Primes CUBE Bedienungsanleitung

Revision 10 EN - 03/2021

35,0(6

Original Instructions

Cube

LaserDiagnosticsSoftware LDS

Cube App

35,0(6

Cube

Revision 10 EN - 03/2021

IMPORTANT!

READ CAREFULLY BEFORE USE.

KEEP FOR FUTURE USE.

35,0(6

Cube

4Revision 10 EN - 03/2021

Table of contents

1 Basic safety instructions 8

2 Symbol explanation 10

3 About this operating manual 11

4 Conditions at the installation site 11

5 Important notes on the lithium-ion battery 12

5.1 Charging the lithium-ion battery ........................................................... 12

5.2 Storing the device with a permanently installed lithium-ion battery........ 12

5.3 Dangers to health and the environment in the event of damage to the

lithium-ion battery ................................................................................ 12

5.4 Shipping the device with permanently installed lithium-ion battery........ 12

6 Device description 13

6.1 Functional description .......................................................................... 13

6.2 Measuring principle.............................................................................. 13

7 Transport 14

8 Installation/Removal 15

8.1 Prepare installation............................................................................... 15

8.2 Mounting position ................................................................................ 15

8.3 Align the device ................................................................................... 16

8.4 Install the device .................................................................................. 17

8.5 Remove the device .............................................................................. 17

9 Connections 18

9.1 Safety interlock .................................................................................... 18

9.2 Micro-USB socket ............................................................................... 19

9.3 Bluetooth............................................................................................. 20

35,0(6

Cube

Revision 10 EN - 03/2021

10 Functions of the On/Off button 21

11 Displays on the device 22

11.1 Status messages ................................................................................. 22

11.2 Warning message ................................................................................ 23

11.3 Charge status of the lithium-ion battery................................................ 23

12 Important information for measuring with the Cube 24

12.1 Safety instructions................................................................................ 24

12.2 Laser parameter setting ....................................................................... 26

12.2.1 Setting the laser rise time ....................................................... 26

12.2.2 Maximum permissible power density...................................... 27

12.2.3 Minimum and maximum energy input per measurement......... 28

12.3 Waiting times until the next measurement in a measurement series...... 29

12.4 Measurement with pulsed lasers .......................................................... 30

13 Measuring with the Cube 31

13.1 Start measurement .............................................................................. 31

13.2 Measuring results display..................................................................... 33

14 Measuring with the optional LaserDiagnosticsSoftware LDS 34

14.1 Notes of the LaserDiagnosticsSoftware LDS during measurement ....... 34

14.2 Connect the Cube to the LaserDiagnosticsSoftware LDS..................... 35

14.3 Open toolbench Cube measurement ................................................... 36

14.4 Settings for trigger level, power saving functions and automatic

measurement readiness....................................................................... 37

14.5 Start measurement .............................................................................. 39

14.6 Measuring results display..................................................................... 40

14.6.1 Display the current measurement in the toolbench Cube

measurement ......................................................................... 40

14.6.2 Display of the measurements stored in the Cube.................... 41

14.7 Delete measured values from the memory of the Cube ........................ 43

35,0(6

Cube

6Revision 10 EN - 03/2021

15 Measuring with the optional Cube App 44

16 Maintenance and service 45

16.1 Exchanging the protective window on the device................................. 45

16.1.1 Safety instructions.................................................................. 46

16.1.2 Exchanging the protective window ......................................... 47

17 Measures for the product disposal 48

18 Declaration of conformity 49

19 Technical data 50

20 Dimensions 52

21 Appendix 53

21.1 Max. laser power depending on the irradiation time

for devices with standard absorber ...................................................... 53

21.2 Max. laser power depending on the beam diameter

for devices with standard absorber ...................................................... 53

21.3 Max. laser power depending on the irradiation time

for devices with advanced absorber..................................................... 54

21.4 Max. laser power depending on the beam diameter

for devices with advanced absorber..................................................... 54

35,0(6

Cube

Revision 10 EN - 03/2021

PRIMES - The Company

PRIMES manufactures measuring devices used to analyze laser beams. These devices

are employed for the diagnostics of high-power lasers ranging from CO2lasers and

solid-state lasers to diode lasers. A wavelength range from infrared through to near UV

is covered, offering a wide variety of measuring devices to determine the following beam

parameters:

• Laser power

• Beam dimensions and position of an unfocused beam

• Beam dimensions and position of a focused beam

• Beam quality factor M²

Development, production and calibration of the measuring devices is performed at

PRIMES. This guarantees optimum quality, excellent service, and a short reaction time,

providing the basis for us to meet all of our customers’ requirements quickly and reliably.

