Panasonic ER-206 Bedienungsanleitung

Operating Instructions

(Household) AC/Rechargeable Beard/Hair Trimmer

Model No. ER206

English ............................................. 3

(5B0(LQGE 

(5B0(LQGE 

English

Operating Instructions

(Household) AC/Rechargeable Beard/Hair Trimmer

Model No. ER206

Thank you for purchasing this Panasonic product.

Before operating this unit, please read these instructions completely and save them for future use.

Safety precautions.....................4

Intended use ........................................7

Parts identication ..............................8

Charging the trimmer ..........................8

Attaching and removing the comb

attachment ...........................................9

Using the trimmer ................................9

Trimming Beard .................................10

Cleaning the trimmer.........................10

Troubleshooting ................................12

Frequently asked questions .............12

Blade life.............................................12

Battery life ..........................................12

Removing the built-in rechargeable

battery.................................................13

Specications ....................................13

Contents

(5B0(LQGE 

English

Safety precautions

To reduce the risk of injury, loss of life, electric shock, re, and

damage to property, always observe the following safety precautions.

Explanation of symbols

The following symbols are used to classify and describe the level

of hazard, injury, and property damage caused when the

denotation is disregarded and improper use is performed.

DANGER Denotes a potential

hazard that will result in

serious injury or death.

WARNING Denotes a potential

hazard that could result in

serious injury or death.

CAUTION Denotes a hazard that

could result in minor injury

or property damage.

The following symbols are used to classify and describe the type

of instructions to be observed.

This symbol is used to alert users to a specic operating

procedure that must not be performed.

This symbol is used to alert users to a specic operating

procedure that must be followed in order to operate the

unit safely.

WARNING

Do not connect or disconnect the adaptor to a

household outlet with a wet hand.

- Doing so may cause electric shock or injury.

Never use the appliance if the AC adaptor is

damaged or if the power plug ts loosely in a

household outlet.

Doing so may cause electric shock or re due to a short circuit.

Do not damage the cord or plug.

Do not damage or modify, or forcefully bend, pull,

or twist the cord.

Also, do not place anything heavy on or pinch the cord.

- Doing so may cause electric shock, burn or re due to a

short circuit.

Do not use in a way exceeding the rating of the

household outlet or the wiring.

- Exceeding the rating by connecting too many plugs to one

household outlet may cause re due to overheating.

This product has a built-in rechargeable battery.

Do not throw into ame or heat.

- Doing so may cause uid leak, overheating, or explosion.

Do not modify or repair.

Doing so may cause re, electric shock, or inury.

- Contact an authorized service center for repair (battery

change, etc.).

Never disassemble except when disposing of the

product.

- Doing so may cause re, electric shock, or injury.

(5B0(LQGE 

English

WARNING

Do not use anything other than the supplied AC

adaptor. Also, do not charge any other product with

the supplied AC adaptor. (See page 8.)

- Doing so may cause burn or re due to short circuit.

•Do not immerse the main body and AC adaptor in

water or wash them with water.

•Do not place the appliance over or near water lled

sink or bathtub.

Doing so may cause electric shock or re due to a short circuit.

Keep the appliance dry.

The symbol on the left means “Do not wash the

product with water”.

- Only the blade is washable with water.

Do not store within the reach of children or infants.

Do not let them use it.

- Putting the blade, the cleaning brush and/or oil container

in the mouth may cause accidents and injury.

Immediately stop using and remove the adaptor if

there is an abnormality or malfunction.

- Failure to do so may cause re, electric shock, or injury.

•The main body or AC adaptor is deformed or

abnormally hot.

•The main body or AC adaptor smells of burning.

•There is abnormal sound during use or charging of

the main body or AC adaptor.

- Immediately request inspection or repair at an authorized

service center.

Always unplug the adaptor from a household outlet

when cleaning.

- Failure to do so may cause electric shock or injury.

•Always ensure the main body is operated on an

electric power source matched to the rated voltage

indicated on the AC adaptor.

•Fully insert the adaptor.

- Failure to do so may cause re or electric shock.

Regularly clean the power plug and the appliance

plug to prevent dust from accumulating.

- Failure to do so may cause re due to insulation failure

caused by humidity.

Disconnect the adaptor and wipe with a dry cloth.

If the oil is consumed accidentally, do not induce

vomiting, drink a large amount of water, and contact

a physician.

If the oil comes into contact with eyes, immediately wash

thoroughly with running water, and contact a physician.

- Failure to do so may result in physical problems.

(5B0(LQGE 

English

WARNING

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience and

knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

Children should be supervised to ensure that they

do not play with the appliance.

- Failure to do so may cause an accident or injury.

The supply cord cannot be replaced. If the cord is

damaged, the AC adaptor should be scrapped.

- Failure to do so may cause an accident or injury.

CAUTION

•Do not use excessive pressure to apply the blades

to your lip or other part of your face.

