CommercialTreadmill Owner’s Manual

COMMERCIAL PRODUCTS DIVISION

C954

C956

page 2

COMMERCIAL PRODUCTS DIVISION

Thank you for purchasing the Precor C956 or C954 Commercial Treadmill.

Built to the exacting standards of the health club environment, the treadmill is

intended for commercial use and can withstand the rigors of daily club use with

little maintenance.

BeforeusingPrecorequipment,weurgeyoutofamiliarizeyourselfandstaffwith

the entire Owner’s Manual. Understanding this manual will help you and your

customers use the treadmill safely and successfully.

ABOUT THIS MANUAL

Inside this manual, you will find instructions for assembling and using the tread-

mill.To maximize the use of the unit, please study this manual thoroughly. The

manual uses the following conventions for identifying special information:

“Note:”Containsadditionalinformationthat applies to the preceding text.

“Important:”Indicates information to which you should payspecial attention.

“CAUTION:”Indicatesstepsorinformationnecessarytopreventharmtoyourselfor

damagetotheequipment.

“WARNING:”Providesinstructions toprevent electrical damage totheequipment

and prevent injuries to yourself.

“DANGER:” Indicates steps you must take to prevent electrical shock.

OBTAINING SERVICE

Do not attempt to service the treadmill yourself except for the maintenance tasks

described in this manual.The treadmill does not contain any user-serviceable parts.

For information about product operation or service, visit the Precor Web Site at

www.precor.com or contact an authorized Precor dealer or a Precor Factory

Authorized Service Company.To locate the dealer or service person nearest you,

call1-888-665-4404.

Theserial number on thetreadmillisprinted on alabellocatedonthe base frame.

Tolocate the serialnumber,verifythatthetreadmillisturnedOFF.Then,standat

therearofthetreadmillandface the display console, kneel down and look under

the treadmill on the inboard-side of the running bed at the left, rear corner. For

future reference, write the serial and model number and the date of purchase in

thespaceprovidedbelow.

Model/unit #: _____ Serial #: __________________ Date purchased:_____

Model/unit #: _____ Serial #: __________________ Date purchased: ____

If you have questions regarding the treadmill, use the model and serial number when-

ever you contact Precor Customer Service, your Precor dealer, or service person.

BeforeYou Begin

page 3

COMMERCIAL PRODUCTS DIVISION

When using an electrical appliance, basic precautions should always be taken,

including the following:

• Read all instructions before using the treadmill.These instructions are written

to ensure your safety and to protect the unit.

• To ensure the proper use and safety of the treadmill, make sure that all users

read this manual. Please make this manual a part of your training program.

Before beginning any fitness program, users of this equipment should obtain a

complete physical examination from a qualified physician.

Il est conseillé de subir un examen médical complet avant d’entreprendre tout

programme d’exercise. Si vous avez des étourdissements ou des faiblesses, arrêtez

les exercices immédiatement.

DANGER

WARNING

• When it is plugged in, do not leave the treadmill unattended. Unplug the treadmill

from the outlet when it is not in use, and before putting on or taking off parts.

• Do not allow children on or near the treadmill.

• Use the treadmill only for its intended use as described in this manual. Do not

use accessory attachments that are not recommended by the manufacturer—

such attachments might cause injuries.

• Never operate the unit if it has a damaged cord or plug, if it is not working

properly, if it has been dropped or damaged, or dropped in water. Return the

treadmill to a service center for examination and repair.

• Keep the power cord away from heated surfaces. Keep hands away from mov-

ing parts.

• Never block the air openings on the hood while operating the treadmill. Keep

the air openings clean and free of lint, hair, or anything that might impede the

free flow of air. Never drop or insert objects into any opening.

• Do not operate where aerosol (spray) products are being used or where oxygen

is being administered.

• Do not use outdoors.

• Turn the power switch to the OFF (O) position, when the treadmill is not in use

for an extended period of time.Then, remove the power plug from the outlet.

