Netvox RA08B Series Bedienungsanleitung

Wireless Multifunction CO2Sensor

RA08B Series

Wireless Multifunction CO2Sensor

RA08B Series

User Manual

This document contains proprietary technical information which is the property of NETVOX Technology. It shall be maintained in strict

confidence and shall not be disclosed to other parties, in whole or in part, without written permission of NETVOX Technology. The

specifications are subject to change without prior notice.




Table of Contents

Introduction ................................................................................3
Appearance.................................................................................3
Features ......................................................................................4
Set-up Instruction .......................................................................4
1 On/Off..................................................................................4
2 Network Joining...................................................................4
3 Function Key........................................................................5
4 Sleeping Mode.....................................................................5
5 Low Voltage Warning...........................................................5
Data Report.................................................................................6
1 Example of ReportDataCmd................................................7
2 Example of ConfigureCmd ................................................10
3 ReadBackUpData...............................................................12
4 Example of GlobalCalibrateCmd.......................................13
5 Set/GetSensorAlarmThresholdCmd...................................14
Installation................................................................................15
Safety Guide.............................................................................16


1. Introduction

RA08B series is a Class A device based on LoRaWan open protocol. It could be used for temperature, CO2, PIR, air pressure,

illuminance, and TVOC detection. Data collected by sensors would be shown on the E-ink display. Users are able to know the data

through one quick peek.

RA08B series and sensors configuration:

Sensor

Model

Sensor

Note

T/H

TVOC

Light

Pressure

PIR

CO2

1. Weather monitoring: humidity/illuminance/pressure sensor

2. Air quality detection: TVOC/CO2 sensor

3. PIR + E-ink display (refresh data as people pass by)

RA08B01

Standard (support 6 sensors)

RA08B02

Simple (Energy-saving.)

(report 2 less payloads than standard configuration)

LoRa Wireless Technology:

LoRa is a wireless communication technology that adopts techniques such as long-distance communication and low power

consumption. Compared with other communication methods, LoRa spread-spectrum modulation techniques greatly expand the

communication distance. It is used in long-distance and low-data wireless communications like automatic meter reading, building

automation equipment, wireless security systems, and industrial monitoring control system. The features include small size, low power

consumption, long transmission distance, and anti-interference ability.

LoRaWAN:

LoRaWan built LoRa’s end-to-end standards and techniques, ensuring interoperability between devices and gateways from different

manufacturers.

2. Appearance

RA08B01

3. Features

⚫Temperature/Humidity, CO2, PIR, air pressure, illuminance, and TVOC detection

⚫SX1276 wireless communication module

⚫4 ER14505 battery in parallel (AA size3.6V for each battery)

⚫Compatible with LoRaWANTM Class A device

⚫Frequency hopping spread spectrum

⚫Reading data and setting alarms on SMS or email by configuring parameters through third-party platforms (optional)

⚫Support third-party platforms: Actility/ThingPark, TTN, MyDevices/Cayenne

⚫Low-power design for longer battery life

Note: Please refer to http://www.netvox.com.tw/electric/electric_calc.html for battery life calculation and other detailed information

4. Set-up Instruction

4.1 On/Off

Power on

Insert batteries. (Users may need a screwdriver to open battery cover.)

Turn on

Press and hold the function key for 3 seconds until the green indicator flashes.

Turn off

Press and hold the function key for 5 seconds until green indicator flashes once.

Then release the function key. The device will automatically shut down after the indicator flashes 10

times.

Reset to factory setting

Press and hold the function key for 10 seconds until green indicator flashes fast for 20 times.

The device will reset to factory setting and automatically shut down.

Power off

Remove Batteries.

Note

1. When user removes and inserts the battery; the device should be off by default.

2. 5 seconds after power on, the device will be in engineering test mode

3. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor inductance

and other energy storage components.

4.2 Network Joining

Never joined the network

Turn on the device to search the network to join.

The green indicator stays on for 5 seconds: Success

The green indicator remains off: Fail

Had joined the network

(without factory resetting)

Turn on the device to search the previous network to join.

The green indicator stays on for 5 seconds: Success

The green indicator remains off: Fail

Fail to join the network

Note:

1. To save energy, the battery should be removed when the device is not in use.

2. User is recommended to check the device verification information on the gateway or consult your

platform server provider.

4.3 Function Key

Press and hold for 5

seconds

Turn off

Long press the function key for 5 seconds and the green indicator flashes once.

Release the function key and the green indicator flashes 10 times.

The green indicator remains off: Fail

Press and hold for 10

seconds

Reset to factory setting / Turn off

The green indicator flashes 20 times: Success

Long press the function key for 5 seconds the green indicator flash once.