•Do not use this appliance for any purpose other

than trimming beard and hair.

- Doing so may cause skin injury.

Do not directly apply the blades on ears or uneven

skin (such as swellings, inuries or blemishes).

- Doing so may cause injury to ears or uneven skin.

Do not allow pins or trash to adhere to the power

plug or the appliance plug.

Doing so may cause electric shock or re due to a short circuit.

Do not drop or subect to shock.

- Doing so may cause injury.

Do not wrap the cord around the adaptor when storing.

- Doing so may cause the wire in the cord to break with the

load, and may cause re due to short circuit.

Check that the blades are not damaged or deformed

before use.

- Failure to do so may cause skin injury.

Disconnect the adaptor from the household outlet

when not using.

- Failure to do so may cause electric shock or re due to

electrical leakage resulting from insulation deterioration.

Disconnect the adaptor or the appliance plug by

holding onto the adaptor or the appliance plug

instead of the cord.

- Failure to do so may cause electric shock or injury.

(5B0(LQGE 

English

Handling of the removed battery when disposing

DANGER

•The rechargeable battery is exclusively for use

with this appliance. Do not use the battery with

other products.

•Do not charge the battery after it has been

removed from the appliance.

•Do not throw into re or apply heat.

•Do not solder, disassemble, or modify the battery.

•Do not let the positive and negative terminals of

the battery get in contact with each other through

metallic obects.

•Do not carry or store the battery together with

metallic ewellery such as necklaces and hairpins.

•Never peel off the tube.

- Doing so may cause uid leak, overheating, or explosion.

The battery contains alkaline uid. If it comes in

contact with the eyes, do not rub the eyes, and

thoroughly rinse with clean water, such as tap water.

- Failure to do so may cause loss of vision.

Consult a physician immediately.

WARNING

After removing the rechargeable battery, do not

keep it within reach of children and infants.

- The battery will harm the body if accidentally swallowed.

If this happens, consult a physician immediately.

The battery contains alkaline uid. If it comes in

contact with the skin or clothes, rinse off with clean

water, such as tap water.

- Failure to do so may cause skin injury.

Intended use

• Before and after each use, apply oil at the places marked with

circle. (See page 11.)

• Before using an attachment, check that it has been installed correctly.

Failure to do so may cause beard and hair to be cut too short.

• Store the trimmer in a place with low humidity after use.

• The appliance should not be used on animals.

(5B0(LQGE 

English

Parts identication

10 10

11 11

 Main body



Trimming Length Indicator



Power switch (0·charge/1)

 Quick Adjust Dial

 Charge Indicator Lamp

 Appliance socket

 Blade

 Moving Blade

 Stationary Blade

 Cleaning Lever

 Mounting hook

 Comb Attachment



AC adaptor (RE9-16/RE9-55)

• The shape of the AC

adaptor differs depending

on the area.

• One of the power supply

unit specied is provided

with this appliance.

 Adaptor

 Power plug

 Cord

 Appliance plug

Accessories

 Oil

 Cleaning Brush

 Pouch

Charging the trimmer

• Make sure that the trimmer is turned off.

1 Connect the appliance plug

to the appliance socket.

2 Plug in the adaptor into a

household outlet.

• Check that the charge indicator lamp

glows.

• The power switch should be set to

0·charge during charging.

• Charging is completed after approx.

8 hours.

3 After charging is complete, the charge indicator

lamp is solid on. Please disconnect the adaptor

from the household outlet.

Notes

• Recommended ambient temperature for charging is 0 °C –

35 °C. Battery performance may decrease outside of the

recommended temperature.

• A full charge supplies enough power for approximately 50

minutes of use.

The operating time may differ depending on the frequency of

use, the operating method and the ambient temperature.

• When the appliance is not used for 6 months or more, the battery

will weaken (leak battery uid, etc.). Fully charge the battery

once every 6 months.

• When charging the trimmer for the rst time or when it has not

been in use for more than 6 months, the lamp on the main body

may not glow for a few minutes, or the operating time may

shorten. Please charge it for more than 16 hours in such cases.

(5B0(LQGE 

English

AC operation

If you connect the AC adaptor to the trimmer in the same way as

for charging, and turn on the power, you can use it.

• If the remaining battery is too low, the blades may move slowly

or stop, even with the AC operation. In this case, charge the

battery for 3 minutes or more.

• The battery will be discharged, even with the AC operation.

Attaching and removing the comb

attachment

Attaching the comb attachment

Mount the comb attachment to the main body

until “1” appears in the trimming length indicator.

Removing the comb attachment

Hold the main body securely and remove the

comb attachment from the main body.

Using the trimmer

• Make sure that the trimmer is turned off.

• Be careful not to cut your hand with the blade when attaching or

removing the comb attachment.

• The appliance may not operate in an ambient temperature

approximately 0 °C or lower.

