40-755 User Manual

PXI 50 Ω & 75 Ω RF Multiplexer SP4T Module

Page (II) PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Testing Operation ..................................................................3.3

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Modules ............4.1

Multiplexer Module Architecture..........................................4.2

Programming The Multiplexer Module ................................4.3

Using Pickering Drivers in LabVIEW ...................................4.4

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting.........................................................................6.1

Section 7

Maintenance Information............................................................7.1

Switching System Test Tools ...............................................7.1

Relay Lookup Tables.............................................................7.1

CONTENTS

Page (VI) PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755

pickering

Page (VII)

REED RELAY MODULE 40-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user

I/O signals that may be present. Blanking panels are available to order from Pickering in a variety

of slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page (VIII) PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755

pickering

THIS PAGE INTENTIONALLY BLANK

Page 1.1

PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI SP4T RF Multiplexer 40-755

ISSUE 5.1 MAY 2022

Supported by

eBIRST

SMB builds of this product are supported by eBIRST test

tools which simplify fault-ﬁnding by quickly testing the

system and graphically identifying the faulty relay.

For more information go to: pickeringtest.com/ebirst

yUp To 10off SP4T in a Single Module

y1.8 GHz Switching (50 Ω SMB Version)

y1.3 GHz Switching (75 Ω SMB Version)

y1.3 GHz Switching (50 Ω Multiway Version)

y1.3 GHz Switching (75 Ω Multiway Version)

ySMB and Multiway Connector Versions

yLow Cost, High Performance

yVISA, IVI & Kernel Drivers Supplied for

Windows

ySupported by PXI or LXI Chassis

ySupported by

eBIRST

™

y3 Year Warranty

BANK 1

BANK 2

BANK 3

BANK 4

BANK 5

BANK 6

BANK 7

BANK 8

BANK 9

C10

BANK 10

40-755-x10 10 off SP4T RF MUX

Switching Diagram (Default Switch Paths Shown)

The 40-755 is a high density RF multiplexer available in

50 Ω and 75 Ω variants with up to 10xSP4T switches in

a single PXI module. It is available with two connector

options; SMB that provides a frequency range of 1.8 GHz

(50 Ω) / 1.3 GHz (75 Ω), or multiway which limits the

bandwidth to 1.3 GHz but offers a high density solution

occupying one PXI slot. The connectors used are fully

supported by the range of Pickering Interfaces connection

solutions.

40-755 RF Multiplexer Range:

10 off SP4T, 50 Ω, 1.8 GHz, SMB, Dual PXI Slot

10 off SP4T, 50 Ω, 1.3 GHz, Multiway, Single PXI Slot

5 off SP4T, 50 Ω, 1.3 GHz, Multiway, Single PXI Slot

4 off SP4T, 50 Ω, 1.8 GHz, SMB, Single PXI Slot

10 off SP4T, 75 Ω, 1.3 GHz, SMB, Dual PXI Slot

10 off SP4T, 75 Ω, 1.3 GHz, Multiway, Single PXI Slot

5 off SP4T, 75 Ω, 1.3 GHz, Multiway, Single PXI Slot

4 off SP4T, 75 Ω, 1.3 GHz, SMB, Single PXI Slot

The module offers low insertion loss and low VSWR through

its usable frequency range and each multiplexer has been

designed to have path independent loss.

The array of SP4T switches can be connected into alternative

conﬁgurations through the use of external cabling.

The 40-755 is supplied with drivers that allow the user

to support the module in all popular PXI software

environments. In addition, the module can be supported in

all Pickering’s LXI Modular Chassis, allowing the use of a

PXI or LAN controlled switching solution with the same high

levels of performance.

Page 1.2 PXI 50 Ω & 75 Ω RF MULTIPLEXER SP4T MODULE 40-755

pickering

SECTION 1 - TECHNICAL SPECIFICATION

SP4T RF Multiplexer, 40-755

pickeringtest.com

Speciﬁcations

RF Speciﬁcation

Impedance: 50 Ω

RF Frequency Range: DC to 1.3 GHz

Insertion Loss: <1 dB to 500 MHz (typically 0.7 dB)

2.5 dB to 1.3 GHz (typically 2.0 dB)

VSWR: <1.8:1 to 500 MHz

(typically 1.5:1 max)

3.2:1 to 1.3 GHz (typically 2.8:1)

Isolation: >50 dB to 1.3 GHz

(typically >55 dB)

Crosstalk: <-50 dB to 1.3 GHz

(typically <-55 dB)

Maximum RF Power: 10 W at 1.3 GHz

Other Switching Speciﬁcation

Maximum Hot Switch Voltage: 200 VDC or AC peak

Maximum Hot Switch Current: 1 A

Maximum Cold Switch Current: 1 A

Maximum Hot Switch Power: 10 W

Operating Time: 3 ms typical

Life Expectancy: 10 million operations

at <100 mW

40-755 Speciﬁcation - 50 Ω Versions with Multiway Connectors

Typical insertion loss plot - 50 Ω multiway

Typical VSWR plot - 50 Ω multiway

Typical bank to bank crosstalk plot - 50 Ω multiway

Typical channel to common isolation plot - 50 Ω multiway

40-755-010 10off SP4T RF MUX with

MS-M RF

multiway

connectors

Inhaltsverzeichnis

Andere Pickering Steuereinheit Handbücher

Pickering

Pickering 4 785C Series Bedienungsanleitung

Pickering

Pickering 40-220A Bedienungsanleitung

Pickering

Pickering SYSTEM 10 Bedienungsanleitung

Pickering

Pickering PXI 40-795-001 Bedienungsanleitung

Pickering

Pickering SYSTEM 10 Bedienungsanleitung

Pickering

Pickering PXI BRIC 40-595A Bedienungsanleitung

Pickering

Pickering SYSTEM 10 Bedienungsanleitung

Pickering

Pickering PXI 40-855 Bedienungsanleitung

Pickering

Pickering 40-880 Bedienungsanleitung

Pickering

Pickering 40-519B Bedienungsanleitung

Pickering

Pickering Pxi 41-182A Bedienungsanleitung

Pickering

Pickering 40-280 Bedienungsanleitung

Pickering

Pickering 40-191B Bedienungsanleitung

Pickering

Pickering 40-290-021 Bedienungsanleitung

Pickering

Pickering 43-182B Bedienungsanleitung

Pickering

Pickering 40-540 Bedienungsanleitung

Pickering

Pickering 40-670 Bedienungsanleitung

Pickering

Pickering 40-534 Bedienungsanleitung

Pickering

Pickering 40-727 Bedienungsanleitung

Pickering

Pickering 40-296 Bedienungsanleitung

Pickering

Pickering PXI 41-752 Bedienungsanleitung

Pickering

Pickering 4x-727A Bedienungsanleitung

Pickering

Pickering PXI BRIC 40-562A Bedienungsanleitung

Pickering

Pickering 40-565A Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