Keep pressing the function key for more than 10 seconds, the green indicator flashes 20 times.

The green indicator remains off: Fail

Short press

The device is in the network: green indicator flashes once, screen refreshes once, and send a data report

The device is not in the network: screen refreshes once and the green indicator remains off

4.4 Sleeping Mode

The device is on and in the

network

Sleeping period: Min Interval.

When the reportchange exceeds the setting value or the state changes, the device will send a data report

based on the Min Interval.

The device is on but not in

the network

Note:

1. The battery should be removed when the device is not in use.

2. User is recommended to check the device verification information on the gateway

4.5 Low Voltage Warning

Low Voltage

3.2 V

5. Data Report

After power on, the device would refresh the information on the screen and send a version packet report along with an uplink packet.

Note: 1. The interval of data packets would be 10 seconds by default. When the ack = 0x01, the intervals would be 30 seconds.

2. Two hours after power on, the data sent by devices with TVOC sensors are for reference only. If the data is way higher or

below the setting, the device should be placed in the environment with fresh air in 24 to 48 hours until the data is back to

normal value.

3. The device sends data based on the default configuration before any configuration is done. Please do not send commands

without turning on the device.

Max Interval: 0x708 (1800s)

Min Interval: 0x708 (1800s) Note: the Max and Min Interval shall not be less than 1 minute.

Data collecting and transmission:

Join the network: press the function key (indicator flashes once) / trigger PIR, read data, refresh screen, report detected data (based on

the report interval)

Without joining the network: press the function key / trigger PIR to get data and refresh the information on the screen.

The information shown on the E-ink display:

FFFF of reported data and “—” on the screen means the sensors are turning on, disconnection, and errors of sensors.

The information shown on the screen is based on user’s choice of sensor. It would be refreshed by pressing the function key, triggering

the PIR, or refreshed based on the report interval.

Note: 1. Fluctuation of CO2 data caused by delivery and storage time could be calibrated. Please refer to 5.2 Example of

ConfigureCmd for detailed information.

2. TVOC level

Very good

< 150 ppm

Good

150-500 ppm

Medium

500-1500 ppm

Poor

1500-5000 ppm

Bad

> 5000 ppm

3. Please refer Netvox LoRaWAN Application Command document and Netvox Lora Command Resolver

http://www.netvox.com.cn:8888/cmddoc to resolve uplink data.

Data report configuration and sending period are as follows:

Min. Interval

(Unit: second)

Max. Interval

(Unit: second)

Detection Interval

Report Interval

180 to 65535

MinTime

Exceed the setting value: report based on the

MinTime or the MaxTime interval

5.1 Example of ReportDataCmd

Fport: 0x06

Bytes

1 Byte

Var (Fix = 8 Bytes)

Version

DevieType

ReportType

NetvoxPayLoadData

Version–1 bytes –0x01——the Version of NetvoxLoRaWAN Application Command Version

DeviceType–1 byte –Device Type of Device

The devicetype is listed in Netvox LoRaWAN Application Devicetype V1.9.doc

ReportType –1 byte–the Presention of the NetvoxPayLoadData，according the devicetype

NetvoxPayLoadData–Fixed bytes (Fixed =8bytes)

Tips

1. Battery Voltage:

The voltage value is bit 0 ~ bit 6, bit 7=0 is normal voltage, and bit 7=1 is low voltage.

Battery=0xA0, binary=1010 0000, if bit 7= 1, it means low voltage.

The actual voltage is 0010 0000 = 0x20 = 32, 32*0.1v =3.2v

2. Version Packet:

When Report Type=0x00 is the version packet, such as 01A0000A01202307030000, the firmware version is 2023.07.03.

3. Data Packet:

When Report Type=0x01 is data packet.

(If the device data exceeds 11 bytes or there are shared data packets, the Report Type will have different values.)

4. Signed Value:

When the temperature is negative, 2's complement should be calculated.

Device

Type

Report

Type

NetvoxPayLoadData

RA08B

0x A0

0x01

Battery

(1Byte, unit:0.1V)

Temperature

(Signed2Bytes,

unit:0.01°C)

Humidity

(2Bytes,

unit:0.01%)

CO2

(2Byte, 1ppm)

Occupy

(1Byte 0:Un Occupy

1: Occupy)

0x02

Battery

(1Byte, unit:0.1V)

AirPressure

(4Bytes,unit:0.01hPa)

illuminance (3Bytes,unit:1Lux)

0x03

Battery (1Byte,

unit:0.1V)

PM2.5(2Bytes,Unit:1 ug/m3)

PM10 (2Bytes,

Unit: 1ug/m3)

TVOC

(3Bytes,Unit:1ppb)

0x05

Battery(1Byte,

unit:0.1V)

