Neilsen CT4694 Bedienungsanleitung
SPECIFICATIONS
Max. pressure 8 Bar (116 PSI)
Working pressure: 6 - 8 Bar (90 -116 PSI)
Air inlet:1/4"
Air pressure: filtered and free of condensation
Dear Customer, before using this Air Sand Blaster it is necessary to study the operation manual
carefully. Thank you.
GENERAL
The air sandblasting gun is ideal for many applications in the car body area and all metallic surfaces.
The sandblasting gun is used for removal of rust, excessive dirt, coatings, etc., and is suitable for
using with normal corundum with a grain size of 46 to 100.
The compressed air sandblasting gun is easy to use, has a lower consumption by reusing the grain.
DESCRIPTION
Scope of delivery
1 Air sand blasting gun
2 Blasting catcher
3 Blasting sand
4 Point blasting cap
5 Surface blasting cap
6 Blasting cap for outside corners
7 Blasting cap for inside corners
Parts of Air Sand Blasting Gun
1 Trigger
2 Aluminum grit container
3 Riser
4 Nozzle
5 Blasting catcher
6 Blasting cap
7 Air inlet
AIR SAND BLASTER GUN KIT CT4694
SAFETY NOTES
1. When working with the sand blasting gun, always wear gloves, safety glasses, hearing protection
and a dust mask.
2. Always wear tight-fitting protective clothing.
3. Store pneumatic tools out of children's reach.
4. Do not use the sand blasting gun in hazardous locations.
5. Do not align the sandblasting gun on another person.
6. Disconnect the machine while making maintenance, repair work and when not in use.
7. The sandblasting gun should not be used near electrical , there is a danger of electrical shock.
8. Be sure that the maximum operating pressure do not exceed 8.0 bar, before using the tool.
9. Please check before using that any hose connection is firmly seated.
10. Disconnect the machine only at zero pressure. Air hoses which hitting around can cause serious
injury.
11. Never carry the tool by the hose.
12. Use the sand blasting gun only for the application which described under "General".
APPLICATION
1. Prepare the work area. All the components are not
sandblasted must be covered. This is especially true for
painted surfaces, engines, transmission parts and other
machines and their components. The finest sand blasting
particles can cause significant damage !
2. Mount the blasting catcher (Fig.1).
3. Screwing the quick coupling fitting into the compressed air
supply thread.
4. Make sure that the operating lever (trigger) (1) s free-
moving and is in the off position (Fig.2).
5. Connect the required sand blast cap (4, 5, 6 or 7) to the
blasting gun (Fig.3)
6. Fill the aluminum container (2) to 3/4 with grit (Fig.4).
7. Meet safety measures such as put on safety glasses, dust
mask, ear protection and gloves.
8. Connect the sandblasting gun to compressed air. Note:
Maximum working pressure must not be exceeded.
9. Put the sand blasting gun on surface and push the
operating lever (Fig.5).
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
EC DECLARATION OF CONFORMITY
We CANNON TOOLS LTD
20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K.
Declare that the following machine complies with the appropriate basic safety
and health requirements of the EC Directive based on its design and type, as
brought into circulation by us.
In case of alteration of the machine, not agreed upon by us, this declaration
will lose its validity.
Product description: AIR SAND BLASTER GUN KIT
Model: CT4694
Applicable EC Directives:
EC Machinery Directive 2006/42/EC
20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
Mr. Gurcharan Tony Singh Sanghera
Managing Director
CANNON TOOLS LTD
2017-12-15
