Anita 2 Sided and 3 Sided Alcove

1. When you receive your Anita shower check contents for any freight damage of defect.

2. Advise Newline on 0508 639 5463 if any damage has occurred within 8 hours of receiving

the goods so this is can rectied.

3. Do not proceed with installation until resolved as there cannot be a valid claim later.

Important!

INSTRUCTION MANUAL

JULY 2018 V2

2 SIDED & 3 SIDED ALCOVE

WARRANTY

• Faultygoodsarecoveredunderwarrantyfor5years.Visitwww.newline.nzforwarrantyinformation.

• Breakagesincurredduringinstallationarenotcoveredunderwarranty.

• Installationsmustconformtotheinstructionstobecoveredbythewarranty

HEALTH AND SAFETY

Toughened Glass:

• Donotreworkpre-cutglasspanels.Cuttingoralteringaglasspanelwillcauseittoexplodewithoutwarning.

• Unpackallglassassemblies.Standglassonsoftpackagingwhenitisontheoorandagainstawall.Caremust

betakennottostrikeanyedgeorcorneragainstahardsurfaceasthiswillchipanddestroytheglasspanel.

Installation:

• Glasspanelsandassembliesareheavy.Twomanliftingisrecommendedforhandlingandinstallation.

• Determinepositioningofwiringandpipingwithinwallcavitiesbeforeshowerinstallation.Marktheirpositionsto

ensureelectricalandpipingareasareavoided.

• Wearappropriateprotectiveclothingandeyeprotectionduringinstallation.

TOOLS REQUIRED

NEWLINE RECOMMENDS A SKILLED TRADESMAN ACQUAINTED WITH

SHOWER INSTALLATIONS IS USED TO ENSURE THE VERY BEST OUTCOME.

IMPORTANT INFORMATION

AFTERCARE

• Theshowermustbesqueegeeddownaftereachshower.Thoroughlycleanweeklywithamicrobercloth,

milddetergentandwater.Rinsewithcleanwaterandsqueegeeandwipeddry.

ENSURE YOU TICK THE SPECIFIC BOXES THAT APPLY AS YOU PROGRESS

Floor & Walls:Floormustlevelwithnodeectionandwallsplumbandat.Thisisofallimportancefora

successfulinstallation.

Tray and Liner:InstallationforTiletraysorAcrylicTrays&LineraresuppliedwiththespecicTrayordered

Frame:

1. Wall Prole options

Acrylic Tray:Centred20mmooutsideoftrayedge

Hob Tile Tray:Centred45mmonishedtileedge.(Thiswillallow32mmotraybeforetiling)

Level Entry:Centredatthetransitionline(whereslopebegins)

2. Solid xing for Wall Rail Bracket

A3sidedonlyonthedoorsideadjacentwall.

Attacha300mmverticallengthofframingontheinsideofthewallprolestudstartingatthelowest

pointof1780mmotheoorto2080mmatthetop.

3. Solid xings for wall mounted plumbing ttings

Consultwiththeplumber.

Wet Grade lining: AqualineGib.orequivalent“mustbeusedbehindallshowerinstallationsforcompliance”

Plumbing:UsearegisteredplumberforinstallationallsupplyandwasteitemspriortoTrayandWalllinings

Waterproong “Pronsh Tile Trays”:ThismustcomplywithAS/NZS4858:2004andbeundertakenby

certiedapplicatorandaProducerStatementprovided.Thereisalistofprovensystemsonourwebsite

www.newline.co.nz

Tiling:

1. Newlinerequirestheuseofcompletesystemsbylicenced/trainedapplicators.Waterproong,Tile

Adhesive,GroutingandSiliconedetailingforfullaccountabilityandperformancerequirements.

2. Thetilesmustconformtogradientsprovidewiththe“ProFinishTileTray”tocomplytoNZBuilding

Code.