WARNING

IMPORTANT SAFETY INSTRUCTIONS

IMPORIMPOR

IMPORTT

TANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS

ANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS

ANT SAFETY INSTRUCTIONS

To reduce the risk of electrical shock, always unplug the

unit from its power source before cleaning or performing

any maintenance tasks.

To reduce the risk of burns, fire, electric shock, or injury to

persons, take the following precautions:

Connect the treadmill to a properly grounded outlet only.See

Grounding Instructions

on page 4.

SAVE THESE INSTRUCTIONS

page 4

COMMERCIAL PRODUCTS DIVISION

GROUNDING INSTRUCTIONS

The C956 or C954 treadmill must be grounded. If it should malfunction or

break down, grounding provides a path of least resistance for electric current

which reduces the risk of electrical shock. The C956 or C954 treadmill is

equipped with a power cord having an equipment-grounding conductor and a

grounding plug. The plug must be inserted into an appropriate outlet that is

properly installed and grounded in accordance with all local codes and ordi-

nances. If you do not follow these

Grounding Instructions

, you could void the

Precor limited warranty.

DANGER

Improper connection of the equipment-grounding conductor can result in a risk

of electric shock. Check with a qualified electrician or service person if you

are in doubt as to whether the treadmill is properly grounded. Do not modify

the plug provided with the treadmill—if it doesn’t fit the outlet, get a proper

outlet installed by a qualified technician.

120V Units Designated for U.S. Markets

The C956 or C954 treadmill must be connected to a 20 amp dedicated circuit

having a nominal rating of 120-volts. The treadmill’s grounding plug looks like

the plug illustrated in Diagram A. The power outlet must have the same con-

figuration as the plug. No adapter should be used with this product.

240V Units Designated for U.S. Markets

The C956 or C954 treadmill must be connected to a 20 amp dedicated circuit

having a nominal rating of 240-volts. The treadmill is factory-equipped with a

specific power supply cord to permit connection to a proper electric circuit.

Make sure that the treadmill is connected to an outlet having the same configu-

rations as the plug. See Diagram A. No adapter should be used with this product.

If the treadmill must be reconnected for use on a different type of electrical

circuit, the reconnection must be made by qualified service personnel.

SAFETY APPROVAL

When identified with the ETL-c logo, the treadmill has been tested and con-

forms to the requirements of CAN/CSA-E-335-1/2-94, Safety of Household

and Similar Electrical Appliances.

Diagram A

Correct power

outlet for U.S.

Markets: 20 amp

120-volt and

240-volt plugs.

120-volt grounding plug 240-volt grounding plug

page 5

COMMERCIAL PRODUCTS DIVISION

RFI — RADIO FREQUENCY INTERFERENCE

Federal Communications Commission Part 15

The treadmill has been tested and found to comply with,

• theIECEMCDirective(internationalelectromagneticcompatibilitycertification)

• the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a commercial installation.The treadmill generates, uses, and

can radiate radio frequency energy and, if not installed and used in accor-

dance with the owner’s manual instructions, may cause harmful interference

to radio communications. Operation of the treadmill in a residential area is

likely to cause harmful interference. If this occurs, the user will be required to

correcttheinterferenceathisor her own expense.

CAUTION

Canadian Department of Communications

This digital apparatus does not exceed the Class A limits for radio noise emis-

sions from digital apparatus set out in the Radio Interference Regulations of

the Canadian Department of Communications.

Leprésent appareil numérique n’émet pasdebruitsradioéélectriquesdépassant

leslimitesapplicablesauxappareilsnumériques de la Class A prescrites dans le

Règlementsur le brouillage radioélectriqueédictéparle ministére des Communi-

cationsduCanada.

EUROPEAN APPLICATIONS

This product conforms to the requirements of the European Council Directive 89/336/

EEC, Electromagnetic Compatibility and has been tested to the following standards:

EN55022, Limits & Methods of Measurement of Radio Interference, Informa-

tion Technology Equipment (Class A).

EN50082-1, Generic Immunity Standard for Residential, Commercial and Light

Industrial Products (Class A).

