Page 1.1

32X8 RF MATRIX MODULE 40/42-724

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI/PXIe 32x8 RF Coaxial Matrix Modules 40/42-724

ISSUE 1.2 NOV 2022

yAvailable as PXI or PXIe Modules

yEasy to Use Loop-thru Option Allows Unlimited

X Axis Expansion

y300 MHz Usable Bandwidth, 150 MHz With Loop-thru

yVISA & IVI Drivers Supplied for Windows

yPXI Version Supported by PXI or LXI Chassis

ySupported by

eBIRST

™

y3 Year Warranty

40/42-724-021-L

32x8 Matrix With

Loop-Thru

The 40-724 (PXI) and 42-724 (PXIe) are RF matrix modules

suitable for switching frequencies up to 300 MHz. Having a

50 Ω characteristic impedance and front panel SMB

connectors, these modules provide a simple and scalable

bidirectional matrix for RF and are intended for the easy

construction of high performance switching systems.

The 40/42-724-021-L version includes Y loop-thru connectors

to allow easy matrix expansion between adjacent modules.

All X and Y connections have isolation switches. These can be

used to disconnect the matrix from the external test ﬁxture to

maximize isolation and RF performance.

Matrix Operation

The 40/42-724 is a high density matrix designed to provide a

Y to X connection to maximize bandwidth.

This module is based on the same construction as the

popular 40-725 RF matrix, but has increased capacity and

optional Y axis loop thru allowing easy expansion.

Supported by

eBIRST

This module is supported by eBIRST test tools. These

simplify switching fault-ﬁnding by quickly testing the

system and graphically identifying the faulty relay.

For more information go to: pickeringtest.com/ebirst

Other RF Matrix Modules in Pickering’s PXI Range:

40-725 8x9 500 MHz, 50 Ω/75 Ω

40-726A 12x8 300 MHz, 50 Ω/75 Ω - Optional Y Loop-Thru

40-727 16x4 300 MHz, 50 Ω/75 Ω - Optional Y Loop-Thru

40-728 16x2 300 MHz, 50 Ω/75 Ω - Optional Y Loop-Thru

40-729 8x4 300 MHz, 50 Ω/75 Ω - Optional Y Loop-Thru

40-750 8x2 1.5 GHz, 50 Ω/75 Ω - Y Loop-Thru

40/42-877A Single/dual 2x2 2.5 GHz, 50 Ω

40/42-837A Single/dual 2x2 2.5 GHz, 75 Ω

45-720A 6 U, 16x16 250 MHz, 50 Ω/75 Ω - Y Loop-Thru

Alternative LXI Ethernet Controlled RF Matrices:

60-760 Single/Dual 24x8 25 MHz, 50 Ω

60-711 Single/Dual 24x8 25 MHz, 75 Ω

65-110A Scalable 24x8 to 104x16 200 MHz, 50 Ω

X30

X31

X32

Isolation

Switches

Crosspoint

40/42-724-021 32x8 Matrix Without Loop-Thru

X30

X31

X32

Isolation

Switches

Crosspoint

YLT1

YLT2

YLT3

YLT4

YLT5

YLT6

YLT7

YLT8

Page 1.2 32X8 RF MATRIX MODULE 40/42-724

pickering

SECTION 1 - TECHNICAL SPECIFICATION

32x8 RF Coaxial Matrix, 40/42-724

pickeringtest.com

Overview

96x8 RF Matrix Created from 2-off 40/42-724-021-L and 1-off 40/42-724-021

(Loop-thru cables interconnect the Y-buses of each 32x8 matrix module)

Y Axis Loop-Thru

The easy to use loop-thru option allows 40/42-724 modules to be cascaded to form larger matrices whilst

minimizing impact on RF performance.

The 40/42-724-021-L version of the module has Y loop-thru connectors on the front panel which are simply

plugged into the Y connectors of the adjacent matrix module via SMB to SMB coaxial cables.

The loop thru system is designed to provide an extended connection from Y to X.

The inter-module front panel wiring for an example 96x8 matrix is shown below and the switching diagram is

show overleaf.

40/42-724-021-L

Module #1

40/42-724-021-L

Module #2

40/42-724-021

Module #3

X Connections

Y Connections

Y Loop-Thru

Connections

Y Loop-Thru

Coaxial Cables

pickering pickering pickering

X Connections

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Pickering Steuereinheit Handbücher

Pickering

Pickering PXI 40-787 Bedienungsanleitung

Pickering

Pickering 40-280 Bedienungsanleitung

Pickering

Pickering 40-528A Bedienungsanleitung

Pickering

Pickering PXI BRIC 40-562A Bedienungsanleitung

Pickering

Pickering PXI 30 A Bedienungsanleitung

Pickering

Pickering SYSTEM 10 Bedienungsanleitung

Pickering

Pickering 40-521 Bedienungsanleitung

Pickering

Pickering 40-533B Bedienungsanleitung

Pickering

Pickering 40-581 Bedienungsanleitung

Pickering

Pickering PXI 40-145 Bedienungsanleitung

Pickering

Pickering SYSTEM 10 Bedienungsanleitung

Pickering

Pickering 40-574 Bedienungsanleitung

Pickering

Pickering PXI 40-664A Bedienungsanleitung

Pickering

Pickering PXI BRIC 40-563A Bedienungsanleitung

Pickering

Pickering 40-592A Bedienungsanleitung

Pickering

Pickering 40-331 Bedienungsanleitung

Pickering

Pickering 40-670A Bedienungsanleitung

Pickering

Pickering 40-573 Bedienungsanleitung

Pickering

Pickering 40-290-021 Bedienungsanleitung

Pickering

Pickering PXI 40-855 Bedienungsanleitung

Pickering

Pickering 40-565A Bedienungsanleitung

Pickering

Pickering SYSTEM 10 Bedienungsanleitung

Pickering

Pickering 40-545 Bedienungsanleitung

Pickering

Pickering 40-870 Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
