NEC MultiSync P750 Bedienungsanleitung

MultiSync P750

User’s Manual

Declaration of the Importer

We hereby certify that the color monitors

MultiSync P750 JC-1744UMB

are in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 60555-2

- EN 60555-3

- EN 50082-1

(IEC 801-2)

(IEC 801-3)

(IEC 801-4)

and marked with

NEC Europe Ltd. Ismaning Office

Steinheilstraße 4-6

D-85737 Ismaning, Germany

Safety Instruction

Caution:

When operating the JC-1744UMB with a 220-240V AC power source

in Europe except UK, use the power cord provided with the monitor.

In UK, a BS approved power cord with moulded plug has a Black (five

Amps) fuse installed for use with this equipment. If a power cord is not

supplied with this equipment please contact your supplier.

When operating the JC-1744UMR with a 220-240V AC Power source

in Australia, use the power cord provided with the monitor.

For all other cases, use a power cord that matches the AC voltage of the

power outlet and has been approved by and complies with the safety

standard of your particular country.

IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of

International Business Machines Corporation.

Apple and Macintosh are registered trademarks of Apple Computer Inc.

Microsoft and Windows are registered trademarks of the Microsoft Corporation.

NEC is a registered trademark of NEC Corporation. ErgoDesign, IPM, OSM, ColorControl,

OptiClear, CROMACLEAR and Advanced Digital Control System are trademarks of NEC Home

Electronics, Ltd.

MultiSync is a registered trademark of NEC Technologies, Inc in U.S., and of NEC Home

Electronics, Ltd in Canada, U.K., Germany, France, Spain, Italy, Austria, Benelux,

Switzerland, Denmark, Finland, Norway and Saudi Arabia.

All other trademarks or registered trademarks are property of their respective owners.

English

Deutsch

Français

Italiano

Español

Appendix

English

Introduction

Congratulations on your purchase of the MultiSync P750 colour Monitor!

The MultiSync P750 monitor includes the CROMACLEAR CRT,

Microsoft’s Plug and Play, NEC’s ErgoDesign properties, the On

Screen Manager (OSM), as well as all the unique features you expect

from MultiSync Monitors.

The MultiSync technology provides you with automatic compatibility

with multiple operating platforms and a vast array of graphics standards

allowing resolution upgrades without upgrading the monitor.

The MultiSync P750 monitor strictly follows ErgoDesign guidelines

featuring enhanced human ergonomics (human and earth condition).

The goal of ErgoDesign is to maximise the comfort and productivity of

the end user. ErgoDesign parallels the strict European standards of

power management and reduced emissions. In addition our monitor is

designed to be recyclable.

CROMACLEAR CRT Technology

The MultiSync P750 monitor features NEC’s exclusive CROMACLEAR

CRT (Cathode Ray Tube), the latest advancement in display technology.

This technology, patented by NEC, delivers images with more clarity

than found in traditional dot-trio CRTs. Unlike the conventional shadow

mask with phosphor dots, CROMACLEAR CRT has ellipse-shaped

phosphors. Screen images have higher definition, color saturation and

more depth and dimension.

The CROMACLEAR CRT has Dynamic Beam Focus which provides

precise and continuous focus adjustment of the electron beams.

Dynamic beam focus provides optimum image quality, even to the far

edges of the screen. You will notice a significant difference in the focus

and clarity of the image for realistic text, graphics and video.

The OptiClear Surface of the P750 CRT dramatically reduces the

reflection of ambient illumination and glare resulting in greatly

improved user comfort and productivity. This multilayered screen

coating increases the contrast without sacrificing the focus level, clarity

or brightness.

Introduction E - 1

A high contrast screen with a .25 mm mask pitch sharpens image clarity

and enhances detail. On-screen information is easier to read.

The flat square CRT technology reduces image distortion and glare.

Plug and Play

Plug and Play is the new Microsoft®solution with Windows®95 to

provide automatic peripheral connections without confusing and

time-consuming setup. When used with a Plug and Play compatible system

and video card, the MultiSync P750 monitor automatically tells the system

its identification and capabilities. The system will then select its highest

resolution and refresh rate to take advantage of your MultiSync monitor.

D-SUB/BNC Selection

Up-front BNC/D-SUB Selection Button on the monitors allows you to

connect two systems to one MultiSync P750 monitor. This front panel

button allows you to select a system. Use the MultiCable with the

D-Sub connector to display the video of one system, and use the BNC

inputs to display the video of another system. Using the same P750

monitor, you can easily select either one of the systems by simply

pushing the BNC/D-SUB Button.

