Panasonic KX-HNS103EX Bedienungsanleitung

Installation Guide

Home Network System

Water Leak Sensor

Model No. KX-HNS103EX

Thank you for purchasing a Panasonic product.

This document explains how to install the water leak sensor properly.

For details about how to use the system, refer to the User’s Guide

(page 20).

Please read this document before using the unit and save it for future

reference.

For dedicated help, support, or advice, available to help you Monday -

Friday, 09:00 - 23:00. For U.K., please contact us on 0330 3331112 and

for Ireland 01 4475228.

HNS103EX_(en_en)_0111_ver.105.pdf 1 2017/01/11 18:37:54

Introduction

Accessory information ...............3

Important Information

About this system ......................5

For your safety ...........................5

Important safety instructions ......6

For best performance ................6

Other information .......................7

Setup

Part names and functions ..........9

LED indicator .............................9

Setup overview ..........................9

Inserting the battery .................10

Registering the sensor .............10

Confirming the usage area ......11

Installation ...............................12

Appendix

Testing the sensor ...................20

Features available when using the

[Home Network] app ................20

Accessing the User’s Guide ....20

Specifications ..........................21

Conditions of guarantee ..........22

Table of Contents

HNS103EX_(en_en)_0111_ver.105.pdf 2 2017/01/11 18:37:55

Accessory information

Supplied accessories

No. Accessory item/Part number Quantity

ABattery*11

BWall mounting adaptors*22

CWall mounting screws (25 mm)*3/XTB4+25AVW 3

*1 When replacing the battery, see “Power source” of “Specifications”, page 21

for battery information.

*2 1 adaptor for the main unit: PNHR2107Z

1 adaptor for the probe unit: PNHR2108Z

*3 2 screws for the main unit and 1 screw for the probe unit

AB C

Other information

RDesign and specifications are subject to change without notice.

RThe illustrations in these instructions may vary slightly from the actual product.

Trademarks

RiPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other

countries.

RAndroid is a trademark of Google Inc.

RMicrosoft, Windows, and Internet Explorer are either registered trademarks or

trademarks of Microsoft Corporation in the United States and/or other countries.

RAll other trademarks identified herein are the property of their respective owners.

Sales and support information

Customer Communications Centre

RFor customers within the U.K.: 0330 3331112

RFor customers within Ireland: 01 4475228

RFor further support on your product, please visit our website:

www.panasonic.co.uk

Helpline Tel. No.: U.K. 0330 3331112 Ireland 01 4475228 3

Introduction

HNS103EX_(en_en)_0111_ver.105.pdf 3 2017/01/11 18:37:55

Direct Sales at Panasonic U.K.

ROrder accessory and consumable items for your product with ease and

confidence by phoning our Customer Communications Centre Monday - Friday

9:00am - 5:00pm (Excluding public holidays).

RGo on line through our Internet Accessory ordering application at

www.pas-europe.com

RMost major credit and debit cards accepted.

RAll enquiries transactions and distribution facilities are provided directly by

Panasonic U.K.

For your future reference

We recommend keeping a record of the following information to assist with any

repair under warranty.

Serial No. Date of purchase

(found inside the main unit)

Name and address of dealer

Attach your purchase receipt here.

4Helpline Tel. No.: U.K. 0330 3331112 Ireland 01 4475228

Introduction

HNS103EX_(en_en)_0111_ver.105.pdf 4 2017/01/11 18:37:55

About this system

RThis system is an auxiliary system; it

is not designed to provide complete

protection from property loss.

Panasonic will not be held

responsible in the event that

property loss occurs while this

system is in operation.

RThe system’s wireless features are

subject to interference, therefore

functionality in all situations cannot

be guaranteed. Panasonic will not

be held responsible for injury or

damage to property that occurs in

the event of wireless communication

error or failure.

For your safety

To prevent severe injury and loss of life/

property, read this section carefully

before using the product to ensure

proper and safe operation of your

product.

WARNING

Power connection

RUse only the power source marked

on the product.

RDo not connect non-specified

devices.

Installation

RTo prevent the risk of fire or

electrical shock, do not expose the

product to rain.

RDo not place or use this product

near automatically controlled

devices such as automatic doors

and fire alarms. Radio waves

emitted from this product may cause

such devices to malfunction

resulting in an accident.

RDo not allow the cable to be

excessively pulled, bent or placed

under heavy objects. Keep the main

unit upright at all times.

