Planet VC24024 Bedienerhandbuch

VDSL2 IP DSLAM

VC-2402 / VC-2402-48

Quick Installation Guide

Table of Contents

Mandatory Regulations ..................................................................................... 3

Package Contents ............................................................................................ 5

1. Installation of the VC-2402.......................................................................... 6

1.1 Pre-Installation.................................................................................... 6

1.1.1 Tools and Test Equipment Requirements....................................... 6

1.1.2 Safety Requirement.................................................................... 6

1.1.3 Electrostatic Discharge Protection ................................................ 6

1.2 Hardware Installation........................................................................... 7

1.2.1 Hardware Type........................................................................... 7

1.2.2 Installation Overview .................................................................. 7

1.2.3 Mounting the VC-2402................................................................ 8

1.2.4 Power and Ground Connections ..................................................10

1.2.5 Connecting the VDSL/ADSLx and POTS interfaces ........................11

1.2.6 Connecting the GBE1/GBE2 trunk interface..................................13

1.2.7 Ethernet Port (MGMT)................................................................14

1.2.8 Console Port (CID) ....................................................................15

1.2.9 Housekeeping and Alarm Contact Output Interface.......................16

1.3 Provisioning a Management IP port......................................................17

1.4 CongurationImport/Export ................................................................21

1.5 Firmware Update................................................................................23

2. Operating and Maintaining the VC-2402.......................................................25

2.1 Maintenance requirement ....................................................................25

2.1.1 Tools and Equipment Requirements.............................................25

2.1.2 System Spares..........................................................................25

2.1.3 Dispatching Maintenance Personnel.............................................25

2.1.4 Electrostatic Discharge Protection ...............................................25

2.1.5 Routine Maintenance .................................................................25

2.2 Powering the VC-2402 Up or Down ......................................................26

2.3 Controls and LED Indication ................................................................27

2.4 Cleaning Units....................................................................................29

3. Troubleshooting the VC-2402......................................................................30

3.1 Introduction to Troubleshooting............................................................30

3.2 Resolving Problems Indicated Through LEDs .........................................30

3.3 Resolving Problems Indicated Through Alarms.......................................30

3.4 Procedures for Troubleshooting the VC-2402.........................................30

Mandatory Regulations

The following sections describe the mandatory regulations that govern the

installation and operation of the VC-2402.

List of Terms

Table 1 lists the terms used in this chapter.

List of Terms

Term Expansion

CE Conformité Européenne

EN European Standards

FCC Federal Communications Commission

ITU-T Telecommunication Standardization Sector of the International

Telecommunications Union

RoHS Restriction of Hazardous Substances

General Requirements

The sections that follow outline the mandatory regulations that govern the

installation and operation of the VC-2402. You must adhere to these instructions so

that your system meets regulatory requirements.

Prevention of Access

The VC-2402 must be accessible only to authorized personnel. Install this apparatus

in a restricted access location or similar environment to prevent unauthorized

access.

Laser Interface

The VC-2402 uses Class I lasers as optical transmitter sources which are inherently

safe unless mishandled. The radiation from laser diodes is much more intense than

other light sources radiation. Only trained operating personnel thoroughly familiar

with laser radiation hazards should install or remove the ber optic cables and

cards in this system.

EMC Compliance

EMC compliance may require the use of ferrites, shielded cables or other special

accessories. Where required, these special accessories must be installed as per the

instructions.

Regulations compliance

Safety Approval

The system complies with the following safety norms:

– ProductSafetyRequirementsidentiedinEN60950:2000

– Over Voltage Protection Requirements of ITU-T K.20

EMI/EMC

The system meets the requirements of Telecommunications Network Equipment:

EN300-386.

Electromagnetic Compliance

The system complies with the standard FCC Part 15 Class A and EN55022.

RoHS

The system complies with the RoHS.

The system conforms to the CE requirement.

Package Contents

VC-2402 / VC-2402-48

• VC-2402 / VC-2402-48 Unit x 1

• AC / DC Power Cord x 1

• CD (Containing User’s Manual, QIG) x 1

• Quick Installation Guide x 1

• 2-Meter Telco-50 Cable x 2

• Console Cable x 1

• Rack-mounting x 2

• Screw Package x 2

• Connector Tenon x 2

If any of above items are damaged or missing, please contact your dealer

immediately.

1. Installation of the VC-2402

1.1 Pre-Installation

This section provides the information users have to ware before installing the VC-

2402. The information includes required installation tools, safety requirements, and

electrostatic discharge protection.

