Panasonic ER-2403 Bedienungsanleitung

Operating Instructions

使用說明書

사용 설명서

คู่มือการใช้งาน

Body Hair & Beard Trimmer

體毛 / 鬍子修剪器

체모 / 수염 트리머

เครื่องโกนขน/กันหนวดเครา

Model No.

型號

모델 번호

เลขที่รุ่น

ER2403

Before operating this unit, please read these instructions completely.

操作此產品前，請先讀畢此守則。

이 기기를 사용하기 전에 먼저 본 설명서를 자세히 읽어 주십시오.

โปรดอ่านคำแนะนำโดยละเอียดก่อน

English 2

中文 8

한글 13

ไทย 19

English

Safety Instructions

To ensure proper operation of the appliance, please carefully read all

information contained in these Safety Instructions.

All information in this section is provided to instruct you in the correct and safe

operation of this appliance so that you can avoid injuries to yourself and others

as well as damage to property.

Safety warnings, cautions and precaution symbols are distinguished as follows.

ALWAYS FOLLOW THESE IMPORTANT SAFETY PRECAUTIONS!

CAUTION:

This message indicates potentially hazardous actions and situations, which, if

not avoided, could result in personal injury or property damage.

Safety Precautions Symbols

A circle and slash symbolizes prohibited actions and behaviors.

A solid circle denotes mandatory actions and instructions to be followed for

safe operation.

After reading these safety instructions, ensure they are kept in a place

allowing easy viewing at all times by the appliance user.

CAUTION!

Prohibited!

Do not press the blades with excessive force against the soft parts of

your skin such as your lips, chin and around the nape of your neck.

It may damage your skin.

Do not use the appliance except for its intended use to cut beards,

moustaches, sideburns and downy hair.

It may damage your skin.

Do not dismantle!

Do not alter the appliance. Also, do not disassemble or repair it.

It could result in ﬁre, electric shock or injury. Contact the shop where you

purchased the appliance or your nearest servicenter for repairs.

Mandatory!

Be sure to lubricate the blades before using them.

Not doing this may cause the appliance to pull your hairs or damage your skin.

Check that the blades are not damaged before using them.

Not doing this may damage your skin.



English

Important

Cautions for use and storage

The appliance may become warm during operation. This is normal.

Turn off the appliance before changing the trimming length or

removing the comb attachment.

Close supervision is necessary when the appliance is used by, on,

or near children or invalids.

Use the appliance only for its intended use as described in these

operating instructions. We strongly recommend that you do not use

comb attachments not recommended by the manufacturer.

We strongly recommend that you do not tamper with the moving

parts.

We strongly recommend that you do not use the appliance on

animals.

We strongly recommend that you do not disassemble the appliance.

Take it to a qualiﬁed serviceperson when service or repair is

required.

We strongly recommend that you do not store the appliance in a

place exposed to direct sunlight or near a heater or other source of

heat.

We strongly recommend that you do not place or store the appliance

where it can fall into a bath or a sink. We strongly recommend that

you do not place it in or drop into water or other liquids.

Cautions for cleaning

We strongly recommend that you do not take the housing apart as

this can affect the watertight construction of the appliance.

Wash the appliance in tap water. We strongly recommend that you

do not use salt water or boiling water. Also, we strongly recommend

that you do not use cleaning products that are designed for toilets,

bathrooms or kitchen appliances. We strongly recommend that you

do not submerge the appliance in tap water for a long time.

Clean the housing only with a soft cloth slightly dampened with tap

water or soapy tap water. We strongly recommend that you do not

use a caustic cleaner such as benzine or bleach.

SPECIFICATIONS

Batteries: Two AAA (LR03) dry-cell batteries (DC 3.0 V)

(Sold separately)

Weight: 128 g(including comb attachment and batteries)

This product is intended for household use only.



•



•

English

Parts identiﬁcation

AMain body

1Mounting hook

2Trimming length

indicator

3Switch

4Battery cover

BBlade block

5Cleaning lever

6Moving blade

7Stationary blade

CComb attachment

DOil

ECleaning brush

























Replacing batteries

1. Slide the switch on the main body downwards to turn

off the trimmer.

2. Remove the battery cover and insert two AAA (LR03)

dry-cell batteries as illustrated.

3. Reattach the battery cover.

We strongly recommend that you do not mix old and new

batteries.

Remove the batteries when not using the trimmer for a long

time.

•

English

Using the trimmer

Use

Trimming your moustache

1. Apply a few drops of the oil to the

blades.