RDo not allow the probe unit to make

contact with a battery or an electric

outlet. The product could become

damaged.

RKeep small parts (screws, etc.) out

of the reach of children. There is a

risk of swallowing. In the event they

are swallowed, seek medical advice

immediately.

Operating safeguards

RDo not disassemble the product.

Medical

RConsult the manufacturer of any

personal medical devices, such as

pacemakers or hearing aids, to

determine if they are adequately

shielded from external RF (radio

frequency) energy. DECT features

operate between 1.88 GHz and

1.90 GHz with a peak transmission

power of 250 mW.

RDo not use the product in health

care facilities if any regulations

posted in the area instruct you not to

do so. Hospitals or health care

facilities may be using equipment

that could be sensitive to external

RF energy.

CR Lithium battery

RDo not recharge, disassemble,

remodel, heat or throw it into fire.

Helpline Tel. No.: U.K. 0330 3331112 Ireland 01 4475228 5

Important Information

HNS103EX_(en_en)_0111_ver.105.pdf 5 2017/01/11 18:37:55

RDo not touch the terminals and

with metal objects.

RRisk of explosion if battery is

replaced by an incorrect type.

Dispose of used battery according to

local regulations.

RIf any electrolyte should come into

contact with your hands or clothes,

wash it off thoroughly with water.

RIf any electrolyte should come into

contact with your eyes, never rub

your eyes. Rinse your eyes

thoroughly with water, and then

consult a doctor.

CAUTION

CR Lithium battery

RUse only the battery noted on

page 3.

RInsert the battery correctly.

RDo not leave the battery in an

automobile exposed to direct

sunlight for a long period of time with

the doors and windows closed.

RRemove the battery if you do not

use the product for a long period of

time. Keep it in a cool, dark area.

RDo not replace a battery with wet

hands.

RKeep out of the reach of small

children. There is a risk of

swallowing. If the battery is

swallowed, seek medical attention

immediately.

RRemove the battery if it becomes

unusable. There is a risk of leakage,

overheating, and rupture. Do not

attempt to use a battery if it is

leaking.

RExercise care when handling the

batteries. Do not allow conductive

materials such as rings, bracelets, or

keys to touch the batteries,

otherwise a short circuit may cause

the batteries and/or the conductive

material to overheat and cause

burns.

Important safety

instructions

When using your product, basic safety

precautions should always be followed

to reduce the risk of fire, electric shock,

and injury to persons, including the

following:

1. Use only the batteries indicated in

this document. Do not dispose of

batteries in a fire. They may

explode. Check with local codes for

possible special disposal

instructions.

SAVE THESE INSTRUCTIONS

For best performance

Hub location/avoiding noise

The hub and other compatible

Panasonic devices use radio waves to

communicate with each other.

RFor maximum coverage and

noise-free communications, place

your hub:

– at a convenient, high, and central

location with no obstructions

between the product and hub in

an indoor environment.

– away from electronic appliances

such as TVs, radios, personal

computers, wireless devices, or

other phones.

– facing away from radio frequency

transmitters, such as external

6Helpline Tel. No.: U.K. 0330 3331112 Ireland 01 4475228

Important Information

HNS103EX_(en_en)_0111_ver.105.pdf 6 2017/01/11 18:37:55

antennas of mobile phone cell

stations. (Avoid putting the hub

on a bay window or near a

window.)

RIf the reception for a hub location is

not satisfactory, move the hub to

another location for better reception.

Environment

RKeep the product away from

electrical noise generating devices,

such as fluorescent lamps and

motors.

RThe product should be kept free

from excessive smoke, dust, high

temperature, and vibration.

RThe product should not be exposed

to direct sunlight.

RDo not place heavy objects on top of

the product.

RThe product should be kept away

from heat sources such as radiators,

cookers, etc. It should not be placed

in rooms where the temperature is

less than 0 °C or greater than 40 °C.

ROperating the product near electrical

appliances may cause interference.

Move away from the electrical

appliances.

RDo not allow the probe unit’s metal

probes to make contact with metal

objects. This may reduce the battery

life.

Other information

CAUTION: Risk of explosion if battery

is replaced by an incorrect type.

Dispose of used batteries according to

the instructions.

Routine care

RWipe the outer surface of the

product with a soft moist cloth.

RDo not use benzine, thinner, or any

abrasive powder.