PRIMES GmbH

Max-Planck-Str. 2

64319 Pfungstadt

Germany

Tel +49 6157 9878-0

[email protected]

www.primes.de

35,0(6

Cube

8Revision 10 EN - 03/2021

1 Basic safety instructions

Intended use

The device has been designed exclusively for measurements in the beam of high-power

lasers.

Use for any other purpose is considered as not intended and is strictly prohibited.

Furthermore, intended use requires that you observe all information, instructions, safety

notes and warning messages in this operating manual. The speciﬁcations given in chap-

ter19, „Technical data“, on page50 apply. Any given limit values must be complied

with.

If not used as intended, the device or the system in which the device is installed can be

damaged or destroyed. In addition, there is an increased risk to health and life. Only use

the device in such a way that there is no risk of injury.

If you still have questions after reading this operating manual, please contact PRIMES or

your supplier for your own safety.

Observing applicable safety regulations

Observe the safety-relevant laws, guidelines, standards and regulations in the current

editions published by the state, standardization organizations, professional associations,

etc. In particular, observe the regulations on laser safety and comply with their require-

ments.

Necessary safety measures

The device measures direct laser radiation, but does not emit any radiation itself. How-

ever, during the measurement the laser beam is directed at the device. This produces

scattered or directed reﬂection of the laser beam (laser class 4). The reﬂected beam is

usually not visible.

Protect yourself from direct and reﬂected laser radiation while working with the device

by taking the following measures:

• If the device is moved from its aligned position, increased scattered or directed

reﬂection of the laser beam occurs during measuring operation. Fix the device in

such a way that it cannot be moved by unintentional bumping or pulling on the

cables.

• Connect the laser control’s safety interlock to the device. Check that the safety

interlock will switch off the laser properly in case of error.

35,0(6

Cube

Revision 10 EN - 03/2021

• Install safety switches or emergency safety mechanisms that allow the laser to be

switched off immediately.

• Use suitable beam guidance and beam absorber elements which do not emit any

hazardous substances when irradiated.

• Wear safety goggles adapted to the power, power density, laser wave length and

operating mode of the laser beam source in use.

• Wear suitable protective clothing or protective gloves if necessary.

• If possible, also protect yourself from direct laser radiation and scattered radiation

by using separating protective devices that block or attenuate the radiation.

Employing qualiﬁed personnel

The device may only be operated by qualiﬁed personnel. The qualiﬁed personnel must

have been instructed in the installation and operation of the device and must have a

basic understanding of working with high-power lasers, beam guiding systems and

focusing units.

Conversions and modiﬁcations

The device may not be modiﬁed in terms of design or safety without the express con-

sent of the manufacturer. The same applies to unauthorised opening, dismantling and

repair. The removal of covers is only permitted within the scope of the intended use.

Liability disclaimer

Manufacturer and distributor exclude any liability for damages and injuries which are

direct or indirect consequences of using the device not as intended or modifying the

device or the associated software without authorization.

35,0(6

Cube

10 Revision 10 EN - 03/2021

2 Symbol explanation

The following symbols and signal words indicate possible residual risks:

DANGER

Means that death or serious physical injuries will occur if necessary safety

precautions are not taken.

WARNING

Means that death or serious physical injuries can occur if necessary safety

precautions are not taken.

CAUTION

Means that a slight physical injury can occur if necessary safety precautions

are not taken.

NOTICE

Means that property damages can occur if necessary safety precautions are

not taken.

The device itself or the packing bears the following symbols to indicate require-

ments and possible dangers:

Read and observe the operating instructions and safety guidelines before

startup!

The device contains a permanently built-in lithium-ion battery. To avoid health

and environmental damage, the battery must be disposed of in accordance

with the applicable national and international laws.
