information
•Package Includes
•About Your Robot Vacuum and Mop
•About Your Self-Emptying Dustbin
•LED Indicator
•Get Started
•Trouble Shooting
•Customer Support
•Care and Maintenance
•Warranty
1-2
3
4-6
7
8
9-13
14-16
17
17-23
24-25
User Guide
Guide de l'utilisateur
• Informations sur la sécurité
• Le forfait comprend
• À propos de votre robot aspirateur et vadrouille
• À propos de votre poubelle à vidange automatique
• Indicateur LED
• Démarrez
• Service clientèle
• Entretien et maintenance
• Garantie
26-27
28
29-31
32
33
34-41
42
42-48
49-50
• Sicherheitsinformationen
• Das Paket enthält
• Über Ihren Saugroboter und Mopp
• Über Ihren selbstentleerenden Staubbehälter
• LED-Anzeige
• Beginnen
• Fehlerbehebung
• Kunden-Support
• Pflege und Wartung
• Garantie
51-52
53
54-56
57
58
59-63
64-66
67
67-73
74-75
• 安全情報
• パッケージ内容
• ロボット掃除機・モップについて
• 自動ゴミ収集ボックスについて
• LEDインジケーター
• 掃除開始
• トラブルシューティング
• カスタマーサポート
• ケアとメンテナンス
• 保証
76-77
78
79-81
82
83
84-88
89-91
92
92-98
99-100
使用說明
• 使用說明
• 產品配件
• 關於您的掃地機器人
• 關於您的集塵堡
• 指示燈
• 使用說明
• 故障排除
• 售後服務
• 保修
101-102
103
104-106
107
108
109-113
114-116
117-123
124-125
Safety Information
General Warning
• Your robot is not a toy. Small children and pets should be supervised when your robot is operating.
• Do not sit or stand on your robot or charging station.
• Do not use unauthorized chargers. Use of an unauthorized charger could cause the battery to
generate heat, smoke, catch fire, or explode.
• Your robot comes with a region approved power supply cord and is designed to be plugged into a
standard household AC power outlet only. Do not use any other power supply cord. For replacement
cords, please contact Customer Support to ensure proper selection of country specific power supply cord.
• Do not open your robot or charging station. There are no user serviceable parts inside.Refer servicing to
qualified service personnel.
• Risk of electric shock, use indoors in dry location only.
• Do not handle your robot or charging station with wet hands.
• Store and operate your robot in room temperature environments only.
• If the room to be cleaned contains a balcony, a physical barrier should be used to prevent access
to the balcony and ensure safe operation.
1
Safety Information
2
Battery & Charging Warnings
• Do not use a charging station with a damaged cord or plug. If the cord or plug is damaged, it must be replaced.
• Always disconnect your robot from the charging station before maintenance.
• Charge your robot only with the power supply provided. The provided power supply delivers safety extra low
voltage corresponding to the input marking on the robot which is required to maintain safe operation.
• Do not open, crush, heat above 176°F/80°C, or incinerate. Follow manufacturer’s instructions.
• Do not short-circuit the battery by allowing metal objects to contact battery terminals or immerse in liquid.
• Do not subject batteries to mechanical shock.
Cautions
• Do not operate the robot in areas with exposed electrical outlets in the floor.
• If the device passes over a power cord and drags it, there is a chance an object could be pulled off a table or
shelf. Before using this device, pick up objects like clothing, loose papers, pull cords for blinds or curtains, power
cords, and any fragile objects.
• Be aware that the robot moves on its own. Take care when walking in the area that the robot is operating in to
avoid stepping on it.
• Do not use this device to pick up sharp objects, glass, or anything that is burning or smoking.
Disposable Mop Cloth*10
HEPA*1
Package Includes
3
Self-Emptying Dustbin*1
Cleaning Brush*1
（Place under the self-emptying dustbin lid）
Mop Cloth Support*1 Mop Cloth*2
Dust Bag*2
Robot Vacuum and Mop*1
User Guide*1
Accessories
Note: If you find something missing in your package, please contact customer support via [email protected] in time.
Side Brush*2
Long press the buttons and for 3
seconds to enter the network
configuration.
About Your Robot Vacuum and Mop
4
Recharge/Spot Cleaning
Short press to start the recharge.
Press and hold for 3 seconds to start the
spot cleaning.
Infrared sensor
Bumper
Recharge button/indicator
Power button/indicator
Anti-collision strip
Lidar
On and Off/Cleaning All
Short press to start/pause the clean all.
Press and hold for 3 seconds to turn the
machine on or off.
Note: During recharging, spot
cleaning or cleaning all, short press any
button to pause the machine.
Front View
Network Configuration
About Your Robot Vacuum and Mop
5
Mop cloth assembly
Main brush
Side drive wheel
Side brush
Cliff sensor
Main brush cover
Side drive wheel
Battery
Cliff sensor
Caster
Bottom View
About Your Robot Vacuum and Mop
6
Charging electrode tip
Reset button
Short press to restart.
Press and hold for 3 seconds to
restore the factory settings.
Wall-mounted TOF sensor
Dustbin release button
Side View
Two-in-one Water Tank
Water inlet
Water tank
Dustbin
Dustbin release button
Dustbin buckle
Mop cloth bracket
Mop Cloth
HEPA filter
Filter sponge