RIf the probe unit’s metal probes

come into contact with a foreign

material (oil, detergent, etc.), the

probes may repel water and

therefore will not be able to properly

detect a water leak. Periodically

check the metal probes and wipe

away any water or foreign material

that has become adhered to the

probes.

RIf the probes come into contact with

water, wipe the probe unit dry. Do

not allow the probes to remain in

contact with water for an extended

period of time, as the probes may

begin to turn black. (This will not

affect the product’s ability to detect a

water leak.)

Disposal of Old Equipment and

Batteries (Only for European Union

and countries with recycling

systems)

These symbols (A, B) on the

products, packaging, and/or

accompanying documents mean that

used electrical and electronic products

and batteries must not be mixed with

general household waste.

For proper treatment, recovery and

recycling of old products and used

Helpline Tel. No.: U.K. 0330 3331112 Ireland 01 4475228 7

Important Information

HNS103EX_(en_en)_0111_ver.105.pdf 7 2017/01/11 18:37:55

batteries, please take them to

applicable collection points in

accordance with your national

legislation.

By disposing of them correctly, you will

help to save valuable resources and

prevent any potential negative effects

on human health and the environment.

For more information about collection

and recycling, please contact your local

municipality.

Penalties may be applicable for

incorrect disposal of this waste, in

accordance with national legislation.

For business users in the European

Union

If you wish to discard electrical and

electronic equipment, please contact

your dealer or supplier for further

information.

Information on Disposal in other

Countries outside the European

Union

These symbols (A, B) are only valid

in the European Union. If you wish to

discard these items, please contact

your local authorities or dealer and ask

for the correct method of disposal.

Note for the battery symbol

This symbol (B) might be used in

combination with a chemical symbol. In

this case it complies with the

requirement set by the Directive for the

chemical involved.

Note for the battery removal

procedure

Refer to “Inserting the battery” on

page 10.

General information

Declaration of Conformity:

RPanasonic Corporation declares that

the radio equipment type

(KX-HNS103) is in compliance with

Directive 2014/53/EU. The full text of

the EU declaration of conformity is

available at the following internet

address:

http://www.ptc.panasonic.eu/doc

Contact to Authorised

Representative:

Panasonic Testing Centre

Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg,

Germany

Ecodesign information

Ecodesign information under EU

Regulation (EC) No. 1275/2008

amended by (EU) Regulation No.

801/2013. From 1 January 2015.

Please visit here: http://

www.ptc.panasonic.eu/erp

Click [Downloads]

a Energy related products information

(Public)

Power consumption in networked

standby and guidance are mentioned in

the web site above.

8Helpline Tel. No.: U.K. 0330 3331112 Ireland 01 4475228

Important Information

HNS103EX_(en_en)_0111_ver.105.pdf 8 2017/01/11 18:37:55

Part names and

functions

Main unit

Main unit cover

M N

Used to confirm the status of the

sensor or register the sensor to

the hub.

LED indicator

Cable

Probe unit

Probes

LED indicator

You can press MN and check the

LED indicator to confirm the sensor’s

status.

After confirming the sensor’s status, we

recommend turning the LED indicator

off by pressing M N again as soon

as possible, otherwise battery life may

be reduced.

Indicator Status

Green, lit No water detected

Red, lit Water detected

Red,

blinking

Sensor is out of range

of the hub

Green,

blinking

slowly

Registration mode

(You pressed and held

MN)

Off No battery power

Note:

RThe LED indicator does not indicate

sensor status if the sensor has not

been registered (page 10).

Setup overview

1Initial setup

Make sure you can access the

system using your mobile device.

For details, refer to the System

Setup Guide included with your

hub.

2Insert the battery

The sensor is battery powered.

3Registration

Required only if the sensor was

purchased separately (i.e., not as

part of a bundle).

4Confirm the usage area

Read the information in this

document to confirm that the

desired installation area is suitable

to proper operation.

5Installation

Install the sensor in the desired

location.

Helpline Tel. No.: U.K. 0330 3331112 Ireland 01 4475228 9

Setup

HNS103EX_(en_en)_0111_ver.105.pdf 9 2017/01/11 18:37:55

Inserting the battery

RUSE ONLY a CR2 Lithium battery.

RConfirm the polarities ( , ).

1Remove the main unit cover.

RLift from the indented area (A)

and open the main unit cover

(B).

