Performus X Series Dispensers

Quick Start Guide

Electronic pdf les of Nordson EFD

manuals are also available at

www.nordsonefd.com

WATCH SETUP VIDEOS

www.nordsonefd.com/PerformusSetUp

Unpack the unit. Now is a good time to activate the warranty

online at www.nordsonefd.com/warranty/dispensers/two.

1. NOTE: Clean, dry ltered air

is required to meet warranty. If

your air supply is not ltered,

order the 5-micron lter /

regulator. See the Dispenser

Accessories data sheet

at www.nordsonefd.com/

DispenserAccessories for

details.

Turn the air regulator

adjustment knob to zero (0).

Connect one end of the air

input hose to the Performus™;

connect the other end to the

plant air supply. Set the plant

air supply between 5.5–7.0bar

(80–100 psi).

2. Attach the plug that matches the local power outlet to

the power pack.

Connect the power cord to the Performus and insert the

plug into the local power source.

Press the power button on the front panel.

3. Connect the foot pedal or optional nger switch.

4. Attach a lled Nordson EFD syringe

barrel to the adapter assembly and snap

the safety clip closed. Replace the tip

cap with a Nordson EFD dispense tip

and place the syringe barrel in the barrel

stand.

5. Insert the adapter assembly into the

quick-connect tting on the front of the

Performus and twist to lock.

6. Set air pressure:

• Pull the air regulator adjustment knob

out to unlock it.

• Turn the knob clockwise until the

correct air pressure is shown on the

LED display.

• Push the air regulator adjustment knob

in to lock it.

3 12

Open

Closed

7. Set the dispense time (refer to the operating manual for

detailed instructions):

• Put the Performus in the Timed or Teach mode.

• Use the Program / Teach function to set the dispense

time.

8. Unsnap the safety clip on the adapter assembly.

9. Purge the dispense tip and apply uid as described

below:

a. Put the dispenser in the Steady mode and press the

foot pedal until uid ows from the tip, then release

the foot pedal.

b. Put the dispenser in the Timed mode and press the

foot pedal once to make a timed deposit.

For Nordson EFD sales and service in over

40 countries, contact Nordson EFD or go to

www.nordsonefd.com.

Global

East Providence, RI USA

800-556-3484; +1-401-431-7000

[email protected]

Europe

Dunstable, Bedfordshire, UK

0800 585733; +44 (0) 1582 666334

[email protected]

Asia

China: +86 (21) 3866 9006; [email protected]

India: +91 80 4021 3600; [email protected]

Japan: +81 03 5762 2760; [email protected]

Korea: +82-31-736-8321; [email protected]

SEAsia: +65 6796 9522; [email protected]

The Wave Design is a trademark of Nordson Corporation.
