Nokia Bluetooth Display Car Kit CK-15W
2 Copyright © 2007Nokia. All rights reserved.
Please note: car accessories must be installed or repaired by qualified
professionals only. Carefully read the User Guide and Installation Guide
for each system to be installed.
Contents
•Purpose of these guidelines
•Product overview
•Installation guidelines
•Troubleshooting
3 Copyright © 2007Nokia. All rights reserved.
Please note: car accessories must be installed or repaired by qualified
professionals only. Carefully read the User Guide and Installation Guide
for each system to be installed.
To provide the technical background information needed for carrying out professional
installation.
Only a qualified service technician should install or service the car kit using the approved
original Nokia parts supplied in the sales package. Faulty installation or service may be
dangerous and may invalidate any warranty which may apply to the car kit. End users
should remember that the car kit comprises complex technical equipment that requires
professional installation using special tools and expert know-how.
Instructions given in this guide are general guidelines which apply for the installation of
the car kit in an automobile. However, due to the wide variety of car types and models
available on the market, this guide cannot consider the individual technical
requirements relevant for any particular vehicle. Contact the vehicle manufacturer for
detailed information about the vehicle in question.
Purpose of these guidelines
4 Copyright © 2007Nokia. All rights reserved.
Please note: car accessories must be installed or repaired by qualified
professionals only. Carefully read the User Guide and Installation Guide
for each system to be installed.
Car radio mute
Nokia Bluetooth Display
Car Kit CK-15W
Input device
Hands-free over Bluetooth
wireless technology
Display
Microphone
Speaker
Product overview
Hands-free unit
Example of connectivity
5 Copyright © 2007Nokia. All rights reserved.
Please note: car accessories must be installed or repaired by qualified
professionals only. Carefully read the User Guide and Installation Guide
for each system to be installed.
Sales package content
1 = Loudspeaker SP-3
2 = Display SU-29
3 = Microphone MP-2
4 = Input device CU-8
5 = Hands-free unit HF-15
6 = Power cable PCU-4
7 = Clamps
8 = System cable CA-115
1
2
3
5
4
6
7
8
6 Copyright © 2007Nokia. All rights reserved.
Please note: car accessories must be installed or repaired by qualified
professionals only. Carefully read the User Guide and Installation Guide
for each system to be installed.
Connectors
1 = Microphone 4 = Display
2 = Speaker 5 = Power cable
3 = Display
5
24
31
7 Copyright © 2007Nokia. All rights reserved.
Please note: car accessories must be installed or repaired by qualified
professionals only. Carefully read the User Guide and Installation Guide
for each system to be installed.
Options of installation
Phone in
Phone in
Phone in
Handsfree unit
CRM*
Mute Spkr.
Handsfree unit
CRM*
Mute Spkr.
Phone-in Mute box Speaker
Car
speaker
Handsfree unit
CRM*
Mute Spkr.
Dedicated
speaker
Car sound systemCar sound system Car sound system
* Please note: CRM can be left open in the event that the car sound system does not support the connection.
8 Copyright © 2007Nokia. All rights reserved.
Please note: car accessories must be installed or repaired by qualified
professionals only. Carefully read the User Guide and Installation Guide
for each system to be installed.
Overview
Connection
options
Installation and
placement of
components in the car
Cable connections to
the car kit
9 Copyright © 2007Nokia. All rights reserved.
Please note: car accessories must be installed or repaired by qualified
professionals only. Carefully read the User Guide and Installation Guide
for each system to be installed.
Connection options
Phone-in
Various connections
In order to ensure correct car sound system
mute, audio volume behavior, and voice
must be handled differently.
Overview of connection options:
– Phone-in
– Mute box (i.e. relay to switch car speakers
between sound system and car kit)
– Speaker
Mute box
Speaker
10 Copyright © 2007Nokia. All rights reserved.
Please note: car accessories must be installed or repaired by qualified
professionals only. Carefully read the User Guide and Installation Guide
for each system to be installed.
Connection options
• Voice signal from the audio-out of the
hands-free to phone-in port of the car
sound system
• Mute signal from power cable
to car sound system
Cables/Adapters needed:
• Adapter cable from audio-out (e.g. simply
cut the cable of the speaker included in
the sales package) to the phone-in of car
sound system
Car sound system phone-in
