Paxar TC6032EM Technisches Dokument

Monarch®

Pathfinder®Ultra®

Printer

Each product and program carries a respective written warranty, the only

warranty on which the customer can rely. Paxar reserves the right to make

changes in the product and the programs and their availability at any time and

without notice. Although Paxar has made every effort to provide complete and

accurate information in this manual, Paxar shall not be liable for any omissions

or inaccuracies. Any update will be incorporated in a later edition of

this manual.

reserved. No part of this publication may be reproduced, transmitted, stored in

a retrieval system, or translated into any language in any form by any means,

without the written permission of Paxar Americas, Inc.

Trademarks

Monarch®, Pathfinder®, Ultra®, Pathfinder® Ultra®, 6032, 9462, and 9465 are registered trademarks of

Paxar Americas, Inc.

Paxar® is a trademark of Paxar Corporation.

Avery Dennison® is a trademark of Avery Dennison Corporation.

RBRC® is a trademark of Rechargeable Battery Recycling Corporation.

Avery Dennison Printer Systems Division

170 Monarch Lane

Miamisburg, OH 45342

TABLE OF CONTENTS

INTRODUCTION 1-1

Using This Manual .................................................................................. 1-1

Audience................................................................................................ 1-1

Getting Started ....................................................................................... 1-2

Helpful Reminders................................................................................... 1-2

Attaching the Safety Strap ....................................................................... 1-3

USING BATTERIES 2-1

Using the Main Battery ............................................................................ 2-1

Changing the Main Battery.................................................................... 2-2

Replacing the Backup Battery .................................................................. 2-3

Main Battery Safety Information................................................................ 2-4

USING SUPPLIES 3-1

Loading Supplies .................................................................................... 3-1

Loading for Peel Mode ......................................................................... 3-3

Loading for Non-Peel Mode .................................................................. 3-6

Removing the Supply Roll in Peel Mode .................................................... 3-6

ENTERING & PRINTING DATA 4-1

Using the Keypad.................................................................................... 4-1

Data Entry Modes ................................................................................ 4-2

Entering Letters................................................................................... 4-3

Using the Display.................................................................................... 4-3

Reading the Status Line ....................................................................... 4-3

Scanning Bar Codes................................................................................ 4-4

Scanner Certification Note ....................................................................... 4-5

Printing.................................................................................................. 4-6

Power Management................................................................................. 4-6

CARE & MAINTENANCE 5-1

Cleaning ................................................................................................ 5-1

Cleaning the Printhead......................................................................... 5-2

Cleaning the Platen Roller .................................................................... 5-3

Cleaning the Black Mark Sensor............................................................ 5-4

Cleaning the Scanner Window............................................................... 5-4

Cleaning the Scanner Flex Cable .......................................................... 5-5

Clearing Supply Jams.............................................................................. 5-5

Storing the Printer................................................................................... 5-6

TROUBLESHOOTING 6-1

Error Codes ........................................................................................ 6-2

SPECIFICATIONS & ACCESSORIES A-1

Specifications.........................................................................................A-1

Accessories............................................................................................A-2

GLOSSARY G-1

Introduction 1-1

INTRODUCTION

The Monarch® Pathfinder® Ultra® Silver 6032™ printer scans bar

codes and prints.

Using This Manual

Following is a summary of the contents of this manual.

Chapter Contents

1 Introduction Information you should know before using the printer.

2 Using Batteries Charging, changing, and using batteries safely.

3 Using Supplies Loading and removing supplies.

4 Entering and

Printing Data

Using the keypad and scanner, and printing.

5 Care and

Maintenance

Clearing supply jams and cleaning the printer.

6 Troubleshooting Common problems and their solutions.

A Specifications &

Accessories

Printer specifications and accessories/options.

G Glossary Printer terms and their definitions.

Audience

This manual is for the person who prints and applies labels and scans bar

codes.

A Quick Reference for this printer is available in the box. A Packet

Reference Manual and other documentation are available on our Web site.

Information in this document supercedes information in previous versions.

Check our Web site (www.paxar.com) for the latest documentation and

release information.

1-2 Equipment Manual

Getting Started

To start using the printer, you must:

1. Review the printer safety information in the Regulatory Compliance

document provided with your printer.

2. Charge the battery. See “Charging the Battery” in Chapter 2 for more

information.

Note: Charge the battery as soon as you receive the printer, even if you

do not use it right away.

3. Insert the charged battery in the printer. See “Changing the Battery” in

Chapter 2 for more information.

4. Attach the safety strap found in the documentation package. See

“Attaching the Safety Strap ” later in this chapter for more information.

5. Load supplies in the printer. See “Loading Supplies” in Chapter 3 for

more information.

6. Turn on the printer.

Helpful Reminders

♦ Always start with a fully charged battery.

♦ Attach the safety strap to your wrist before using the printer.

♦ Do not pound the printer when applying labels printed in peel mode.

♦ Switch to a fully charged battery every time you load a new roll of

supplies. This ensures optimum print quality.

♦ Turn off the printer when you are not using it.

♦ Operate and store the printer within the recommended temperature and

humidity ranges. See “Specifications” in Appendix A for more

information.

Introduction 1-3

Attaching the Safety Strap

1. Turn the printer upside down, resting its top on the

table.

2. Take the thin end of the safety strap and push it

through the loop at the bottom of the printer handle

(near the battery compartment).

3. Push the thick end of the safety strap through the

thin end’s loop.

4. Pull the strap. It may be necessary to help the

thin end’s loop fit over the plastic piece in the

middle of the strap.

5. Pull the strap tight.

1-4 Equipment Manual

Using Batteries 2-1

USING BATTERIES

The printer uses two batteries: a main battery and a backup

battery.

Battery Use

Main Running the printer. It is also rechargeable using the

Monarch9462single-station or the Monarch9465

four-station charger.

Backup Maintaining the printer’s system settings.

Using the Main Battery

The printer’s main power source is a 7.4V lithium-ion battery.

Note: The printer only takes this battery. Do not substitute batteries.

You must charge the battery when you receive the printer, even if you do not

use it right away.

Charging the Main Battery

To charge the main battery, use either the 9462 single-station

or 9465 four-station battery chargers. Refer to the

documentation provided with the chargers for more

information. Charging time is approximately 1.5 – 3 hours.

Warning: The battery might explode if placed on a

different charger.

2-2 Equipment Manual

Changing the Main Battery

To change the main battery:

1. Turn the printer over and press the button on the battery compartment

door (at the bottom of the printer’s handle) and slide it open.

2. Turn the printer upright, holding your palm beneath the open battery

compartment. Hit the printer on your hand and catch the battery as it

slides out.

3. Insert a new battery into the compartment (connector end first).

4. Slide the compartment door shut until it clicks into place.

Battery

Button

Battery Compartment Door
