Pioneer DEH-P545R Bedienungsanleitung

MULTI-CD CONTROL HIGH POWER CD PLAYER WITH RDS TUNER

DEH-P545R X1P/EW

DEH-P544R X1P/EW

DEH-P443R X1P/EW

PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan

PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.

PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium

PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880

C PIONEER ELECTRONIC CORPORATION 1998

ORDER NO.

CRT2251

K-ZZA. AUG. 1998 Printed in Japan

-This additional service manual is designed to be used together with Model DEH-P545R/EW, DEH-

P544R/EW and DEH-P443R/EW Service Manual CRT2148. Refer to it for finding parts numbers and

adjustment,etc. which are not shown in this manual.

EXPLODED VIEWS AND PARTS LIST

PACKING(Page 3)

-PACKING SECTION PARTS LIST

* : Non spare part

Part No.

Mark No. Description DEH-P545R/EW DEH-P545R/X1P/EW

2 Accessory Assy CEA1917 UEA1917

3 Screw CBA1284 CBA1304

5 Bush CNV1009 CNV3930

* 6 Polyethylene Bag E36-615 CEG-127

17 Polyethylene Bag CEG-162 UEG-012

18-1 Polyethylene Bag CEG1116 UEG1116

18-2 Owner's Manual CRD2568 URD2568

18-3 Owner's Manual CRD2569 URD2569

18-4 Owner's Manual CRD2570 URD2570

19-1 Polyethylene Bag CEG1116 UEG1116

19-2 Installation Manual CRD2571 URD2571

19-4 Passport CRY1013 *CRY1014

* 19-5 Warranty Card CRY1087 URY1087

21 Carton CHG3440 UHG-106

22 Contain Box CHL3440 UHL-039

DEH-P545R,P544R,P443R

* : Non spare part

Part No.

Mark No. Description DEH-P544R/EW DEH-P544R/X1P/EW

2 Accessory Assy CEA1917 UEA1917

3 Screw CBA1284 CBA1304

5 Bush CNV1009 CNV3930

* 6 Polyethylene Bag E36-615 CEG-127

17 Polyethylene Bag CEG-162 UEG-012

18-1 Polyethylene Bag CEG1116 UEG1116

18-5 Owner's Manual CRD2631 URD2631

18-6 Installation Manual CRD2632 URD2632

* 18-9 Warranty Card CRY1087 URY1087

21 Carton CHG3441 UHG-105

22 Contain Box CHL3441 UHL-038

23 Protector CHP1766 UHP1766

24 Protector CHP1767 UHP1767

26 Case Assy CXB1063 UXB1063

* : Non spare part

Part No.

Mark No. Description DEH-P443R/EW DEH-P443R/X1P/EW

2 Accessory Assy CEA1917 UEA1917

3 Screw CBA1284 CBA1304

5 Bush CNV1009 CNV3930

* 6 Polyethylene Bag E36-615 CEG-127

17 Polyethylene Bag CEG-162 UEG-012

18-1 Polyethylene Bag CEG1116 UEG1116

18-5 Owner's Manual CRD2633 URD2633

18-6 Installation Manual CRD2634 URD2634

18-8 Passport CRY1013 *CRY1014

* 18-9 Warranty Card CRY1087 URY1087

21 Carton CHG3442 UHG-104

22 Contain Box CHL3442 UHL-037

23 Protector CHP1766 UHP1766

24 Protector CHP1767 UHP1767

26 Case Assy CXB1063 UXB1063

Part No.

Mark No. Description DEH-P545R/EW DEH-P545R/X1P/EW

23 Protector CHP1766 UHP1766

24 Protector CHP1767 UHP1767

26 Case Assy CXB1063 UXB1063

DEH-P545R,P544R,P443R

EXTERIOR(Page 8)

-EXTERIOR SECTION PARTS LIST

Part No.

