Page 1.1

6-CHANNEL BATTERY SIMULATOR MODULE 41-752

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

41-752

6 Channel Battery Simulator Module

●6 Power Supplies In A Single PXI Slot

●Independent Sense Connections

●Ideal For Battery Stack Emulation

●750V Independent Isolation Barriers

●Up To 300mA Output Per Simulator

●Battery Charging Emulation To 100mA

●Uses Backplane Power Sources

●Hardware shutdown control

●VISA and Kernel Drivers Supplied For

Windows XP/Vista/7/8 Plus Soft Front Panel

●Use In Pickering 19-Slot PXI Chassis Or

18-Slot LXI Chassis

The 41-752 is a 6 channel battery simulator, each channel

being capable of supplying up to 7V and 300mA to the

load. Each channel is fully isolated from ground and from

each other allowing the channels to be connected in series

to simulate batteries arranged in a stacked architecture. The

750V isolation barrier permits the 41-752 to be used to

create a lower power version of a battery stack representative

of those used for vehicle propulsion.

Each battery simulator provides independent power and

sense connections, allowing the battery simulator to sense

a remote load and correct for wiring voltage losses. The

battery simulator is designed to respond to dynamic loads,

minimizing the need for local decoupling capacitors at the

load.

A signal line on the user connector allows the user to

shutdown all battery simulator channels with a single

connection. Mulitple module control lines may be linked

together to provide an easy way of inhibiting voltage

generation when using many series connected modules

that provide high output voltages and providing a means of

automatic shutdown when connectors are removed.

ISSUE 3.0 JUN 2013

Soft Front Panel for The 41-752 Battery Simulator

POWER AND CONTROL FROM PXI BACKPLANE

CHANNEL 1

Vout+ Sense+Vout- Sense-

Current

Sink

Voltage

Source

CHANNEL 2

V+ S+V- S-

CHANNEL 3

V+ S+V- S-

CHANNEL 4

V+ S+V- S-

CHANNEL 5

V+ S+V- S-

CHANNEL 6

V+ S+V- S-

37-WAY D-TYPE CONNECTOR

Functional Block

Diagram For The

41-752 6-Channel

Battery Simulator

The 41-752 can be used as a 6 channel fully isolated power

supply with independent sense lines on each channel

The user connector is a 37-way high voltage D Type which

is fully supported by the wide range of Pickering Interfaces

connector accessories.

Page 1.2 6-CHANNEL BATTERY SIMULATOR MODULE 41-752

pickering

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

Power Requirements from PXI Power Supply

+3.3V +5V +12V -12V

0.8A 2.0A 0.6A 0.3A

At maximum load for all channels,

Recommended chassis are 60-103 and 60-103A or 40-923

and 40-923A for applications requiring many modules (up to

18 off) in a single chassis to avoid chassis limitations.

Speciﬁcation

Number of Channels: 6 independent isolated channels.

Output Voltage Range:

0 to 7V, settable with 14-bit

resolution (approximately 0.43mV).

Output Voltage Accuracy:

0.2%

20mV from 1V to 7V output

over ambient temperature range

+ 11

C to +31

Isolation Voltage: ±750V

Output Current: Up to 300mA per channel for

voltages from 2.5V to 7V

Linearly de-rate to 200mA into a

short circuit below 2.5V without

thermal shutdown.

Current Sink: Variable current sink permits

the output to be loaded so the

battery simulator can sink current

from a charger. Current sink can

be set from 0 to 100mA in 16

steps. Current sink setting reduces

the current available at the user

connector.

Output Connections: Vout+, Vout- and two sense inputs

for each simulator channel.

Sense inputs detect output voltage

at front panel connector if no

remote sense lines are connected.

Load Response Time: 250µs

Power Source: PXI backplane +12V, +5V, +3.3V

and -12V.

Protection: All simulators are short circuit

protected, reverse voltage

protected and include thermal

shutdown.

Output Connector: 37-way D-type, high voltage

PXI Characteristics

Backplane connection: 33MHz, 32-bit.

Mechanical: 3U, 1-slot.

Mating Connectors & Cabling

For connection accessories for the 41-752 please refer to the

90-007D 37-way D-Type Connector Accessories data sheet

where a complete list and documentation can be found for

accessories.

Product Order Codes

Battery Simulator, 6-Channel 41-752-001

Inhaltsverzeichnis

Andere Pickering Steuereinheit Handbücher

Pickering

Pickering PXI 40-535 Bedienungsanleitung

Pickering

Pickering PXI BRIC 40-563A Bedienungsanleitung

Pickering

Pickering PXI 40-795-001 Bedienungsanleitung

Pickering

Pickering 40-331 Bedienungsanleitung

Pickering

Pickering 40-618A Bedienungsanleitung

Pickering

Pickering BRIC Series Bedienungsanleitung

Pickering

Pickering 40-584 Bedienungsanleitung

Pickering

Pickering PXI 40-787 Bedienungsanleitung

Pickering

Pickering 40-553A Bedienungsanleitung

Pickering

Pickering PXI 40-664A Bedienungsanleitung

Pickering

Pickering 40-884A Bedienungsanleitung

Pickering

Pickering 40-670A Bedienungsanleitung

Pickering

Pickering 40-880 Bedienungsanleitung

Pickering

Pickering 40-540 Bedienungsanleitung

Pickering

Pickering 40-252 Bedienungsanleitung

Pickering

Pickering 40-565A Bedienungsanleitung

Pickering

Pickering 40-296 Bedienungsanleitung

Pickering

Pickering 40-522 Bedienungsanleitung

Pickering

Pickering 41-760 Bedienungsanleitung

Pickering

Pickering 40-582 Bedienungsanleitung

Pickering

Pickering PXI 40-785 Bedienungsanleitung

Pickering

Pickering 40-575 Bedienungsanleitung

Pickering

Pickering 42-724 Bedienungsanleitung

Pickering

Pickering Module Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