3. Thelinewhereshowerframesitsmustbelevelforanacceptableinstalloftheshower.

PREPARATION CHECKLIST

ANITA SHOWER - SELECTING THE CORRECT LAYOUT PLAN

There are four layout pages provided. Please ensure you select the correct layout page and combine

this with the installation details.

2ExplodedViewAssemblyDiagram  Page 3

2SidedAcrylicLayoutPlanA   Page 4

2SidedTilewithProFinishTileTrayLayoutPlanB Page 5

Alcove(DoorOnly)LayoutPlanC   Page 6

InstallationSteps     Page 7

ANITA SHOWER - ASSEMBLY DIAGRAM

REF. DESCRIPTION PART NO. QTY REF. DESCRIPTION PART NO. QTY

1 WallProle K8618 2 13 Rail H8601 1

2 Returnpanel 1 14 Railjoinerassembly K0970 2

3 Doorpanel 1 15 Wallgaskets K1342 2

4 Buerstrip I6105 1 16 Wallcap K1359 1

5 Buer/sealstrip I8526 1 17 Frontxedpanel 1

6 Handleset H8533 1 18 Waterdeector I8595 2

7 Lockinknobsets(door) K1519 2Screw Pack K0895 1

8 Frontglasstorailxing K1526 219 ThreadedScrewsM5x10 2

9 Endblock H8540 220 ScrewsM4x35 8

10 Slidingblocks(L/R) LH:H8557

RH:H8564 221 ScrewsM4x8 8

11 Waterbar H8571 124 Screwcovercaps 8

12 Rollersets(door) K8588 225 C/SScrewsM4x35 2

112

Screw Pack

ANITA SHOWER: ACRYLIC 2 SIDED - LAYOUT PLAN A

DOTTED LINE: 

OUTERCHANNELBOUNDARYLINE

RETURN GLASS EDGE:

5MMBACKFROMDOTTEDLINE

IMPORTANT DETAIL

MINIMUM / MAXIMUM TABLE

SHOWER TYPE FRONT DOOR PANEL (A) MIN/MAX RETURN PANEL (B) MIN/MAX

1200x900 1165-1180mm 868-880mm

OPTION A: ANITA ACRYLIC SHOWER (APPLIES TO 1200 X 900)

Anita Acrylic Shower with Newline Acrylic Tray and ABS/Acrylic Liner:

SetouttheAnitaShowerbymarkingouttheoutsidelineofthewallchannels(A)12mminfromtheoutsideedge

ofthetray.Thiswillallowforsuitableplacementoftheshowerplussomevariancesfromplumbonthewalls.

Greatervarianceswillneedtobecalculatedinthelayout.

NOTE: Allmeasurements

assumetheoorislevel,

thewallsareplumbandall

surfacesareat.Anyvariation

mustbeadjustedforinthe

measurementsprovided.

ANITA SHOWER: TILE WITH PROFINISH TILE TRAY - LAYOUT PLAN B

DOTTED LINE: 

OUTERCHANNELBOUNDARYLINE

RETURN GLASS EDGE:

5MMBACKFROMDOTTEDLINE

IMPORTANT DETAIL

MINIMUM / MAXIMUM TABLE

SHOWER TYPE

FRONT DOOR PANEL (A) MIN/MAX RETURN PANEL (B) MIN/MAX ProFinish Tile Tray

1200x900

1165-1180mm 868-880mm 1200X900

NOTE: Allmeasurements

assumetheoorislevel,

thewallsareplumbandall

surfacesareat.Anyvariation

mustbeadjustedforinthe

measurementsprovided.

OPTION B: ANITA TILE SHOWER WITH PROFINISH TILE TRAY

Anita Tile Shower with ProFinish Tile Tray with Hobs Application:

SetouttheAnitaShowerplacebymarkingouttheoutsidelineoftheWallchannels(A)30mminfromtheoutside

edgeofthetiledhob.Thiswillallowforsuitableplacementoftheshowerplussomevariancesfromplumbonthe

walls.Greatervarianceswillneedtobecalculatedfromtheminimum-maximumtablebelow.