Mark No. Description DEH-P545R/EW DEH-P545R/X1P/EW

14 Screw CBA1284 CBA1304

16 Bush CNV1009 CNV3930

19 Holder CNC6798 UNC6798

25 Tuner Amp Unit CWM5624 UWM5624

29 Clamper CEF1009(×2) CEF1009(×1)

30 Pin Jack(CN253) CKB1028 CKB1035

48 Case Assy CXB1063 UXB1063

52 Detach Grille Assy CXB1998 UXB1998

68 Keyboard Unit CWM5638 UWM5638

70 Cord CDE5665 UDE5665

81 Button CAC5180 CAC4836

89 Arm CNV4951 CNV4728

93 CD Mechanism Module CXK5004 UXK5004

Part No.

Mark No. Description DEH-P544R/EW DEH-P544R/X1P/EW

14 Screw CBA1284 CBA1304

16 Bush CNV1009 CNV3930

19 Holder CNC6798 UNC6798

25 Tuner Amp Unit CWM5624 UWM5624

29 Clamper CEF1009(×2) CEF1009(×1)

30 Pin Jack(CN253) CKB1028 CKB1035

48 Case Assy CXB1063 UXB1063

52 Detach Grille Assy CXB1999 UXB1999

68 Keyboard Unit CWM5639 UWM5639

70 Cord CDE5665 UDE5665

81 Button CAC5180 CAC4836

89 Arm CNV4951 CNV4728

93 CD Mechanism Module CXK5004 UXK5004

Part No.

Mark No. Description DEH-P443R/EW DEH-P443R/X1P/EW

14 Screw CBA1284 CBA1304

16 Bush CNV1009 CNV3930

19 Holder CNC6798 UNC6798

25 Tuner Amp Unit CWM5621 UWM5621

48 Case Assy CXB1063 UXB1063

52 Detach Grille Assy CXB2002 UXB2002

68 Keyboard Unit CWM5635 UWM5635

70 Cord CDE5665 UDE5665

81 Button CAC5180 CAC4836

89 Arm CNV4951 CNV4728

93 CD Mechanism Module CXK5004 UXK5004

94 IC(IC201) TDA7384 TDA7384A

DEH-P545R,P544R,P443R

ELECTRICAL PARTS LIST(Page 50)

TUNER AMP UNIT

Part No.

DEH-P545R/EW DEH-P545R/X1P/EW

Circuit Symbol and No. Part Name DEH-P544R/EW DEH-P544R/X1P/EW

IC 731 IC PMW001B PM4006B

Q 101, 801 Chip Transistor 2SA1162 2SA1037K

Q 501, 806, 923, 957 Transistor 2SC2712 2SC2412K

Q 851 Chip Transistor 2SA1162 2SA1037K

D 501 Diode MA152WK DAN202K

D 901, 902, 911, 922 Diode ERA15-02VH 1SR139-400

D 931, 932 Diode ERA15-02VH 1SR139-400

C 501, 502 CCSQCH150K50 CCSQCH150J50

C 514 CKSQYB473K16 CKSQYB473K25

C 532 CKSQYB473K16 CKSQYB473K25

Part No.

Circuit Symbol and No. Part Name DEH-P443R/EW DEH-P443R/X1P/EW

IC 201 IC TDA7384 TDA7384A

IC 731 IC PMW001B PM4006B

Q 101, 801 Chip Transistor 2SA1162 2SA1037K

Q 501, 806, 923, 957 Transistor 2SC2712 2SC2412K

C 501, 502 CCSQCH150K50 CCSQCH150J50

C 532 CKSQYB473K16 CKSQYB473K25

CONTROL UNIT

Part No.

DEH-P545R/EW DEH-P545R/X1P/EW

DEH-P544R/EW DEH-P544R/X1P/EW

Circuit Symbol and No. Part Name DEH-P443R/EW DEH-P443R/X1P/EW

C 102, 122, 124 CKSQYB104K16 CKSQYB104K25

C 110, 202, 203, 602 CKSQYB104K16 CKSQYB104K25

C 112 CKSQYB473K16 CKSQYB473K25

CD MECHANISM MODULE(Page 12)

-CD MECHANISM MODULE SECTION PARTS LIST

Part No.

DEH-P545R/EW DEH-P545R/X1P/EW

DEH-P544R/EW DEH-P544R/X1P/EW

Mark No. Description DEH-P443R/EW DEH-P443R/X1P/EW

1 Control Unit CWX2285 UWX2224
