USER`S MANUAL VER. 1.0
B/W DOME CAMERA
NVC-10BD
NOVUS SECURITY Sp. z o.o.
359 Pulawska Str., 02-801 Warsaw, Poland
tel: +4822-546-0-500; fax: +4822-546-0-519
[email protected]; www.novuscctv.com
© Copyright 2003, NOVUS SECURITY Sp. z o.o.
NVC-10BD B/W dome camera, User`s Manual
2
© Copyright 2003, Novus Security Sp. z o.o. All rights reserved.
Thank you for choosing this high quality camera, before attempting to connect or operate this product,
please read and follow these instructions completely and carefully.
B/W CCTV CAMERA OPERATING MANUAL
SPECIFICATIONS
Pick up Element 1/3" B/W CCD image sensor
Number of Pixels 500(H) x 582(V) <CCIR>
Resolution 380 TV lines
Min. Illumination 0.25 Lux / F2.0
S/N Ratio More than 48dB (AGC off)
Electronic Shutter 1/50 to 1/100,000 s
Iris Mode AES only
Video Output 1.0Vp-p composite,75 Ohm
Standard Board Lens f3.6mm / F2.0
Operating Temperature 0º~ 50ºC
Lens Angle 68°
Power Source DC12V ± 10%
Current Consumption 100 mA
Dimension (mm) 100(Ø) x 57.5(H)
Weight 135g
WARNING:
TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE
GENERAL
This B/W CCD video camera equipped with a B/W CCD (charge coupled device) provides an
exceptionally long product life and high reliability. The speciality of this super mini camera is the
possibility to locate it at any location, so thanks to this camera you can easily monitor a broad area.
NVC-10BD B/W dome camera, User`s Manual
3
© Copyright 2003, Novus Security Sp. z o.o. All rights reserved.
FEATURES
Feates
1. 380 TV lines of horizontal resolution and high quality picture.
2. Built in Auto Electronic Shutter.
3. Minimum illumination of 0.25 Lux / F2.0
4. Signal-to-noise ratio of 48dB.
5. High reliability under long time operation.
MAJOR OPERATING CONTROLS AND FUNCTIONS
1. DC12V Input Terminal : For connected to power supply.
2. Video Output Connector (VIDEO OUT) : For connected to video terminal.
CONNECTIONS
1. Connect to the power cord: This is to connect camera to a 12V DC regulated power supply.
2. Connect to video input: This is to connect camera to 75Ohm video terminal with standard 75 Ohm
coaxial cable
STANDARD ACESSORIES
1. Main Body * 1
2. DC-BNC Connector * 1
3. Instruction Manual * 1
1
2
NVC-10BD B/W dome camera, User`s Manual
4
© Copyright 2003, Novus Security Sp. z o.o. All rights reserved.
CAUTION
1. Please use correct power adaptor, DC12V (regulated), to operate this unit. The power tolerance of
this unit is DC 12V ± 10% (DC10.8V~13.2V), over maximum DC13.2V power input will damage this
unit.
2. Video output (BNC connector) of this unit can be only connected to monitor. Please check the
wiring of video output before power on. If the power is offered through video output, the unit will be
damaged.
1. Do zasilania kamery należy użyćwłaściwego zasilacza prądu stałego :12 V DC (regulowane).
Tolerancja napięcia dla tej kamery wynosi: 12 VDC + 10 % ( 10.8 -13.2 VDC). Przyłożenie do
kamery napięcia większego od dopuszczalnego tj. 13.2 VDC, może spowodowaćuszkodzenie kamery.
2. Wyjście wizyjne kamery (BNC) można połączyćwyłącznie z właściwym wejściem monitora. Przed
połączeniem kamery z innymi urządzeniami CCTV, należy sprawdzićokablowanie. Jeśli wraz z wizją
zostanie podany inny sygnał, o napięciu większym niż1 V p-p, to kamera może ulec uszkodzeniu.
1. Por favor use el correcto adaptador de energía eléctrica DC12V (regulado) para operar esta
unidad, La tolerancia de energía de esta unidad es de DC12V ± 10% (DC10.8V~13.2V). Sobrepasar
el máximo de DC13.2V de la potencia de entrada dañara esta unidad.
2. La potencia de salida del video (Conector BNC) de esta unidad puede ser solo conectado al
monitor. Por favor revise los cables del video antes de encenderles. Si la energía es dada por la
potencia de salida del video, la unidad se dañara.
1. Bitte schließen Sie das Gerät an das Netzgerät (DC12V) an. Die Toleraz der Stromversorgung ist
12V DC ± 10% (DC10.8V~13.2V). Abweichende Werte können zu Beschädigungen am Gerät führen.
2. Verbinden Sie den Video-Ausgang (BNC-Anschluß) mit dem Video-Eingang des Monitors. Bevor
Sie die Spannungsversorgung einschalten, überprüfen Sie Bitte den korrekten Anschluß des Video-
Ausgangs. Falsche Anschlußbelegungen können zu Beschädigungen an den Geräten führen.
Connections
Standard Accessories
CAUTION
All rights reserved © NOVUS SECURITY
NOVUS SECURITY Sp. z o.o.