ThisproductadditionallyconformstotherequirementsoftheEuropeanCouncilDirective

73/23/EEC,LowVoltageDirectiveand hasbeentestedtothefollowingstandard:

IEC 335-1, Safety of Household and similar Electrical Appliances.

European Applications −−

−−

−240Volt Units Only

This product has been tested to the requirements of EN55022,“Limits & Methods of

Measurement of Radio Interference, Information Technology Equipment.” Per that

standard, the C956 or C954 treadmills are a Class A product. In a domestic environ-

ment, these products may cause radio interference, in which case the user is re-

sponsible to take adequate measures to alleviate the interference.

Per FCC rules, changes or modifications to the

treadmill not expressly approved by Precor, could

void the user’s authority to operate the equipment.

page 6

COMMERCIAL PRODUCTS DIVISION

PERSONAL SAFETY

When using the treadmill, take the following precautions:

• Do not allow children on or near the treadmill. Do not leave children unsu-

pervised around the treadmill.

• Assemble and operate the treadmill on a solid, surface. Locate the treadmill

a few feet from walls or furniture. Keep the area behind the treadmill clear.

• Turn OFF (O) and unplug the treadmill when adjusting or working near the rear

roller. Do not adjust the running belt when someone is standing on the unit.

• Keep all electrical components, such as the motor, power cord, and I/O switch,

away from liquids to prevent shock.Do not set anything on the handrail, display

console, or hood. Place liquids only in the appropriate receptacles.

• The security clip should be attached at waist level prior to beginning a

workout. A cord connects the security clip to the red STOP button on the

console.Ifauserencountersdifficulties, the running belt can be stopped by

pulling on the cord.To resume operation, press the Speed ▲key.

• Maintain the treadmill in good working condition. (Refer to the

Maintenance

section). Run through a check list prior to each use. Make sure that all

fasteners are secure and the belt is cleaned and running smoothly.

• Wear proper exercise clothing and shoes during a workout—no loose cloth-

ing. Tie long hair back. Keep all loose towels away from the running sur-

face. The running belt will not stop immediately if an object becomes

caught in the belt or rollers.

• Use care when getting on or off the treadmill. Use the handrail(s) whenever

possible. Step onto the running belt when the speed is at 1 mph (1.6 kph).

Never step off the treadmill while the running belt is moving.

• Before the running belt begins moving (prior to a workout), and after it

stops (at the end of a workout), straddle the belt by placing your feet

firmly on the right and left side platforms.

• Never turn ON the treadmill when someone is standing on the machine.

• Keep your body and head facing forward.Never attempt to turn around on

the treadmill when the running belt is moving.

• Do not rock the unit.Do not stand on the handrails, display console, or hood.

• Do not attempt to service the treadmill yourself other than the assembly and

maintenance instructions found in this manual. Refer to

Obtaining Service

• Do not overexert yourself or work to exhaustion.If you feel any pain or abnor-

mal symptoms, stop your workout immediately and consult your physician.

PRECOR HEART RATE OPTIONS—SAFETY GUIDELINES

The Precor Heart Rate Options are created and designed exclusively for Precor

products.The equipment is very sensitive—you should use the heart rate options

with this in mind and take time to read the guidelines found in this owner’s manual.

If you purchased the POLAR®chest strap, review the guidelines found in the

Precor Heart Rate Option Owner’s Manual

that is supplied with that option.

page 7

COMMERCIAL PRODUCTS DIVISION

BeforeYou Begin ..............................................................2

About this Manual .................................................................. 2

ObtainingService................................................................... 2

Important Safety Instructions................................................. 3

GroundingInstructions ........................................................... 4

SafetyApproval ..................................................................... 4

RFI—RadioFrequency Interference ..................................... 5

EuropeanApplications ........................................................... 5

PersonalSafety...................................................................... 6

Precor Heart Rate Option - Safety Guidelines ........................ 6

Unpacking theTreadmill ..................................................9

StandardEquipment............................................................... 9

