Z/A/X/DZ Common Accessories Z/A/X/DZ F-189

Limit

Switches

Z/A/X/DZ Common Accessories

Z/A/X/DZ

Ordering Information

■List of Models

Terminal Covers (Sold Separately)

Common to Z, A, X, and DZ Models

The Terminal Cover is secured with mounting screws and protects the casing and terminal wires from dust, vibration, or fingers, thus preventing

terminal short-circuiting, ground faults, wire disconnection or improper connection, and electric shock accidents.

Terminal Covers made of phenol resin have five or six thin wall sections. These sections can be torn open for providing holes for lead cables at

desired points.

Note: Use the screw-terminal use Terminal Cover for DZ-series soldering-terminal models.

Separator (Sold Separately)

Common to Z, A, X, and DZ Models

Model: Separator for Z

Actuators (Sold Separately)

Common to Z and X Models

A Switch can be actuated by a cam or an appropriate object, in which case, use one of the following Actuators according to the application.

Application Soldering terminal use Screw terminal use Remarks

Material Mounting direction Model

Phenol resin Side mounting AP-A AP-B ---

Metal press mold Side mounting AP1-A AP1-B Used for AP-A and AP-B

Vinyl chloride Side mounting AP-Z ---

Actuator Common to Z and X models

XAA-1

ZAA-2

Short ZAQ-3

Medium ZAQ-2

Long ZAQ-1

ZAQ-22

Hinge lever

Hinge roller lever

Panel mount plunger

Panel mount roller plunger

F-190 Z/A/X/DZ Common Accessories Z/A/X/DZ

Dimensions

■Dimensions and Operating Characteristics

Terminal Covers

Note: Each dimension has a tolerance of ±0.4 mm unless otherwise specified. (±0.8 mm for the AP-Z)

2.15R 2.15R

AP-A AP-B

AP1-A AP1-B

Soldering Terminal Use

(Phenol Resin)

Note: The Cover has five thin, easy-to-separate por-

tions for easy lead wire connections.

Screw Terminal Use

(Phenol Resin)

Note: The Cover has six thin, easy-to-separate por-

tions for easy lead wire connections.

Soldering Terminal Use

(Metal Press Mold)

2. AP1-A should be used with AP-A.

Note: 1. The Cover has five holes for easy

lead wire connections.

Screw Terminal Use

(Metal Press Mold)

2. AP1-B should be used with AP-B.

Note: 1. The Cover has six holes for easy

lead wire connections.

AP-Z

Nut

Cable Pull-out Dimension

A-A' cross-section B-B' cross-section

Two, 4.2 dia.

8 dia. 6 dia.

Soldering or Screw Terminal Use

(Vinyl Chloride) Pressure plate

(t1 steel)

M3 ×20 Phillips screw

(with plane washer and

nut)

Note: A 6-dia. or 8-dia. cable can be used by

cutting the cable pull-out hole to the size

of the cable to be used.

Z/A/X/DZ Common Accessories Z/A/X/DZ F-191

Limit

Switches

Separator

Actuators

Note: These Actuators are not provided with Switches.

Note: Each dimension has a tolerance of ±0.4 mm unless otherwise specified.

t = 0.34

Two, 4.5 dia.

Note: 1. Each dimension has a tolerance of +0.4 mm unless

otherwise specified.

2. The material is EAVTC (Epoxide Alkyd Varnished

Tetron Cloth) and its heat-resisting temperature is

130°C.

Model Z-15G-B X-10G-B

OF max.

RF min.

PT max.

OT min.

MD max.

4.90 n {500 gf}

1.67 N {170 gf}

6 mm

12.7 mm

2.2 mm

4.90 n {500 gf}

1.67 N {170 gf}

6 mm

12.7 mm

3.3 mm

FP max. 32.9±1.6 mm

Model Z-15G-B X-10G-B

OF max.

RF min.

PT max.

OT min.

MD max.

4.90 n {500 gf}

1.67 N {170 gf}

6 mm

12.7 mm

2.2 mm

4.90 n {500 gf}

1.67 N {170 gf}

6 mm

12.7 mm

3.3 mm

FP max. 44.5±1.6 mm

60R

Hinge Lever

XAA-1

Two, M4 Two, M4 30

Stainless steel

58.5R

Hinge Roller Lever

ZAA-2

Two, M4 Two, M4 30

Stainless steel

9.5 dia. ×4.8 (stainless-

steel roller)

F-192 Z/A/X/DZ Common Accessories Z/A/X/DZ

Note: 1. Stainless-steel pin plunger

2. Bronze frame

3. Incomplete screw section part

with a maximum of 1.5 mm

Note: This Actuator (pin plunger) can be used with Standard Pin Plungers (Z-15G(-B), Z-15E(-B), X-10G(-B), DZ-10G-1A(-1B)) for the Z, X, and

DZ models.

