Network Technologies SPLITMUX-DVI-4 Bedienungsanleitung
MAN093 Rev Date 12-1-11
SPLITMUX-DVI-4
Quad Screen Video Splitter
Installation and Operation Manual
SPLITMUX®Series
i
TRADEMARK
SPLITMUX is a registered trademark of Network Technologies Inc in the U.S. and other countries.
COPYRIGHT
Copyright © 2007, 2011 by Network Technologies Inc. All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner
Drive, Aurora, Ohio 44202.
CHANGES
The material in this guide is for information only and is subject to change without notice. Network Technologies Inc
reserves the right to make changes in the product design without reservation and without notification to its users.
FIRMWARE VERSION
3.02
WARRANTY INFORMATION
The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact
Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our website at
http://www.networktechinc.com for information regarding repairs and/or returns. A return authorization number is
required for all repairs/returns.
ii
SPLITMUX-DVI-4 3.02 Release Notes
Correction for display of serial number in the OSD.
SPLITMUX-DVI-4 3.00 Release Notes
Transparent USB 2.0 Matrix
The transparent USB 2.0 Matrix allows switching of up to four USB devices to the connected hosts.
New improved Video ICs
The new video processor of V-Switch quad II provides best image quality in Quad, PiP, Dual and Fullscreen mode. New
interpolation filters guarantee brilliant image quality when scaling.
New equalizers allow connecting sources and console at up to 20 meters distance.
Improved Input Video Mode Support
New DVI receivers support any resolution up to 1920x1200@60 Hz at digital inputs following the VESA or CEA standards.
Support for 1920x1200 and 1920x1080 at 50 Hz and 60 Hz as analog input modes.
1920x1200 and 1920x1080 at 50 Hz and 60 Hz are now supported as analog input modes.
Improved EDID Management
Input EDIDs can now be programmed comfortably. The content of monitor EDIDS can be copied into the input EDIDs.
iii
SPLITMUX-DVI-4 - 2.1 Release Notes
SPLITMUX firmware version 2.1 contains new and improved features, including smooth transitions, manual input video mode
selection, and automatic hiding of notifications like “no signal” to prevent burn-in.
New Features in 2.1
Fade through black
An elegant visual effect for presentations: When switching channels or display modes, the previous image fades to black, and the
next image is faded in smoothly. Fade through black can be enabled or disabled by the user, and has five speed settings.
Screen protection
Some servers switch off their video output after a period of inactivity. To prevent burn-in, notifications such as “no signal” are
hidden after 10 seconds.
Manual settings for input video mode
To enable users to ensure they always have the current input video mode, SPLITMUX now supports manual settings for modes
that are difficult to distinguish automatically.
Improved video mode detection
Automatic input and output mode detection have been improved.
SPLITMUX-DVI-4- 1.40a Release Notes
SPLITMUX Firmware version 1.40a features improved keyboard compatibility and includes minor features and bug fixes.
New Features in 1.40a
Improved keyboard compatibility
Version 1.40a adds compatibility with programmable keyboards that can send custom key combinations. Now you can efficiently
operate a single unit as well as multiple cascaded units with the press of a button.
Raw EDID data
Using the CONSOLE->EDID menu, it is now possible to view the raw EDID data of the connected monitor to facilitate
troubleshooting.
New resolution
HDTV 720p (1280x720) is now accepted both as an analog signal as well as a digital signal. Previous firmware versions only
support digital HDTV resolutions.
More on Cascading
By cascading the Splitmux-DVI-4, you can connect up to 16 computers, and show them simultaneously on a single display.
Please see drawings at the end of this manual. They are for 8 computers on a single console (or computers with multiple outputs).
NOTE: Instead of using a standard keyboard you can use a key pad (like X-key) and program any command behind a
single key. This allows switching comfortably between display modes and active channels.
LIMITATION: Please remember the issue with the lack of resolution of displays and the real time video issue.
There will be no real time video in each of the small quadrants even if you would lower each computers resolution to 800x600 and
rise the refresh rate to 180Hz.. The reason is that the outputs of the “slave” Splitmux-DVI-4unit will only support up to 80Hz.