ErgoDesign

The MultiSync ErgoDesign features enhance human ergonomics

(human and earth conditions). MultiSync monitor’s ErgoDesign will

improve the working environment, protect the health of the user and

save money. ErgoDesign parallels the strict European standards of

power management and reduced emissions:

–automatic display power-down (also known as NUTEK

specification 803299)

–emission characteristics (stricter than those referred to as

reduced electromagnetic fields as recommended by MPR II

and, for JC-1744UMB, also by TCO)

–safety (EN 60950)

E - 2 Introduction

MultiSync monitors comply with these standards by offering IPM

System power management and Reduced Magnetic Field technology.

Power Manager

IPM (Intelligent Power Manager) System is an innovative power-saving

utility that complies with both the EPA’s Energy Star requirements and

Europe’s TCO NUTEK’s power management requirements. Energy Star

products use less than 30 watts when in the main power saving mode. The

NUTEK specification 803299 requires automatic power down to less than

30 watts in the suspend mode and less than 8 watts in the off mode.

When in the maximum power-down mode, the MultiSync P750 monitor

will consume approximately 10% of the total power drawn under

normal operation. This innovation adds up to 90% energy savings,

longer monitor life, environmental protection, reduced emissions and

reduced air conditioning costs of the work environment. The IPM

System increases the monitor’s life and saves energy and costs by

powering down when not in use.

MultiSync monitors follow the Video Electronics Standard Association

(VESA) approved DPMS power-down signalling method. VESA’s

Display Power Management Signalling (DPMS) method, which is

endorsed by the EPA, is the power-down process a system should use to

communicate to the monitor to save power. Power-down functions can

be utilised only with an Energy Star system or video card which adheres

to the VESA DPMS standard. By using the monitor’s horizontal and

vertical SYNC signals, the monitor can be prompted into the different

IPM modes. The following is the description of the LED indicator for

the IPM power-saving modes:

Introduction E - 3

Mode LED Indicator Power Saving

On Green None

Stand By Green Minimum (Quickest Recovery)

Suspend Yellow Moderate (< 20 Watts, Moderate

Recovery)

Off (IPM Mode) Orange Maximum (< 5 Watts, Slow Recovery)

Off (Power

Switch, Off) No Light No Power Used (Fully Off)

Reduced Emissions

The P750 monitor incorporates Reduced Magnetic Field technology designed

to reduce magnetic and alternating electric field emissions and static

electricity. NEC’s monitors follow the strictest magnetic field, alternating

electric field, and electrostatic recommendations of the Swedish Board for

Technical Accreditation, or SWEDAC (previously known as MPR, National

Board for Measurement and Testing). The JC-1744UMB follow the

recommendations of the TCO which specify maximum recommended values

of electric and magnetic fields.

Multiple Frequency Technology

Multiple Frequency Technology automatically adjusts the monitor to the

video card’s scanning frequency, displaying the resolution you desire. The

MultiSync P750 color monitor also supports multiple operating platforms

such as PC compatible, Macintosh family and workstation systems.

Increased refresh rates at all resolutions provide a flicker-free image.

The clearer image is easier on your eyes and extends your viewing time.

A wide range of graphics standards of PC and Macintosh computers,

including VESA standards, is supported by the MultiSync P750 color

monitor including:

E - 4 Introduction

–640 x 480: 60 - 160 Hz vertical refresh

–800 x 600: 55 - 145 Hz vertical refresh

–832 x 624: 55 - 140 Hz vertical refresh

–1024 x 768: 55 - 115 Hz vertical refresh

–1152 x 870: 55 - 100 Hz vertical refresh

–1280 x 1024: 55 - 85 Hz vertical refresh (non-interlaced, 85 Hz

recommended)*

–1600 x 1200: 55 - 75 Hz vertical refresh (non-interlaced)**

* NEC cites recommended resolutions for optimal display performance

** Maximum resolution based on horizontal and vertical frequencies only.

NOTE: Some system may not support all modes listed.

Horizontal and vertical FullScan capability can increase the display size

of a variety of video modes to the edges of the monitor bezel. The

FullScan capability allows you to use the entire screen area in most

resolutions, significantly expanding image size.

Introduction E - 5