OptionalEquipment................................................................ 9

HardwareKit .......................................................................... 10

AcquiretheAppropriateTools ................................................. 10

Setting Up the Treadmill ................................................11

Installation Requirements...................................................... 11

Assembly Instructions .......................................................... 11

Turning the Unit ON and OFF................................................ 18

Checking the Alignment of the Running Belt......................... 19

Club Information ............................................................20

Changing the Club Settings................................................... 20

Selecting the Language ......................................................... 20

Determining the Units of Measure ........................................ 21

DeterminingtheClubSpeedLimit .......................................... 22

Setting a Workout Time Limit ................................................ 22

Setting a Pause Time Limit.................................................... 22

Changing the C956 Custom Courses.................................... 23

Viewing the Odometer, Hours of Use,

Software Version, and Error Log ........................................... 24

Using CSAFEStandard Equipment ........................................ 24

Table of Contents

page 8

COMMERCIAL PRODUCTS DIVISION

Table of Contents

The C956/C954 Display..................................................25

FeaturesontheDisplayConsole............................................ 25

Top Display Windows ............................................................ 25

Center Display Window (C956 only) ..................................... 26

Elongated CenterDisplay (C956 andC954) ............................ 26

Keys on the Display Console ................................................ 28

Keypad Tips........................................................................... 28

Exercising on the Treadmill...........................................32

Using the Security Clip ......................................................... 32

Pause, Cool Down, Summary and Exit Features .................... 32

Quick Steps to Working Out.................................................. 34

Workout Tips ......................................................................... 34

Cooling Down After a Workout .............................................. 35

Courses ...........................................................................36

The Heart Rate Features....................................................... 36

Utilizing the Smart Rate® Feature.......................................... 36

Manual Mode and the Quick Start Key ................................. 37

The Track Course .................................................................. 38

Preprogrammed Courses ...................................................... 38

Interval Course ..................................................................... 38

Custom Courses ................................................................... 39

Random Course .................................................................... 39

Heart Rate Course ................................................................ 40

Weight Loss Course .............................................................. 41

Goal-based Courses ............................................................. 41

Maintenance....................................................................42

Cleaning the Equipment ........................................................ 42

Aligning the Running Belt ...................................................... 42

Storing the POLAR®Chest Strap .......................................... 43

Servicing the Treadmill .......................................................... 43

LongTerm Storage ................................................................ 43

Specifications............................................................back cover

page 9

COMMERCIAL PRODUCTS DIVISION

Thetreadmillis carefully tested and inspected beforeshipmentsoitshouldarrive

in good operating condition. Precor ships the unit in the following pieces:

• base frame assembly

• hood

• front assembly (includes 2 upright supports and display console)

• handrails(oneforeachside)

• owner’smanual and hardwarekit

CAUTION:The treadmill weighs over 350 pounds (157 kilograms).To avoid

injury and ensure the safety of the unit and yourself, we suggest that you

get assistance before removing the unit from the box.

If any items are missing, contact your Precor Commercial Products Service

Representative at 1-888-665-4404.

STANDARD EQUIPMENT

Both the C956 and C954 treadmills incorporate the Precor Smart Rate®and

Heart Rate features into it’s display consoles. Devices, such as FittLinxx that

are CSAFE compatible, can also be attached.

Note: An optional POLAR® chest strap must be worn to transmit a user’s heart

rate to the display console’s receiver. Another option, Precor “touch” heart rate

can be purchased (at point of sale) and provides electrode strips on the center

handrail. When a user places his or her hands over the strips and grasps the

handrail, a heart rate is transmitted to the receiver.

OPTIONAL EQUIPMENT

Optional equipment that you can purchase through your dealer includes:

• POLAR®chest strap

• Touch Heart Rate (separate display console)

• Longhandrails

If you are interested in obtaining Precor option kits for your unit, check with

you dealer. To locate the dealer nearest you, call 1-888-665-4404. For cus-

tomer service, see

Obtaining Service

on page 2.