This means about 10-12 frames per second for each of the up to 16 quadrants.
iv
SPLITMUX-DVI-4- 1.40 Release Notes
Touch Screen Support
SPLITMUX version 1.40 adds touch screen support to allow the user to operate four computers with a touch screen. The initial
release includes support for touch screens from the following manufacturers:
•elo AccuTouch 2116 Controller Series
includes monitor models 1215L, 1229L, 1515L, 1522L, 1528L Medical, 1529L, 1537L, 1715L, 1729L, 1739L, 1915L,
1928L, 1928L Medical, 1939L, 2020L
•TSharc Octopus Controller
widely used, including in touch screens manufactured by 3M, Microtouch, TrollTouch, The Bergquist Company
Version 1.40b and higher:
-2701 Controller Series (IntelliTouch, SecureTouch)
SPLITMUX-DVI-4 - Installation and Operation Manual
TABLE OF CONTENTS
TABLE OF CONTENTS
I
INTRODUCTION 1
FEATURES 1
TECHNICAL SPECIFICATIONS 3
SAFETY GUIDELINES 4
HARDWARE 5
- FRONT PANEL 5
- LED indicators 5
- Push buttons 6
- Additional button functions 7
- REAR PANEL 8
- Power / Reset / Monitor 8
- DVI-I / RS 232 / USB 9
INSTALLATION 10
CONNECTING UNIT TO POWER 10
CONNECTING CONSOLE (MONITOR, KEYBOARD, MOUSE, TOUCHSCREEN, TRACKBALL) 10
CONNECTING SOURCES / COMPUTERS 11
CONNECTING USB DEVICES 11
POWERING UP THE SYSTEM 11
ON SCREEN DISPLAY 12
OSD - OVERVIEW 12
OSD - MAIN MENU WINDOW 13
OSD - NAVIGATION 13
OSD SYSTEM - HOTKEY 14
- HOTMOUSE FUNCTION 15
- QUAD MODE 16
- OSD POSITION 17
- OSD LANGUAGE 17
- SECURITY - SECURITY LEVELS 18
- TEST PATTERN 21
- DISABLE CHANNEL 22
- CONTROL - DCP control 23
- Example of DCP control 24
- DCP synchronize 24
- Example of DCP synchronization 25
- SECURITY LEVELS 26
OSD MODE - PIP 27
- START 31
OSD CONFIGURATION - BACKUP 32
- RECALL 32
- FACTORY RESET 33
OSD CONSOLE - VIDEO OUTPUT 34
- LAYOUT / LANGUAGE 35
- TOUCHSCREEN 36
- FADE 38
- MULTI MONITOR 39
- EDID 40
SPLITMUX-DVI-4 - Installation and Operation Manual
TABLE OF CONTENTS
TABLE OF CONTENTS
II
ON SCREEN DISPLAY (continued)
OSD VIDEO - INPUT STATUS 41
- DVI/VGA 41
- BRIGHTNESS 42
- CONTRAST 42
- HORIZONTAL POSITION 42
- VERTICAL POSITION 42
- SCREEN WIDTH 43
- PHASE 43
- FORMAT 44
OSD COMPUTER - KEYBOARD 46
- MOUSE 46
- RESET PS/2 47
- CHANGE EDID/DDC 47
OSD USB DEVICE 1-4 - USB PORT STATUS 50
- SWITCHING MODE 51
- CHANGE NAME 52
OSD HELP - HOTKEY 53
- ABOUT 53
- CONTACT 53
HOTMOUSE 54
ACTIVATING HOTMOUSE CURSOR 54
HOTMOUSE CURSOR IN FULLSCREEN MODE / QUAD MODE 55
HOTMOUSE CURSOR IN PIP MODE 56
HOTMOUSE MENU - ACTIVATING 58
- OPERATING 58
- MODE - QUAD 59
- FULL 59
- PIP 60
SERVICE 62
MAINTENANCE AND REPAIR - TECHNICAL SUPPORT 62
ANNEX 63
DECLARATION OF CONFORMITY 63
FCC DECLARATION 64
KEYBOARD COMMANDS 65
DEVICE CONFIGURATION PROGRAM 67
FIRMWARE UPDATE 69
SERIAL CABLE 70
DCP-XML REMOTE CONTROL 71
SUPPORTED TOUCH SCREEN CONTROLLER 72
SUPPORTED VIDEO INPUT 73
SUPPORTED VIDEO OUTPUT 74
CASCADING 75
DELIVERABLES 76
SPLITMUX-DVI-4 - Installation and Operation Manual
INTRODUCTION
1
Thank you for choosing SPLITMUX-DVI-4 from NTI. This product represents the latest state-of-the-art tech-
nology in keyboard-video-mouse (KVM) switching. The SPLITMUX-DVI-4‘s key advantage over conventional
KVM switches is that it allows you to simultaneously display and administer 4 computers on a single console. It
combines key features of a high-end KVM switch and a digital multiviewer scaling and converting videos at both
inputs and output.