PENETRATION OF WATERPROOFING

Waterproongwarrantieswillpotentiallybevoidiftherearepenetrationsthroughthemembrane.UseBostikV60to

bondwallchannelstothetiles.Allowtocureascartridgeinformation.

Ifpenetrations’throughthewaterproongareundertakenyoumustensureyouhaveanacceptablesolution

andifusinganchors’thesemustbebelowthewallcladdingsurface.Recordthedetailsastheinstalleriswholly

responsibleforfailures.

MINIMUM / MAXIMUM TABLE

Shower Type Front Door Panel (A) Min/Max Return Panel (B) Min/Max Pronish Tile Tray

1200x900 1165-1180mm 868-880mm 1200X900

ANITA ALCOVE (DOOR ONLY) - LAYOUT PLAN C

NOTE: All measurements assume the oor is level, the walls are plumb

and all surfaces are at. Any variation must be adjusted for in the

measurements provided.

This is a brief overview of how to set up a door assembly only. This runs in conjunction with the general

instruction sheet.

Step 1Establishanouterboundarylineacrossthebaseandupeachwall(usethe‘ShowerLineto

TrayEdge’Tableabove).

Step 2Onthesideofthexedglassfastenthewallchannel(1)(ReferItems1.1and1.2,Page9)

Step 3Placefrontxedglasspanelinposition (21) (Referitem2,Page9).

STEP 4FixtheRail(13)tothefrontglass (21)withRailxings (8)(Referitem3.2only,Page10)

Next StepToreplicatethemountingpointontheoppositesidefortheRail.

A:Measuretherailpositionbackfromtheouterboundarylineatthexedglasswallend.

B:Measuretheheightfromthebasetotherailalsoonthexedglasswallend.

C: MarkAandBonoppositeside.Holdthelevelontherailanddoublecheckthe

markedheight.

E:UsetherailJoinerassembly (15)tomarkthetwoholesonthewall.

F:PredrillthewallandfastenupJoinerassemblytoboththeWallandtotheRail.

All other installation steps can be now followed in the general instructions eliminating the return panel details

that do not apply.

OPTION C: ANITA ALCOVE (1200 DOOR SET) WITHTILE

BASEANDACRYLICBASEAPPLICATIONS

ThefollowingtablecoverstheDoorSizewiththeMinimum

andMaximumRange.Caremustbetakenifusingthe

minimumormaximummeasurementsasdiscrepanciesin

thewallsorbasemaynotallowforthis.

SHOWER DOOR TYPE FRONT DOOR PANEL MIN/MAX

1200 Door 1166 - 1180mm

SHOWER LINE TO TRAY EDGE

AcrylicTray 12mm

ProFinishTileTray(Hob) 30mm

ProFinishlevelentrytrayattransitionline(Slopestarts)

Height

Depth

Dotted Line:

Outer boundary

Shower Line to Tray Edge

(See Table)

Rail Joiner:

Mounted L/H or

R/H only

PENETRATION OF WATERPROOFING

Waterproongwarrantieswillpotentiallybevoidiftherearepenetrationsthroughthemembrane.UseBostikV60to

bondwallchannelstothetiles.Allowtocureascartridgeinformation.

Ifpenetrations’throughthewaterproongareundertakenyoumustensureyouhaveanacceptablesolution

andifusinganchors’thesemustbebelowthewallcladdingsurface.Recordthedetailsastheinstalleriswholly

responsibleforfailures.

1.1 1.2

ANITA SHOWER - INSTALLATION INSTRUCTIONS

 IdentifythespecicLayoutPlanapplicabletoyourspecicshower.UsethecorrectLayout

 Planinconjunctionwiththeinstallationinstructions.Markoutthewallchannelstakinginto

 accounttheguidancenotes.

1.1

1.2

Acrlyic:

Pre-drill lead holes in the wall lining matching up to the Channel holes.