2. Grasp the sides of the comb

attachment and move it to the

desired trimming length (between

3 mm and 15 mm).

Indicator Trimming length

3 3 mm

6 6 mm

9 9 mm

12 12 mm

15 15 mm

3. Slide the switch on the main body upwards to turn on

the trimmer.

4. Move the trimmer upwards with the

switch on the main body facing

downwards as illustrated.

Shaping your moustache

1. Remove the comb attachment and

turn on the trimmer.

2. Trim around your moustache.



English

Shaping your sideburns

1. Remove the comb attachment and

turn on the trimmer.

2. Place the trimmer at a right angle to

your skin and cut your sideburns.

Trimming your body hair

You can also trim your body hair.

After using the trimmer

Using the cleaning brush

1. Hold the main body, place your

thumb against the blades and then

push them away from the main

body.

2. Brush off any hair trimmings from

the main body and from around the

blade.

3. Brush any hair trimmings out from

between the stationary blade and

the moving blade while pressing

down the cleaning lever to raise the

moving blade.

Washing with water

The following is the symbol for a wet trimmer. The

symbol means the hand-held part may be used in a

bath or shower.



English

1. Remove the blade.

2. Rinse off any hair trimmings that are

sticking to the blade with running

water.

3. Rinse out any hair trimmings that

are inside the trimmer with running

water.

We strongly recommend that you do not

remove the battery cover when washing

the main body.

•

4. Gently shake the trimmer 4 or 5 times and then wipe off

any water drops from the trimmer and the blade.

5. Place the trimmer on a towel with the switch on the

main body facing downwards to let it dry fully.

Lubrication

Lubricate the blades before using them or

after cleaning them.

1.Apply a few drops of the oil to the

points indicated by the arrows.

Remounting the blade

1.Fit the mounting hook into the blade

mounting on the trimmer and then push

in until it clicks.

Blade life

Blade life varies according to the frequency and length of use of

the trimmer.

For example, the blade life is approximately 3 years when using

the trimmer for 5 minutes 10 times a month. Replace the blades if

cutting efﬁciency reduces substantially despite proper

maintenance.



中文

重要事項

使用與儲存注意事項

機器於運作時機身會變暖。這是正常情形。

變更修剪長度或移除梳子附件時要關閉機器。

若兒童或殘疾者使用、或在其附近使用時，必須緊密監控使用情

形。

僅依據此等操作指示及機器之正確用途，使用本機器。不得使用

製造商未建議之梳子附件。

不得干擾可移動式零件。

不得用在動物身上。

不得拆解機器。如需保養或維修，請洽詢合格之維修服務人員。

不得將機器儲存在直接日照之處，以及靠近暖器或其它熱源之

處。

不得將機器放置或儲存在可掉落至浴缸或水槽之處。不得將機器

放在，或使之掉落水或其它液體中。

清潔注意事項

不得拆解外蓋，以免影響機器的防水結構。

以自來水沖洗機器。不得使用鹽水或開水。也不得使用衛浴或廚

房清潔用品來清潔產品。不得長時間將機器浸泡於自來水中。

僅使用柔軟的布稍微沾濕自來水或沾有肥皂的自來水來清潔外

蓋。不得使用類似揮發油或漂白水等腐蝕性清潔劑。

規格

電池︰兩枚AAA(LR03)乾性電池(DC3.0V)

(獨立銷售)

重量︰128g(包括梳子附件和電池)

本產品僅供居家使用。



•



•

中文

部件說明

A主機體

1底座掛鉤

2修剪長度指示器

3切換鈕

4電池蓋

B刀片封口

5清潔桿

6移動刀片

7固定刀片

C梳子附件

D油

E清潔刷

























更換電池

1. 將主機體的切換鈕往下滑動，關閉修剪器。

2. 如圖所示，移除電池蓋，插入兩枚AAA(LR03)乾性電池。

3. 重新裝回電池蓋。

不得混合使用新舊電池。

若長時間不使用修剪器，請移除電池。

•

中文

使用修剪器

使用方法

修剪鬍子

1. 放數滴油在刀片上。

2. 抓住梳子附件的側邊，將它移動至所需

的修剪長度(3mm至15mm)之間。

指示器修剪長度

3 3mm

6 6mm

9 9mm

12 12mm

15 15mm

3. 將主機體的切換鈕向上滑動，開啟修剪器。

4. 如圖所示，向上移動修剪器，主機體上

的切換鈕朝下。

修整鬍子

1. 移除梳子附件，開啟修剪器。

2. 修整鬍子。