DISPLAY MODES
QUAD MODE u
In this mode, the screen is split into four elds of equal
size each displaying the entire screen contents of one
source.
tFULLSCREEN MODE
In Fullscreen mode, one of the four sources
is displayed in full screen size and maximum
resolution.
PiP MODE (Picture in Picture) u
Using this feature, the full screen display of one of the
four video sources is accompanied by one to three small
images (thumbnails) of the other video sources which
are displayed on the right hand side of the screen allowing
simultaneous monitoring.
All PiP display modes are described in chapter
OSD – MODE – PIP (pages 27ff).
tDUAL MODE
In Dual mode the left halves of the fullscreen images
from two video sources are displayed side by side at
full size and at full vertical resolution. For a version of
Dual mode with two images side by side at full size
(entire screen content, not only left halves) see page 22.
FEATURES
SPLITMUX-DVI-4 - Installation and Operation Manual
INTRODUCTION
2
DVI & VGA
SPLITMUX-DVI-4 supports resolutions of up to 1920 x 1200 @ 60 Hz for both DVI and VGA.
Any combination of VGA and DVI at all standard resolutions is possible at inputs and output. Analog video input
is converted to digital. If an analog display is connected, SPLITMUX-DVI-4 converts the digital signal to analog
at the output. Internally, SPLITMUX-DVI-4 processes video purely digital guaranteeing best digital image
quality.
USB & PS/2 for keyboard / mouse / touch screen / trackball
Use either PS/2 or USB ports on the computer to connect keyboard and mouse to SPLITMUX-DVI-4. It supports
any combination.
To connect the console, SPLITMUX-DVI-4 features two USB ports for mouse, keyboard, touchscreen or
trackball connection.
Transparent USB 2.0
SPLITMUX-DVI-4 features a transparent high speed USB 2.0 matrix: USB 2.0 devices (e.g. printer, external
memory, memory stick,webcam, 3D mouse, nger printer) can be switched to computers connected.
Operation
There are six ways to operate SPLITMUX-DVI-4, switch channels, and select display modes:
1. Using the buttons on the front of the unit
2. Using congurable hotkeys
3. Using the unit’s external conguration program on a remote computer
4. Via a serial port using the protocol DCP XML
5. Using mouse functions (Hotmouse)
6. Using a touch screen
The conguration of SPLITMUX-DVI-4 is effected via an On Screen Display (OSD) opened and and navigated
either with keyboard commands or front panel buttons or remotely via ConfDev on an external PC.
The LEDs on the front panel indicate the unit’s current status.
Use the serial (RS232) port for remote control and rmware updates.
FEATURES
SPLITMUX-DVI-4 - Installation and Operation Manual
INTRODUCTION
3
TECHNICAL SPECIFICATIONS
Casing: Desktop or 19“, black (RAL 9005)
Dimensions WxDxH: 43.6 x 23.4 x 4.4 cm
Weight: 2.9 kg
Operating controls: Front panel: Four channel selection buttons, one Quad mode button, one
PiP mode button, one Fullscreen mode button
Rear panel: One Power On/Off switch, one Reset button
Indicators: Four active channel indicator LEDs, one Quad mode LED, one PiP mode LED,
one Fullscreen mode LED
Computer ports: 4 x DVI-I (analog and digital), 4 x PS/2, 4 x USB
Console ports: 1 x DVI-I, 2 x USB for keyboard and mouse
Transparent USB 2.0 ports:4 x transparent high-speed USB 2.0
Maximum distance: Video (DVI / VGA) up to 20 meters; keyboard / mouse up to 5 meters
Input and
output resolution: up to 1920 x 1200 @ 60 (DVI and VGA) *
EDID adjustments: EDID at each input port customizable
Supported
keyboard layouts: German, English, French, Italian, Spanish, Japanese
Power supply: Internal AC adapter, 100 to 240V 50/60 Hz
Power consumption: 40 watts
Operating temperature: 5 to 45°C
Storage temperature: -10 to 60 °C
Rel. humidity: 5 to 65% non-condensing
*(at WUXGA: reduced blanking only - WUXGAr)