Unpacking the Treadmill

page 10

COMMERCIAL PRODUCTS DIVISION

HARDWARE KIT

After unpacking the treadmill, open the hardware kit and make sure that you

have the following items shown in Diagram 1.

Diagram 1

C956/C954Hardware Kit

(A) 20 — 1” long buttonhead screws

(B)14 — washers

(D) 1/4” hex key — belt adjustment

(E) 3/16” hex key — mount uprights, display and handrails to base frame

(F) 5/32” hex key — install handrails to display and hood to base

Note: After assembling the treadmill, be sure to store the hex keys in a secure

place.Thetoolsareused forspecificmaintenanceproceduresthataredescribedin

this manual.

ACQUIRE THE APPROPRIATE TOOLS

Obtainthefollowingtools

before

assemblingthetreadmill.

Wirecutter

Bubblelevel

Medium weight string [about 1 foot (30 cm)]

Strongadhesivetape

SAE Standard socket set with a ratchet or 8” Crescent wrench

Andere Handbücher für C954

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Precor Tretmühle Handbücher

Precor

Precor 9.17 Technisches Dokument

Precor

Precor PRECISION SERIES Technisches Handbuch

Precor

Precor C934 Bedienungsanleitung

Precor

Precor Experience Series 700 Line Bedienungsanleitung

Precor

Precor GEN06 Series C952 Bedienungsanleitung

Precor

Precor Precision 400 Series Bedienungsanleitung

Precor

Precor 9.21 Bedienungsanleitung

Precor

Precor C954 Bedienungsanleitung

Precor

Precor C966 Bedienungsanleitung

Precor

Precor TRM10/GEN06 Bedienungsanleitung

Precor

Precor 905e Bedienungsanleitung

Precor

Precor C966i Bedienungsanleitung

Precor

Precor C954 Bedienungsanleitung

Precor

Precor 9.33 Bedienungsanleitung

Precor

Precor 903 Bedienungsanleitung

Precor

Precor Experience 600 Series Bedienungsanleitung

Precor

Precor M 9.1 Bedienungsanleitung

Precor

Precor C954 Gebrauchsanweisung

Precor

Precor M9.57 Bedienungsanleitung

Precor

Precor LOW-IMPACT TREADMILLS 9.33 Bedienungsanleitung

Precor

Precor TRM 885.v2 Bedienungsanleitung

Precor

Precor Cycles Integrated LCD Screen Option none Bedienungsanleitung

Precor

Precor 9.35 Bedienungsanleitung

Precor

Precor M9.5sp Bedienungsanleitung

Beliebte Tretmühle Handbücher anderer Marken

Treadly

Treadly TREADLY 2 Bedienungsanleitung

HEALTH ONE

HEALTH ONE Walk Ro Bedienungsanleitung

NordicTrack

NordicTrack NTL12941 Bedienungsanleitung

NordicTrack

NordicTrack T7.5 S Bedienungsanleitung

Gold's Gym

Gold's Gym ADVANTAGE GGTL12920 Bedienungsanleitung

Merax

Merax MS282992 Bedienungsanleitung

FYTTER

FYTTER RU-2SX Bedienungsanleitung

FitLogic

FitLogic freewill d225 Bedienungsanleitung

HOP-SPORT

HOP-SPORT ESTIMA HS-3200LB Bedienungsanleitung

Horizon Fitness

Horizon Fitness Adventure 5 Plus Bedienungsanleitung

Stamia

Stamia InMotion II Bedienungsanleitung

Smooth Fitness

Smooth Fitness EVO 3i Bedienungsanleitung

NordicTrack

NordicTrack NETL81810.0 Bedienungsanleitung

Schwinn

Schwinn 830/Journey 8.0 Bedienungsanleitung

Keys Fitness

Keys Fitness HealthTrainer HT-740T Bedienungsanleitung

Spirit

Spirit XT8 Bedienungsanleitung

NordicTrack

NordicTrack T 14.0 Treadmill Bedienungsanleitung

Master

Master F22 Bedienungsanleitung