ThresholdAlarm(4Bytes,

Bit0:TemperatureHighThresholdAlarm,

Bit1: TemperatureLowThresholdAlarm,

Bit2:HumidityHighThresholdAlarm,

Bit3: HumidityLowThresholdAlarm,

Bit4:CO2HighThresholdAlarm,

Bit5:CO2LowThresholdAlarm,

Bit6: AirPressure HighThresholdAlarm,

Bit7: AirPressure LowThresholdAlarm,

Bit8: illuminanceHighThresholdAlarm,

Bit9: illuminanceLowThresholdAlarm,

Bit10: PM2.5HighThresholdAlarm,

Bit11: PM2.5LowThresholdAlarm,

Bit12: PM10HighThresholdAlarm,

Bit13: PM10LowThresholdAlarm,

Bit14: TVOCHighThresholdAlarm,

Bit15: TVOCLowThresholdAlarm,

Bit16: HCHOHighThresholdAlarm,

Bit17: HCHOLowThresholdAlarm,

Bit18:O3HighThresholdAlarm,

Bit19: O3LowThresholdAlarm,

Bit20:COHighThresholdAlarm,

Bit21: COLowThresholdAlarm,

Bit22-31:Reserved)

Reserved

(3Byte,fixed 0x00)

Uplink: Data #1 01A0019F097A151F020C01

1st byte (01): Version

2nd byte(A0): DeviceType 0xA0 －RA08B Series

3rd byte (01): ReportType

4th byte(9F): Battery－3.1V (Low Voltage) Battery=0x9F, binary=1001 1111, if bit 7= 1, it means low voltage.

The actual voltage is 0001 1111 = 0x1F = 31, 31*0.1v =3.1v

5th 6th byte(097A): Temperature－24.26℃, 97A (Hex)= 2426 (Dec), 2426*0.01℃= 24.26℃

7th 8th byte(151F): Humidity－54.07%, 151F (Hex) = 5407 (Dec), 5407*0.01% = 54.07%

9th 10th byte(020C): CO2－524ppm , 020C (Hex) = 524 (Dec), 524*1ppm = 524

11th byte(01): Occupy－1

Data #2 01A0029F0001870F000032

1st byte (01): Version

2nd byte(A0): DeviceType 0xA0 －RA08B Series

3rd byte (02): ReportType

4th byte(9F): Battery－3.1V (Low Voltage) Battery=0x9F, binary=1001 1111, if bit 7= 1, it means low voltage.

The actual voltage is 0001 1111 = 0x1F = 31, 31*0.1v =3.1v

5th-8th byte(0001870F): AirPressure－1001.11hPa, 001870F (Hex) = 100111 (Dec), 100111*0.01hPa = 1001.11hPa

9th-11th byte(000032): illuminance－50Lux, 000032 (Hex) = 50 (Dec), 50*1Lux = 50Lux

Data #3 01A0039FFFFFFFFF000007

1st byte (01): Version

2nd byte(A0): DeviceType 0xA0 －RA08B Series

3rd byte (03): ReportType

4th byte(9F): Battery－3.1V (Low Voltage) Battery=0x9F, binary=1001 1111, if bit 7= 1, it means low voltage.

The actual voltage is 0001 1111 = 0x1F = 31, 31*0.1v =3.1V

5th-6th (FFFF): PM2.5－0xFFFF, FFFF(HEX) = -1(DEC), -1 * 1ug/m3 = -1ug/m3

7th-8th byte(FFFF): PM10－0Xffff, FFFF(HEX) = -1(DEC), -1 * 1ug/m3 = -1ug/m3

9th-11th byte(000007): TVOC－7ppb, 000007 (Hex) = 7 (Dec), 7*1ppb = 7ppb

Data #5 01A0059F00000001000000

1st byte (01): Version

2nd byte(A0): DeviceType 0xA0 －RA08B Series

3rd byte (05): ReportType

4th byte(9F): Battery－3.1V (Low Voltage) Battery=0x9F, binary=1001 1111, if bit 7= 1, it means low voltage.