Apply silicone to the back of the channel and x in place with the M4 x 35 screws ensuring that the

channel remains plumb.

Insert the return panel (2) and xed front panel (22) into the wall channels (1).

TILING NOTE: Place 10mm wide thin clear plastic strips as isolation packers at 90 degrees under

the xed glass. Finally before nishing with silicone, trim the excess with a knife.

TILE: BondthewallchannelstothetileswithBostikV60.

(Referbacktotilelayoutpagere-penetrationofwaterproong)

Install rail bracket components (14, 15, 17 & 18) to return panel.

Insert the rail (13) into return glass bracket and attached to the front panel with the two glass xing

pieces (8) and tighten these. Tighten the allen keys on the joiner (15) to the rail (13) when the return

glass is at 90 degrees off wall. If more adjustment is required move the glass front panel within the

wall channel.

The return panel leading edge is positioned 5mm back from the outer channel line as in the Layout

plan. Plumb the glass edge and the assess if the adjustment in our out of the return panel is needed.

As this effects the door running parallel at the bottom.

ENSURE A PLASTIC GLASS PROTECTOR IS USED BETWEEN ALL METAL PARTS AND THE GLASS

3.1

3.2

3.3

3.1 3.2

3.3

RETURN

PANEL

ENSURE PANELS

REMAIN LEVEL

FIXED GLASS

FRONT PANEL

C1:

DOTTED LINE:

OUTER CHANNEL BOUNDARY LINE

GLASS LINE:

5MM BACK FROM DOTTED LINE

GLASS

RAIL

IMPORTANT DETAIL

4.1

4.2

4.3

4.4

4.5

Install the roller sets (12) to door panel (3). Rollers should be on the outside of the door. Fit water

deector on bottom edge of door.

Hang the door on the rail from inside of the shower.

Carefully slide the door toward the return panel and check the gap between door and return panel

is even. Adjust if necessary using offset in rollers or adjustment from the rail support. At this point

assess if the return panel needs to go in or out slightly to align the door parallel to the tray.

Bond with Silicone the following parts to the tray. Sliding block (10) slotted into the glass front panel

edge and the waterbar (11) positioned parallel to the outside edge of the tray going across to the

end block (9) against the return panel. Tape in position and allow a minimum of 24 hours for this to

cure.

Install lock in knobs on the door & tighten rail xings.

4.5

4.1

4.2

4.3

4.4

WATER DEFLECTOR (24)

Inhaltsverzeichnis

Andere NewLine Andere Handbücher

NewLine

NewLine NEO ANGLE 6MM FRAMELESS Handbuch

Beliebte Andere Handbücher anderer Marken

GO Industries

GO Industries 38017 Bedienungsanleitung

Cissell

Cissell 30LBCMAN2 Bedienungsanleitung

RIDGID

RIDGID K-60SP Bedienungsanleitung

Gage Bilt

Gage Bilt GB751SH-5 Bedienungsanleitung

OVE

OVE SIERRA 60 Bedienungsanleitung

ReelCraft

ReelCraft 7800 OLB21 Bedienungsanleitung

Body Armor 4x4

Body Armor 4x4 ECO-SERIES Bedienungsanleitung

ROBLIN

ROBLIN DROP Benutzerhandbuch

EMG

EMG EMG-ACB BARREL Service-Handbuch

MiniSolar

MiniSolar MT-150 Bedienungsanleitung

Parkside

Parkside PSZ 250 B2 Bedienungsanleitung

ABB

ABB REM 610 Produkthandbuch

Parkside

Parkside 55992 Betriebsanleitung

Skyjacker

Skyjacker F250 Bedienungsanleitung

IBM

IBM IBM SYSTEM Z Installationsanleitung

Grech Motors

Grech Motors G28 Bedienungsanleitung

NOVAK

NOVAK BATTERY CARE SHEET Leitfaden

Telemotive

Telemotive blue PiraT Mini Benutzerhandbuch