1.1.1 Tools and Test Equipment Requirements

To install and maintain the VC-2402, you should have the tools and test equipment

listed in the Table 1-1.

Table 1-1 Required Installation Tools and Materials

Item Required Purpose

Anti-static wrist strap Protect the VC-2402 system from electrostatic

discharge damage.

Hand tools Screw drivers for equipment removal and

replacement.

Wire cutter/stripper Prepare wires for electrical connections.

Accessories and hardware kit Screws, bolts, etc., for securing the equipment

on the desired location.

1.1.2 Safety Requirement

To prevent possible serious injury, do not apply power to the VC-2402 system at

the central ofce or any remote site until you’ve completed all of the installation

procedures and connected it to the external facilities. Be cautious, when turning

on/off the VC-2402 system power.

1.1.3 Electrostatic Discharge Protection

The terminal cards contain static-sensitive components. When handling them, be

sure to wear a properly grounded anti-static wrist strap to prevent the damage

from electrostatic discharge. If a wrist strap is not available, hold all cards only

by their edges or extractor handles. Do not touch any component or traces on

the cards. For future use, store cards in original shipped antistatic bags, or in an

approved static-protected bag or container.

To minimize the possible damage from electrostatic discharge, do not install the VC-

2402 in cold, dry places where static electricity can build up. Also, when handling

cards, do not touch their rear-edge connector traces. These electrical contact points

should be kept free of body oils and other contaminants.

1.2 Hardware Installation

The hardware installation for the VC-2402 is simple and without complex hardware

setting. However, it should be installed following out the standard installation

procedures. During installation, basic safety precaution should always be taken,

especially, be sure to wear an antistatic wrist strap to prevent static electricity from

damaging the system and injury to the operator. Handle electronic components as

little as possible.

This chapter provides the VC-2402 system hardware installation procedures and

install samples for reference. Please perform the procedures in the suggested

order.

1.2.1 Hardware Type

There are two different types of VC-2402 hardware with the front panel view:

VC-2402-48 with DC power and splitter

VC-2402 with AC power and splitter

1.2.2 Installation Overview

The installation consists of the following procedures. Each procedure will be

explained in detail in the following sections:

Step 1: Mount the system into the desired location of a rack.

Step 2: Turn the power switch in OFF position. Connect to the DC power supply,

and then check the voltage. Make sure the power switch is in OFF position

before wiring the power cable and grounding.

Step 3: Connect the cable between system and MDF.

After executing the previous procedures, please check the cable connection

robustness and correctness before turning on the power supply.

Step 4: Connect Console cable to COM port of a computer. Then run the terminal

program with the setting shown below:

Console Setting

Users can also access the DSLAM via Ethernet. By default the out-band IP address

of the DSLAM is obtained via DHCP. Users can also set the IP address manually

by using the CLI commands or Web Conguration Tool (refer to section 1.3). It’s

possible to access the DSLAM with telnet on port 23.

1.2.3 Mounting the VC-2402

The position and orientation of the brackets depends on the rack used for

mounting. The DSLAM can be front-mounted in a standard channel rack (5-inch

projection); and it can be shipped with the mounting brackets installed in one of

three mounting positions or shipped loose.

The mounting brackets can be rotated for use in wall mounting. Optional adhesive

feet may be attached to the bottom of the chassis so that it can be placed on a

desk or other smooth surface.

STANDARD

FRONT MOUNT

FRONT

MOUNTING

BRACKET

MOUNTING

BRACKET

Mounting Bracket Orientation (Top View)

Afterthesite requirementshave beenveried,thechassismay beinstalledatthe

specied location.  When mounting the chassis, practice good safety habits. Use

two or more people to secure the chassis. Relay rack mounting normally requires

at least two people.

Step Action

1Locate the chassis and obtain the appropriate chassis mounting

hardware.

2Determine and obtain the tools required for the chassis mounting

hardware.

3From the front of the relay rack, position the chassis in its relay rack

mounting location.

4Using the appropriate rack mounting hardware, secure the chassis in its

relay location on both left and right side of mounting bracket.

Note

The chassis should be empty during the chassis mounting proce-

dures. Remove any unit in the chassis, and store them according to

static-sensitive device storage procedures.

Warning

Hazardous voltages may exist on the chassis. Always practice good

safety habits when wiring a live circuit or performing maintenance.

For 23’’ Rack

For 19’’ Rack

Mounting Bracket Position for Standard Mount (VC-2402-48 shown)