The actual voltage is 0001 1111 = 0x1F = 31, 31*0.1v =3.1v

5th-8th (00000001): ThresholdAlarm－1 (HEX) = 1 (DEC), 1&00000001 = 1 (temperature_high_threshold_alarm)

9th-11th byte(000000): Reserved

Note: F refers to unsupported detection item or errors

5.2 Example of ConfigureCmd

FPort: 0x07

Description

Device

CmdID

DeviceType

NetvoxPayLoadData

ConfigReport

Req

RA08B

0x01

0xA0

MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

Reserved

(2Bytes,Fixed 0x00)

ConfigReport

Rsp

0x81

Status

(0x00_suA0ess)

Reserved (8Bytes,Fixed 0x00)

ReadConfigR

eportReq

0x02

Reserved (9Bytes,Fixed 0x00)

ReadConfigR

eportRsp

0x82

MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

Reserved

(2Bytes,Fixed 0x00)

CalibrateCO2

Req

0x03

CalibrateType (1Byte,

0x01_TargetCalibrate,

0x02_ZeroCalibrate,

0x03_BackgroudCalibrate,

0x04_ABCCalibrate)

CalibratePoint

(2Bytes,Unit:1ppm)

Only valid in

targetCalibrateType

Reserved

(6Bytes,Fixed 0x00)

CalibrateCO2

Rsp

0x83

Status

(0x00_suA0ess)

Reserved (8Bytes,Fixed 0x00)

SetIRDisable

TImeReq

0x04

IRDisableTime

(2bytes Unit:s)

IRDectionTime

(2bytes Unit:s)

Reserved

(5Bytes,Fixed 0x00)

SetIRDisable

TImeRsp

0x84

Status (0x00_success)

Reserved (8Bytes,Fixed 0x00)

GetIRDisable

TImeReq

0x05

Reserved (9Bytes,Fixed 0x00)

GetIRDisable

TImeRsp

0x85

IRDisableTime

(2bytes Unit:s)

IRDectionTime

(2bytes Unit:s)

Reserved

(5Bytes,Fixed 0x00)

(1) Configure device parameters

MinTime = 1800s (0x0708), MaxTime = 1800s (0x0708)

Downlink: 01A0070807080000000000

Response:

81A0000000000000000000 (Configuration success)

81A0010000000000000000 (Configuration failure)

(2) Read device configuration parameters

Downlink: 02A0000000000000000000

Response: 82A0070807080000000000 (Current configuration)

Andere Handbücher für RA08B Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere netvox Sicherheitssensor Handbücher

netvox

netvox RA02A Bedienungsanleitung

netvox

netvox R311A Bedienungsanleitung

netvox

netvox R313WA Bedienungsanleitung

netvox

netvox R718WBA Bedienungsanleitung

netvox

netvox R313A Bedienungsanleitung

netvox

netvox R313CB Bedienungsanleitung

netvox

netvox R311CB Bedienungsanleitung

netvox

netvox RA08D Series Bedienungsanleitung

netvox

netvox R718PA9 Bedienungsanleitung

netvox

netvox R718B Bedienungsanleitung

netvox

netvox R718B Bedienungsanleitung

netvox

netvox R719A Bedienungsanleitung

netvox

netvox R313FA Bedienungsanleitung

netvox

netvox R311W Bedienungsanleitung

netvox

netvox R718WB2 Bedienungsanleitung

netvox

netvox R718B2 Bedienungsanleitung

netvox

netvox ZB11C Bedienungsanleitung

netvox

netvox RA0708 Bedienungsanleitung

netvox

netvox R313LA Bedienungsanleitung

netvox

netvox R718WB2 Bedienungsanleitung

netvox

netvox R718WAA Bedienungsanleitung

netvox

netvox R313FC Bedienungsanleitung

netvox

netvox R313W Bedienungsanleitung

netvox

netvox Z801TXB Bedienungsanleitung

Beliebte Sicherheitssensor Handbücher anderer Marken

THORLABS

THORLABS PDA10JT Bedienungsanleitung

Waeco

Waeco UV-DETECT Bedienungsanleitung

Intermatic

Intermatic IOS-DSIMF Bedienungsanleitung

urmet domus

urmet domus 1083 Bedienungsanleitung

Siemens

Siemens AZL66 Series Bedienungsanleitung

BTI

BTI Profiline Multi Finder Bedienungsanleitung

Challenger

Challenger SL01 Bedienungsanleitung

DMP Electronics

DMP Electronics 1122INT Bedienungsanleitung

Rielta

Rielta Ladoga MK-RK Bedienungsanleitung

Mirion Technologies

Mirion Technologies ACCURAD PRD Bedienungsanleitung

Bosch

Bosch DS835 Bedienungsanleitung

DBI SALA

DBI SALA EZ Stop Bedienerhandbuch

Lamptime

Lamptime ST05C Bedienungsanleitung

Ubiquiti

Ubiquiti MFI-MSC Bedienungsanleitung

Subsite

Subsite 910R Montageanleitung

Satel

Satel OPAL Pro Bedienungsanleitung

Aleph

Aleph XC-1XTEU Bedienungsanleitung

Pima

Pima LARIS QUAD Bedienungsanleitung

netvox RA08B Series Bedienungsanleitung

Beliebte Sicherheitssensor Handbücher anderer Marken
