Power
Switch on the power by turning the key in the
battery. Power is applied via the throttle located on
the right-hand handlebar. The use of the throttle
applies and regulates the motor power assistance.
Gears & Chain
Change through the gears one at a time and only
use when the bicycle is being pedalled. To maintain
performance, ensure that all the mechanical
parts of the gears are lightly oiled (avoid getting
oil deposits on the wheel rims). If the chain
mechanism becomes dislodged, re-engage it on
the smallest gear cog.
Saddle
For maximum comfort and safety, ensure that the
saddle is correctly adjusted for the rider.
The height of the saddle can be adjusted without
tools. Loosen the lever at the top of the frame
below the saddle to raise or lower the saddle. Once
the saddle is at the required height, secure it by
tightening the lever.
The saddle also has a tension spring underneath
(black). This acts as the rear suspension. Turning
anti-clockwise slackens it off and clockwise
tightens.
Cycle Helmets
Although there is currently no legal requirement to
wear a cycle helmet, in the UK we recommend that
you do so for your safety. Wearing a cycle helmet
has been proven to reduce the likelihood of head
injuries in the event of an accident.
Professional Maintenance
We recommend that you have your PowaCycle
serviced by a professional cycle engineer at least
once a year to ensure ongoing safe performance. If
you are unsure as to how to carry out an assembly
procedure or adjustment, we recommend that you
consult your local cycle store.
Troubleshooting
1 – Brakes not working effectively
• Check the distance between the brake blocks
and the wheel rim.
• Check that the blocks are parallel with the
wheel rim.
• Check for any wear on the brake blocks.
Fine tuning to the brakes can be performed using
adjusters between the brake lever on the handlebars
and the brake cable. Major adjustments are made at
the brake blocks (you will need the appropriate tools).
See brake assembly instructions.
2 – Motor not working
• Check that the ignition is switched on.
• Check that the battery is properly inserted in
its housing.
• Check that the battery is charged.
• Check that none of the electrical cables have
become dislodged.
3 – Light(s) not working
• Check that the wiring is not broken.
• Check that the bulbs are inserted correctly.
• Check that all connections are properly made.
Warranty
1. The frame has a 2 year warranty.
2. Other main parts have a 1 year warranty.
3. The battery has a 6 month warranty, as
battery life will be determined by user care.
4. Bulbs, brake blocks, tyres etc – are regarded
as consumables, therefore when replacements
are required, these need to be purchased from
your local cycle shop or store.
Warning– PowaCycle Milan
It is essential to slacken off the back brake
significantly should you ever need to remove the
handlebars. This is performed at the back wheel end
and is the reverse process to that described in the
BACK BRAKE section.