1 Mount the comb attachment.

• It can also be used without the comb

attachment. (Trimming height: approx. 0.5 mm)

2 Turn the dial and adust the

trimming length indication

mark to the desired length.

• For more length settings, please refer

the table.

0·charge

Indicator 123456

Trimming Length (mm)

(estimate) 234.567.59

Indicator 7 8 9 10 11 12

Trimming Length (mm)

(estimate) 10.5 12 13.5 15 16.5 18

(5B0(LQGE 

English

3 Slide the power switch upwards to

turn on the appliance.

Trimming Beard

Place the angled face of the comb against the

skin and cut the beard by moving the trimmer in

all directions to obtain a uniform cut.

With curly facial hair, the comb attachment may

not cut all of the hair. In this case, remove the

comb attachment and use a conventional comb to

draw out the remaining uncut hair.

When shaping the beard, remove the comb

attachment. Place the angled edge against the

skin and make the border of the beard even.

• Beard trimmings may collect inside the

attachment when a large volume of beard is cut,

so discard beard trimmings after each use.

Cleaning the trimmer

• Make sure that the trimmer is turned off.

• Clean the housing only with a soft cloth slightly dampened with

tap water or soapy tap water. Do not use thinner, benzine,

alcohol or other chemicals.

It is recommended to clean after every use.

1. Remove the trimmer from the AC adaptor.

2. Remove the comb attachment.

3. Hold the main body, place your thumb

against the blades and then push them

away from the main body.

4. Brush off any beard and

hair trimmings from the

main body and from around

the blade.

5. Brush any beard and hair trimmings

out from between the stationary blade

and the moving blade while pressing

down the cleaning lever to raise the

moving blade.

6. Apply the oil to the blade. (See page 11.)

7. Attach the comb attachment and

blades to the trimmer.

(5B0(LQGE 

Andere Handbücher für ER-206

Inhaltsverzeichnis

Andere Panasonic Elektrorasierer Handbücher

Panasonic

Panasonic ES4011K Operating Bedienungsanleitung

Panasonic

Panasonic ER421KC Bedienungsanleitung

Panasonic

Panasonic ER-GN30 Bedienungsanleitung

Panasonic

Panasonic ES-RP50 Bedienungsanleitung

Panasonic

Panasonic ES-RC20 Bedienungsanleitung

Panasonic

Panasonic ES-SWLT2 Bedienungsanleitung

Panasonic

Panasonic ES-8163 Bedienungsanleitung

Panasonic

Panasonic ES726K Operating Bedienungsanleitung

Panasonic

Panasonic ES-LV81 Bedienungsanleitung

Panasonic

Panasonic ER-CTW1 Bedienungsanleitung

Panasonic

Panasonic ES8249 Bedienungsanleitung

Panasonic

Panasonic ER-GD61 Bedienungsanleitung

Panasonic

Panasonic ES-7016 Bedienungsanleitung

Panasonic

Panasonic ES-LA63A Bedienungsanleitung

Panasonic

Panasonic ES-LT7N Bedienungsanleitung

Panasonic

Panasonic ER?GY50 Bedienungsanleitung

Panasonic

Panasonic ER2031 Bedienungsanleitung

Panasonic

Panasonic ES7036 Bedienungsanleitung

Panasonic

Panasonic ES8243AA Bedienungsanleitung

Panasonic

Panasonic ES-SA40 Bedienungsanleitung

Panasonic

Panasonic ER-GK60 Bedienungsanleitung

Panasonic

Panasonic ER-407 Bedienungsanleitung

Panasonic

Panasonic ES8113 Bedienungsanleitung

Panasonic

Panasonic ES?LV95 Bedienungsanleitung

Beliebte Elektrorasierer Handbücher anderer Marken

Philips

Philips MicroAction 4402LC Bedienungsanleitung

Philips

Philips HQ7740 Bedienungsanleitung

Philips

Philips Norelco BG2022 Bodygroom Bedienungsanleitung

Norelco

Norelco Quadra 7610X Bedienungsanleitung

Philips

Philips 7616X Bedienungsanleitung

Philips

Philips HQ802 Bedienungsanleitung

Philips

Philips HQ7363/17 Bedienungsanleitung

Braun

Braun WaterFlex WF2s Bedienungsanleitung

Philips

Philips NORELCO S7371 Bedienungsanleitung

Daga

Daga MT-400 Handbuch

Philips

Philips RQ119x Bedienungsanleitung

Remington

Remington BHT100 Bedienungsanleitung

Philips

Philips Bodygroom BG2000 Bedienungsanleitung

Kompernass

Kompernass KH 5537 Bedienungsanleitung

Remington

Remington BHT6100 Bedienungsanleitung

Philips

Philips qc5365 Bedienungsanleitung

MIA

MIA Aqua Body Bedienungsanleitung

Philips

Philips NORELCO AT880 Bedienungsanleitung