2Insert the battery.

3Attach the main unit cover.

Registering the

sensor

This procedure is not required for

devices that were included as part of

a bundle.

Before you can use the sensor, it must

be registered to the hub.

If you purchased devices separately

(i.e., not as part of a bundle), you must

You can register each device by using

the registration buttons or the [Home

Network] app.

Using registration buttons

1Hub:

Press and hold M OTHER

DEVICEN until the LED indicator

blinks slowly in green.

2Sensor:

Remove the main unit cover and

press and hold MN until the

LED indicator blinks slowly in

green (page 9).

RWhen registration is complete,

the hub sounds one long beep.

Note:

RTo cancel without registering the

sensor, press MN on the hub and

on the sensor again.

RIf registration fails, the hub sounds

several short beeps.

Using the app

When you register the sensor by using

the [Home Network] app, you can

assign a name to your devices and

10 Helpline Tel. No.: U.K. 0330 3331112 Ireland 01 4475228

Setup

HNS103EX_(en_en)_0111_ver.105.pdf 10 2017/01/11 18:37:55

Inhaltsverzeichnis

Andere Panasonic Zubehör Handbücher

Panasonic

Panasonic DP-00 Series Bedienungsanleitung

Panasonic

Panasonic MA2SE010G Bedienungsanleitung

Panasonic

Panasonic Grid-EYE AMG88 Series Bedienungsanleitung

Panasonic

Panasonic MA3S7810G Bedienungsanleitung

Panasonic

Panasonic MA5J002E Bedienungsanleitung

Panasonic

Panasonic LA-A1 Bedienungsanleitung

Panasonic

Panasonic HL-C211BE Bedienungsanleitung

Panasonic

Panasonic MA6Z121 Bedienungsanleitung

Panasonic

Panasonic ST4 Series Bedienungsanleitung

Panasonic

Panasonic HG-F1 Series Bedienungsanleitung

Panasonic

Panasonic EX Series Bedienungsanleitung

Panasonic

Panasonic MA24F70 Bedienungsanleitung

Panasonic

Panasonic HG-C1000L Series Bedienungsanleitung

Panasonic

Panasonic MA3X704 Bedienungsanleitung

Panasonic

Panasonic Grid-EYE AMG88 Series Bedienungsanleitung

Panasonic

Panasonic HL-C203B Bedienungsanleitung

Panasonic

Panasonic MALT062H Bedienungsanleitung

Panasonic

Panasonic Touch Pen Montage- und Bedienungsanleitung

Panasonic

Panasonic PM-25 Series Bedienungsanleitung

Panasonic

Panasonic CA-LSR10U - Sirius Satellite Radio Receiver Bedienungsanleitung

Panasonic

Panasonic FX-301 Series Bedienungsanleitung

Panasonic

Panasonic MA2J111 (MA111) Bedienungsanleitung

Panasonic

Panasonic Light Emitting Diodes LN360GPX Bedienungsanleitung

Panasonic

Panasonic CY-100 Series Bedienungsanleitung

Beliebte Zubehör Handbücher anderer Marken

Hillco

Hillco 2810 Bedienungsanleitung

Siemens

Siemens QSA2700D Bedienerhandbuch

Contours

Contours ZY024 Bedienungsanleitung

Saivod

Saivod VS621 Bedienungsanleitung

Virtuox

Virtuox VirtuCLEAN 2.0 Bedienungsanleitung

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Bedienungsanleitung

Z-Wave

Z-Wave HSD-200Z Bedienungsanleitung

turck

turck FMX-IM-2UPLI63FX Bedienungsanleitung

Decagon Devices

Decagon Devices 10HS Bedienungsanleitung

UPPAbaby

UPPAbaby Cup Holder Bedienungsanleitung

Elko

Elko SmartSensor Leakage Wireless Bedienungsanleitung

Grizzly

Grizzly H8371 Bedienungsanleitung

IFM Electronic

IFM Electronic Efector 250 Series Referenzhandbuch

DigiDesign

DigiDesign 888/24 I/O Bedienungsanleitung

PROZIS

PROZIS QUAY Bedienungsanleitung

patagonia

patagonia PSI Vest Bedienungsanleitung

SFC Energy

SFC Energy EFOY GO! Bedienungsanleitung

Axminster

Axminster Tooling Stylus Tip Ballpoint Pen Kit Bedienungsanleitung