Note: 1. Stainless-steel pin plunger

2. Bronze frame

3. Incomplete screw section part

with a maximum of 1.5 mm

Note: This Actuator (pin plunger) can be used with Standard Pin Plungers (Z-15G(-B), Z-15E(-B), X-10G(-B), DZ-10G-1A(-1B)) for the Z, X, and

DZ models.

Note: 1. Stainless-steel pin plunger

2. Bronze frame

3. Incomplete screw section part

with a maximum of 1.5 mm

Note: This Actuator (pin plunger) can be used with Standard Pin Plungers (Z-15G(-B), Z-15E(-B), X-10G(-B), DZ-10G-1A(-1B)) for the Z, X, and

DZ models.

Model ZAQ-3

Z-15E-B X-10G-B

OF max.

RF min.

PT max.

OT min.

MD max.

8.34 N

{850 gf}

1.12 N

{114 gf}

0.8 mm

4.8 mm

0.15 mm

5.39 N

{550 gf}

1.12 N

{114 gf}

1 mm

4.5 mm

0.2 mm

OP 27.8±1.5 mm

23.3

Short Panel Mount Plunger

ZAQ-3

Two M4 nuts

7.9 dia.

(Note 2)

(Note 3)

12SR

(Note 1)

14.5

dia.

2 t ×15.6 width

across flats

2 t ×14 width across

flats

M12 ×1 mounting

screw

Two M4 ×25 ±round

head screw

Model ZAQ-2

Z-15E-B X-10G-B

OF max.

RF min.

PT max.

OT min.

MD max.

8.34 N

{850 gf}

1.12 N

{114 gf}

0.8 mm

4.8 mm

0.15 mm

5.39 N

{550 gf}

1.12 N

{114 gf}

1 mm

4.5 mm

0.2 mm

OP 53.2±1.5 mm

23.3

Medium Panel Mount Plunger

ZAQ-2

7.9 dia.

(Note 2)

(Note 3)

Two M4 nuts

12SR

(Note 1)

14.5

dia.

M12 ×1 mounting

screw

2 t ×14 width across

flats

2 t ×15.6 width

across flats

Two M4 ×25

screw

Model ZAQ-1

Z-15E-B X-10G-B

OF max.

RF min.

PT max.

OT min.

MD max.

8.34 N

{850 gf}

1.12 N

{114 gf}

0.8 mm

20.6 mm

0.15 mm

5.39 N

{550 gf}

1.12 N

{114 gf}

1 mm

20.4 mm

0.2 mm

OP 69.1±1.5 mm

23.3

Long Panel Mount Plunger

ZAQ-1

7.9 dia.

(Note 2)

(Note 3)

Two, M 4 ×25 screws

Two, M4 nuts

12SR

(Note 1)

14.5

dia.

M12 ×1 mounting

screw

2 t ×14 width across

flats

2 t ×15.6 width

across flats

Z/A/X/DZ Common Accessories Z/A/X/DZ F-193

Limit

Switches

Note: This actuator (roller plunger) can be

used with standard pin plungers (Z-

15G(-B), Z-15E(-B), and DZ-10G-

1A(-1B)).

It cannot be used with X models.

Model ZAQ-22

Z-15E-B X-10G-B

OF max.

RF min.

PT max.

OT min.

MD max.

8.34 N

{850 gf}

1.12 N

{114 gf}

0.8 mm

20.6 mm

0.15 mm

5.39 N

{550 gf}

1.12 N

{114 gf}

1 mm

20.4 mm

0.2 mm

OP 37±0.8 mm

20.7

1.6

23.3±

0.25

23.9

4.8

20.7

11.9 49.2

25.4±

0.2

18.9

Panel Mount Roller Plunger

ZAQ-22

12.7 dia. (Note 1)

(Note 2)

(Note 3)

14.5

dia.

M12 ×1 mounting

screw

Spring washer

Note: 1. Stainless-steel pin plunger

2. Bronze frame

3. Incomplete screw section part

with a maximum of 1.5 mm.

Two, M 4 ×25

screws

Two hex nuts

5-mm thickness, 19 mm

between opposing edges

With groove for roller

penetration

F-194 Z/A/X/DZ Common Accessories Z/A/X/DZ

In the interest of product improvement, specifications are subject to change without notice.

ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.

To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.

Cat. No. B106-E1-01
